GUI development with Rust and GTK 4

by Julian Hofer, with contributions from the community

GTK 4 is the newest version of a popular cross-platform widget toolkit written in C. Thanks to GObject-Introspection, GTK's API can be easily targeted by various programming languages. The API even describes the ownership of its parameters!

Managing ownership without giving up speed is one of Rust's greatest strengths, which makes it an excellent choice to develop GTK apps with. With this combination you do not have to worry about hitting bottlenecks mid-project anymore. Additionally, with Rust you will have nice things such as

  • thread safety,
  • memory safety,
  • sensible dependency management as well as
  • excellent third party libraries.

The gtk-rs project provides bindings to many GTK-related libraries which we will be using throughout this book.

Who this book is for

This book assumes that you know your way around Rust code. If this is not already the case, reading The Rust Programming Language is an enjoyable way to get you to that stage. If you have experience with another low-level language such as C or C++ you might find that reading A half hour to learn Rust gives you sufficient information as well.

Luckily, this — together with the wish to develop graphical applications — is all that is necessary to benefit from this book.

How to use this book

In general, this book assumes that you are reading it in sequence from front to back. However, if you are using it as a reference for a certain topic, you might find it useful to just jump into it.

There are two kinds of chapters in this book: concept chapters and project chapters. In concept chapters, you will learn about an aspect of GTK development. In project chapters, we will build small programs together, applying what you have learned so far.

The book strives to explain essential GTK concepts paired with practical examples. However, if a concept can be better conveyed with a less practical example, we took this path most of the time. If you are interested in contained and useful examples, we refer you to the corresponding section of gtk4-rs' repository.

Every valid code snippet in the book is part of a listing. The listings be found in the git repository of gtk4-rs.

License

The book itself is licensed under the Creative Commons Attribution 4.0 International license. The only exception are the code snippets which are licensed under the MIT license.

Installation

In order to develop a gtk-rs app, you basically need two things on your workstation:

  • the Rust toolchain, and
  • the GTK 4 library.

As so often the devil hides in the details, which is why we will list the installation instructions for each operating system in the following chapters.

Linux

Flatpak

If you develop on Linux, using Flatpak is the most convenient option. With Flatpak your whole workflow is containerized, and your users get the very same application you develop on including all dependencies. First, assure that Flatpak is installed on your system, check this website to see if any steps are necessary on your distribution. Download the gtk-rust-template and follow the instructions in its README.

Then either install

That is it. The build dependencies can be downloaded by the IDE. With GNOME Builder, you only have to press the run button for that.

Host

If you develop on the host, you first have to install rustup. You can find the up-to-date instructions on rustup.rs.

Then install GTK 4 and the build essentials. To do this, execute the command belonging to the distribution you are using.

Fedora and derivatives:

sudo dnf install gtk4-devel gcc

Debian and derivatives:

sudo apt install libgtk-4-dev build-essential

Arch and derivatives:

sudo pacman -S gtk4 base-devel

macOS

First install rustup. You can find the up-to-date instructions on rustup.rs.

Then install homebrew.

Finally, install GTK 4 by executing the following in your terminal:

brew install gtk4

Windows

When preparing your Windows machine, you have to decide between either using the MSVC toolchain or the GNU toolchain. If in doubt, go for MSVC since that is the default on Windows. You will want to go for the GNU toolchain if you depend on libraries that can only be compiled with the GNU toolchain.

MSVC toolchain

Install Rustup

Install the rust toolchain via rustup.

Remove residues from the GNU toolchain

If you used the GNU toolchain before, make sure to revert all changes you made to environment variables during the installation process.

Also set the rust toolchain back to msvc by executing:

rustup default stable-msvc

Visual Studio

Install Visual Studio Community from visualstudio.microsoft.com. Make sure to check the box "Desktop development with C++" during the installation process.

Git

Download git from gitforwindows.org.

Python

Download python from python.org. Make sure to opt-in to adding Python to your Path during the installation process.

Meson

Install meson by executing:

pip install meson ninja

Pkg-config

Download pkg-config-lite from sourceforge.net. Then extract and unpack it in C:/, so that the executable is in C:\pkg-config-lite-0.28-1\bin.

Update Path environment variable

  1. Go to settings -> Search and open Advanced system settings -> Click on Environment variables
  2. Select Path -> Click on Edit -> Add the following entries:
C:\pkg-config-lite-0.28-1\bin
C:\gnome\bin

Compile and install GTK 4

From the Windows start menu, search for x64 Native Tools Command Prompt for VS 2019. That will open a terminal configured to use MSVC x64 tools. From there, run the following commands:

cd /
git clone https://gitlab.gnome.org/GNOME/gtk.git --depth 1
cd gtk
meson setup builddir --prefix=C:/gnome -Dbuild-tests=false -Dmedia-gstreamer=disabled
meson install -C builddir

Set PKG_CONFIG_PATH environment variable

  1. Go to settings -> Search and open Advanced system settings -> Click on Environment variables
  2. Under User variables click on New and add:
  • Variable name: PKG_CONFIG_PATH
  • Variable value: C:\gnome\lib\pkgconfig

GNU toolchain

Install Rustup

Install the rust toolchain via rustup.

MSYS2

Install MSYS2 from www.msys2.org

Install GTK 4

From the Windows start menu, search for MSYS2 MinGW 64-bit. That will open a terminal configured to use MinGW x64 tools.

There, execute the following commands to install GTK 4, pkgconf and gcc.

pacman -S mingw-w64-x86_64-gtk4 mingw-w64-x86_64-pkgconf mingw-w64-x86_64-gcc

Update Path environment variable

  1. Go to settings -> Search and open Advanced system settings -> Click on Environment variables
  2. Select Path -> Click on Edit -> Add the following three entries:
C:\msys64\mingw64\include
C:\msys64\mingw64\bin
C:\msys64\mingw64\lib

Setup the GNU toolchain for Rust

The default toolchain on windows is stable-msvc. To switch to stable-gnu, run the following commands from your terminal:

  1. rustup toolchain install stable-gnu
  2. rustup default stable-gnu

Please note that this command might change in the future. If it does not work anymore, please open an issue on our repo.

Project Setup

There are two recommended ways to set up your workstation in order to develop gtk-rs applications. Let us go through them one by one.

Cargo

Cargo is Rust's build system and package manager. If following the book is all you care about, using only Cargo will work fine for you.

Let us begin by installing all necessary tools. First, follow the instructions on the GTK website in order to install GTK 4. Then install Rust with rustup.

Now, create a new project by executing:

cargo new my-gtk-app

Add the following lines to your dependencies in Cargo.toml, where X.X should be replaced with the most up-to-date version of the gtk4 crate.

gtk = { version = "X.X", package = "gtk4" }

Per default gtk4-rs is compatible with all GTK 4 releases. If you want to use functionality that has been added to later releases, you have to specify this as a feature. If you want to use functionality of GTK 4.6, you would add the following to your gtk dependency in Cargo.toml.

gtk = { version = "X.X", package = "gtk4", features = ["v4_6"]}

This will only work if your available GTK version is indeed >= 4.6. You can get the version by executing the following command:

pkg-config --modversion gtk4

Now, you can run your application by executing:

cargo run

Cargo + Meson

Cargo is almost enough, but it is not well suited for handling resources such as icons or UI definition files. That is why we recommend to use Meson on top of it. It is cross-platform, and its syntax is very readable. Meson takes care of

Here as well, you first follow the instructions on the GTK website in order to install GTK 4. Then install Rust with rustup. Finally, install Meson by following the instructions on the Meson website.

You can download a ready-to-use gtk-rust-template here. Follow the instructions in the README to initialize your own application. Then configure your project.

meson setup builddir

In order to compile and install it run the following command. You have to execute it every time you modify your application.

meson install -C builddir

Now, the application should be in a folder included in your system path. You can either start it with the application launcher of your choice or from within your terminal.

Hello World!

Now that we have got a working installation, let us get right into it!

At the very least, we need to create an Application instance with an application id. For that we use the builder pattern which many gtk-rs objects support.

Filename: listings/hello_world/1/main.rs

use gtk::prelude::*;
use gtk::Application;

fn main() {
    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Run the application
    app.run();
}

It builds fine, but nothing appears on our screen. GTK warns us that something should be called in its activate step. So let us create a window there.

Filename: listings/hello_world/2/main.rs

use gtk::prelude::*;
use gtk::{Application, ApplicationWindow};

fn main() {
    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Connect to "activate" signal of `app`
    app.connect_activate(build_ui);

    // Run the application
    app.run();
}

fn build_ui(app: &Application) {
    // Create a window and set the title
    let window = ApplicationWindow::builder()
        .application(app)
        .title("My GTK App")
        .build();

    // Present window
    window.present();
}

That is better!

Normally we expect to be able to interact with the user interface. Also, the name of the chapter suggests that the phrase "Hello World!" will be involved.

Filename: listings/hello_world/3/main.rs

use gtk::prelude::*;
use gtk::{Application, ApplicationWindow, Button};

fn main() {
    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Connect to "activate" signal of `app`
    app.connect_activate(build_ui);

    // Run the application
    app.run();
}

fn build_ui(app: &Application) {
    // Create a button with label and margins
    let button = Button::builder()
        .label("Press me!")
        .margin_top(12)
        .margin_bottom(12)
        .margin_start(12)
        .margin_end(12)
        .build();

    // Connect to "clicked" signal of `button`
    button.connect_clicked(move |button| {
        // Set the label to "Hello World!" after the button has been clicked on
        button.set_label("Hello World!");
    });

    // Create a window
    let window = ApplicationWindow::builder()
        .application(app)
        .title("My GTK App")
        .child(&button)
        .build();

    // Present window
    window.present();
}

There is now a button and if we click on it, its label becomes "Hello World!".

Wasn't that hard to create our first gtk-rs app, right? Let us now get a better understanding of what we did here.

Widgets

Widgets are the components that make up a GTK application. GTK offers many-preexisting ones and if those do not fit, you can even create custom ones. There are display widgets, buttons, containers and windows. One kind of widget might be able to contain other widgets, it might present information and it might react to interaction.

The Widget Gallery is useful to find out which widget fits your needs. Let us say we want to add a button to our app. We have quite a bit of choice here, but let us take the simplest one — a Button.

GTK is an object-oriented framework, so all widgets are part of an inheritance tree with GObject at the top. The inheritance tree of a Button looks like this:

GObject
╰── Widget
    ╰── Button

The GTK documentation also tells us that Button implements the interfaces GtkAccessible, GtkActionable, GtkBuildable, GtkConstraintTarget.

Now let us compare that with the corresponding Button struct in gtk-rs. The gtk-rs documentation tells us which traits it implements. We find that these traits either have a corresponding base class or interface in the GTK docs. In the "Hello World" app we wanted to react to a button click. This behavior is specific to a button, so we expect to find a suitable method in the ButtonExt trait. And indeed, ButtonExt includes the method connect_clicked.

Filename: listings/hello_world/3/main.rs

use gtk::prelude::*;
use gtk::{Application, ApplicationWindow, Button};

fn main() {
    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Connect to "activate" signal of `app`
    app.connect_activate(build_ui);

    // Run the application
    app.run();
}

fn build_ui(app: &Application) {
    // Create a button with label and margins
    let button = Button::builder()
        .label("Press me!")
        .margin_top(12)
        .margin_bottom(12)
        .margin_start(12)
        .margin_end(12)
        .build();

    // Connect to "clicked" signal of `button`
    button.connect_clicked(move |button| {
        // Set the label to "Hello World!" after the button has been clicked on
        button.set_label("Hello World!");
    });

    // Create a window
    let window = ApplicationWindow::builder()
        .application(app)
        .title("My GTK App")
        .child(&button)
        .build();

    // Present window
    window.present();
}

Please note that Rust requires bringing traits into scope, before using one of its methods. In our example we did that by adding the following line:

Filename: listings/hello_world/3/main.rs

use gtk::prelude::*;
use gtk::{Application, ApplicationWindow, Button};

fn main() {
    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Connect to "activate" signal of `app`
    app.connect_activate(build_ui);

    // Run the application
    app.run();
}

fn build_ui(app: &Application) {
    // Create a button with label and margins
    let button = Button::builder()
        .label("Press me!")
        .margin_top(12)
        .margin_bottom(12)
        .margin_start(12)
        .margin_end(12)
        .build();

    // Connect to "clicked" signal of `button`
    button.connect_clicked(move |button| {
        // Set the label to "Hello World!" after the button has been clicked on
        button.set_label("Hello World!");
    });

    // Create a window
    let window = ApplicationWindow::builder()
        .application(app)
        .title("My GTK App")
        .child(&button)
        .build();

    // Present window
    window.present();
}

With it, we import all necessary traits for dealing with widgets. You probably want to bring the prelude into scope in most of your source files.

GObject Concepts

GTK is an object-oriented framework. It is written in C, which does not support object-orientation out of the box. That is why, GTK relies on the GObject library to provide the object system.

We already learned, that gtk-rs maps GObject concepts like inheritance and interfaces to Rust traits. In this chapter we will additionally find out:

  • How to manage the memory of GObjects.
  • How to create our own GObjects via subclassing.
  • How to deal with generic values.
  • How to use properties.
  • How to emit and receive signals.

Memory Management

A GObject (or glib::Object in Rust terms) is a reference-counted, mutable object. Let us see in a set of real life examples which consequences this has.

use gtk::prelude::*;
use gtk::{self, Application, ApplicationWindow, Button, Orientation};

fn main() {
    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Connect to "activate" signal of `app`
    app.connect_activate(build_ui);

    // Run the application
    app.run();
}

fn build_ui(application: &Application) {
    // Create a window
    let window = ApplicationWindow::new(application);

    // Create two buttons
    let button_increase = Button::builder()
        .label("Increase")
        .margin_top(12)
        .margin_bottom(12)
        .margin_start(12)
        .margin_end(12)
        .build();
    let button_decrease = Button::builder()
        .label("Decrease")
        .margin_top(12)
        .margin_bottom(12)
        .margin_start(12)
        .margin_end(12)
        .build();

    // A mutable integer
    let mut number = 0;

    // Connect callbacks
    // When a button is clicked, `number` should be changed
    button_increase.connect_clicked(|_| number += 1);
    button_decrease.connect_clicked(|_| number -= 1);

    // Add buttons
    let gtk_box = gtk::Box::new(Orientation::Vertical, 0);
    window.set_child(Some(&gtk_box));
    gtk_box.append(&button_increase);
    gtk_box.append(&button_decrease);
    window.present();
}

Here we would like to create a simple app with two buttons. If we click on one button, an integer number should be increased. If we press the other one, it should be decreased. The Rust compiler refuses to compile it though.

For once the borrow checker kicked in:

error[E0499]: cannot borrow `number` as mutable more than once at a time
  --> main.rs:27:37
   |
26 |     button_increase.connect_clicked(|_| number += 1);
   |     ------------------------------------------------
   |     |                               |   |
   |     |                               |   first borrow occurs due to use of `number` in closure
   |     |                               first mutable borrow occurs here
   |     argument requires that `number` is borrowed for `'static`
27 |     button_decrease.connect_clicked(|_| number -= 1);
   |                                     ^^^ ------ second borrow occurs due to use of `number` in closure
   |                                     |
   |                                     second mutable borrow occurs here

Also, the compiler tells us that our closures may outlive number:


error[E0373]: closure may outlive the current function, but it borrows `number`, which is owned by the current function
  --> main.rs:26:37
   |
26 |     button_increase.connect_clicked(|_| number += 1);
   |                                     ^^^ ------ `number` is borrowed here
   |                                     |
   |                                     may outlive borrowed value `number`
   |
note: function requires argument type to outlive `'static`
  --> main.rs:26:5
   |
26 |     button_increase.connect_clicked(|_| number += 1);
   |     ^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^
help: to force the closure to take ownership of `number` (and any other referenced variables), use the `move` keyword
   |
26 |     button_increase.connect_clicked(move |_| number += 1);
   |                                     ^^^^^^^^

Thinking about the second error message, it makes sense that the closure requires the lifetimes of references to be 'static. The compiler cannot know when the user presses a button, so references must live forever. And our number gets immediately deallocated after it reaches the end of its scope. The error message is also suggesting that we could take ownership of number. But is there actually a way that both closures could take ownership of the same value?

Yes! That is exactly what the Rc type is there for. The Rc counts the number of strong references created via Clone::clone and released via Drop::drop, and only deallocates it when this number drops to zero. We call every object containing a strong reference a shared owner of the value. If we want to modify the content of our Rc, we can use the Cell type.

The Cell class is only suitable for objects that implement the Copy trait. For other objects, RefCell is the way to go. You can learn more about the two cell types in this section of an older edition of the Rust book.

Filename: listings/gobject_memory_management/1/main.rs

use gtk::prelude::*;
use gtk::Application;
use gtk::{self, ApplicationWindow, Button, Orientation};
use std::{cell::Cell, rc::Rc};

fn main() {
    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Connect to "activate" signal of `app`
    app.connect_activate(build_ui);

    // Run the application
    app.run();
}
fn build_ui(app: &Application) {
    // Create two buttons
    let button_increase = Button::builder()
        .label("Increase")
        .margin_top(12)
        .margin_bottom(12)
        .margin_start(12)
        .margin_end(12)
        .build();
    let button_decrease = Button::builder()
        .label("Decrease")
        .margin_top(12)
        .margin_bottom(12)
        .margin_start(12)
        .margin_end(12)
        .build();

    // Reference-counted object with inner-mutability
    let number = Rc::new(Cell::new(0));

    // Connect callbacks, when a button is clicked `number` will be changed
    let number_copy = number.clone();
    button_increase.connect_clicked(move |_| number_copy.set(number_copy.get() + 1));
    button_decrease.connect_clicked(move |_| number.set(number.get() - 1));

    // Add buttons to `gtk_box`
    let gtk_box = gtk::Box::builder()
        .orientation(Orientation::Vertical)
        .build();
    gtk_box.append(&button_increase);
    gtk_box.append(&button_decrease);

    // Create a window
    let window = ApplicationWindow::builder()
        .application(app)
        .title("My GTK App")
        .child(&gtk_box)
        .build();

    // Present the window
    window.present();
}

It is not very nice though to fill the scope with temporary variables like number_copy. We can improve that by using the glib::clone! macro.

Filename: listings/gobject_memory_management/2/main.rs

use glib::clone;
use gtk::prelude::*;
use gtk::{self, ApplicationWindow, Button, Orientation};
use gtk::{glib, Application};
use std::{cell::Cell, rc::Rc};

fn main() {
    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Connect to "activate" signal of `app`
    app.connect_activate(build_ui);

    // Run the application
    app.run();
}
fn build_ui(app: &Application) {
    // Create two buttons
    let button_increase = Button::builder()
        .label("Increase")
        .margin_top(12)
        .margin_bottom(12)
        .margin_start(12)
        .margin_end(12)
        .build();
    let button_decrease = Button::builder()
        .label("Decrease")
        .margin_top(12)
        .margin_bottom(12)
        .margin_start(12)
        .margin_end(12)
        .build();

    // Reference-counted object with inner mutability
    let number = Rc::new(Cell::new(0));
    // Connect callbacks
    // When a button is clicked, `number` will be changed
    button_increase.connect_clicked(clone!(@strong number => move |_| {
        number.set(number.get() + 1);
    }));
    button_decrease.connect_clicked(move |_| {
        number.set(number.get() - 1);
    });

    // Add buttons to `gtk_box`
    let gtk_box = gtk::Box::builder()
        .orientation(Orientation::Vertical)
        .build();
    gtk_box.append(&button_increase);
    gtk_box.append(&button_decrease);

    // Create a window
    let window = ApplicationWindow::builder()
        .application(app)
        .title("My GTK App")
        .child(&gtk_box)
        .build();

    // Present the window
    window.present();
}

Just like Rc<Cell<T>>, GObjects are reference-counted and mutable. Therefore, we can pass the buttons the same way to the closure as we did with number.

Filename: listings/gobject_memory_management/3/main.rs

use std::{cell::Cell, rc::Rc};

use glib::clone;
use gtk::prelude::*;
use gtk::{self, ApplicationWindow, Button, Orientation};
use gtk::{glib, Application};

fn main() {
    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Connect to "activate" signal of `app`
    app.connect_activate(build_ui);

    // Run the application
    app.run();
}

fn build_ui(app: &Application) {
    // Create two buttons
    let button_increase = Button::builder()
        .label("Increase")
        .margin_top(12)
        .margin_bottom(12)
        .margin_start(12)
        .margin_end(12)
        .build();
    let button_decrease = Button::builder()
        .label("Decrease")
        .margin_top(12)
        .margin_bottom(12)
        .margin_start(12)
        .margin_end(12)
        .build();

    let number = Rc::new(Cell::new(0));

    // Connect callbacks
    // When a button is clicked, `number` and label of the other button will be changed
    button_increase.connect_clicked(clone!(@weak number, @strong button_decrease =>
        move |_| {
            number.set(number.get() + 1);
            button_decrease.set_label(&number.get().to_string());
    }));
    button_decrease.connect_clicked(clone!(@strong button_increase =>
        move |_| {
            number.set(number.get() - 1);
            button_increase.set_label(&number.get().to_string());
    }));

    // Add buttons to `gtk_box`
    let gtk_box = gtk::Box::builder()
        .orientation(Orientation::Vertical)
        .build();
    gtk_box.append(&button_increase);
    gtk_box.append(&button_decrease);

    // Create a window
    let window = ApplicationWindow::builder()
        .application(app)
        .title("My GTK App")
        .child(&gtk_box)
        .build();

    // Present the window
    window.present();
}

If we now click on one button, the other button's label gets changed.

But whoops! Did we forget about one annoyance of reference-counted systems? Yes we did: reference cycles. button_increase holds a strong reference to button_decrease and vice-versa. A strong reference keeps the referenced value from being deallocated. If this chain leads to a circle, none of the values in this cycle ever get deallocated. With weak references we can break this cycle, because they do not keep their value alive but instead provide a way to retrieve a strong reference if the value is still alive. Since we want our apps to free unneeded memory, we should use weak references for the buttons instead.

In this simple example, GTK actually resolves the reference cycle on its own once you close the window. However, the general point to avoid strong references whenever possible remains valid.

Filename: listings/gobject_memory_management/4/main.rs

use std::{cell::Cell, rc::Rc};

use glib::clone;
use gtk::prelude::*;
use gtk::{self, ApplicationWindow, Button, Orientation};
use gtk::{glib, Application};

fn main() {
    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Connect to "activate" signal of `app`
    app.connect_activate(build_ui);

    // Run the application
    app.run();
}

fn build_ui(app: &Application) {
    // Create two buttons
    let button_increase = Button::builder()
        .label("Increase")
        .margin_top(12)
        .margin_bottom(12)
        .margin_start(12)
        .margin_end(12)
        .build();
    let button_decrease = Button::builder()
        .label("Decrease")
        .margin_top(12)
        .margin_bottom(12)
        .margin_start(12)
        .margin_end(12)
        .build();

    // Reference-counted object with inner mutability
    let number = Rc::new(Cell::new(0));

    // Connect callbacks
    // When a button is clicked, `number` and label of the other button will be changed
    button_increase.connect_clicked(clone!(@weak number, @weak button_decrease =>
        move |_| {
            number.set(number.get() + 1);
            button_decrease.set_label(&number.get().to_string());
    }));
    button_decrease.connect_clicked(clone!(@weak button_increase =>
        move |_| {
            number.set(number.get() - 1);
            button_increase.set_label(&number.get().to_string());
    }));

    // Add buttons to `gtk_box`
    let gtk_box = gtk::Box::builder()
        .orientation(Orientation::Vertical)
        .build();
    gtk_box.append(&button_increase);
    gtk_box.append(&button_decrease);

    // Create a window
    let window = ApplicationWindow::builder()
        .application(app)
        .title("My GTK App")
        .child(&gtk_box)
        .build();

    // Present the window
    window.present();
}

The reference cycle is broken. Every time the button is clicked, glib::clone tries to upgrade the weak reference. If we now for example click on one button and the other button is not there anymore, upgrade will return None. Per default, it immediately returns from the closure with () as return value. In case the closure expects a different return value or a panic is preferred @default-return or @default-panic. For more information about glib::clone, please have a look at the docs.

Notice that we move number in the second closure. If we had only moved weak reference in both closures, nothing would have kept number alive and the closure would have never been called. Thinking about this, button_increase and button_decrease are also dropped at the end of the scope of build_ui. Who then keeps the buttons alive?

Filename: listings/gobject_memory_management/4/main.rs

use std::{cell::Cell, rc::Rc};

use glib::clone;
use gtk::prelude::*;
use gtk::{self, ApplicationWindow, Button, Orientation};
use gtk::{glib, Application};

fn main() {
    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Connect to "activate" signal of `app`
    app.connect_activate(build_ui);

    // Run the application
    app.run();
}

fn build_ui(app: &Application) {
    // Create two buttons
    let button_increase = Button::builder()
        .label("Increase")
        .margin_top(12)
        .margin_bottom(12)
        .margin_start(12)
        .margin_end(12)
        .build();
    let button_decrease = Button::builder()
        .label("Decrease")
        .margin_top(12)
        .margin_bottom(12)
        .margin_start(12)
        .margin_end(12)
        .build();

    // Reference-counted object with inner mutability
    let number = Rc::new(Cell::new(0));

    // Connect callbacks
    // When a button is clicked, `number` and label of the other button will be changed
    button_increase.connect_clicked(clone!(@weak number, @weak button_decrease =>
        move |_| {
            number.set(number.get() + 1);
            button_decrease.set_label(&number.get().to_string());
    }));
    button_decrease.connect_clicked(clone!(@weak button_increase =>
        move |_| {
            number.set(number.get() - 1);
            button_increase.set_label(&number.get().to_string());
    }));

    // Add buttons to `gtk_box`
    let gtk_box = gtk::Box::builder()
        .orientation(Orientation::Vertical)
        .build();
    gtk_box.append(&button_increase);
    gtk_box.append(&button_decrease);

    // Create a window
    let window = ApplicationWindow::builder()
        .application(app)
        .title("My GTK App")
        .child(&gtk_box)
        .build();

    // Present the window
    window.present();
}

When we append the buttons to the gtk_box, gtk_box keeps a strong reference to them.

Filename: listings/gobject_memory_management/4/main.rs

use std::{cell::Cell, rc::Rc};

use glib::clone;
use gtk::prelude::*;
use gtk::{self, ApplicationWindow, Button, Orientation};
use gtk::{glib, Application};

fn main() {
    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Connect to "activate" signal of `app`
    app.connect_activate(build_ui);

    // Run the application
    app.run();
}

fn build_ui(app: &Application) {
    // Create two buttons
    let button_increase = Button::builder()
        .label("Increase")
        .margin_top(12)
        .margin_bottom(12)
        .margin_start(12)
        .margin_end(12)
        .build();
    let button_decrease = Button::builder()
        .label("Decrease")
        .margin_top(12)
        .margin_bottom(12)
        .margin_start(12)
        .margin_end(12)
        .build();

    // Reference-counted object with inner mutability
    let number = Rc::new(Cell::new(0));

    // Connect callbacks
    // When a button is clicked, `number` and label of the other button will be changed
    button_increase.connect_clicked(clone!(@weak number, @weak button_decrease =>
        move |_| {
            number.set(number.get() + 1);
            button_decrease.set_label(&number.get().to_string());
    }));
    button_decrease.connect_clicked(clone!(@weak button_increase =>
        move |_| {
            number.set(number.get() - 1);
            button_increase.set_label(&number.get().to_string());
    }));

    // Add buttons to `gtk_box`
    let gtk_box = gtk::Box::builder()
        .orientation(Orientation::Vertical)
        .build();
    gtk_box.append(&button_increase);
    gtk_box.append(&button_decrease);

    // Create a window
    let window = ApplicationWindow::builder()
        .application(app)
        .title("My GTK App")
        .child(&gtk_box)
        .build();

    // Present the window
    window.present();
}

When we set gtk_box as child of window, window keeps a strong reference to it. Until we close the window it keeps gtk_box and with it the buttons alive. Since our application has only one window, closing it also means exiting the application.

As long as you use weak references whenever possible you will find it perfectly doable to avoid memory cycles within your application. If that is ensured, you can rely on GTK to properly manage the memory of GObjects you pass to it.

Subclassing

GObjects rely heavily on inheritance. Therefore, it makes sense that if we want to create a custom GObject, this is done via subclassing. Let us see how this works by replacing the button in our "Hello World!" app with a custom one.

First, we need to create an implementation struct that holds the state and overrides the virtual methods. It is advised to keep it in a private module, since its state and methods are only meant to be used by the GObject itself. It therefore corresponds to the private section of objects in languages like Java and C++.

Filename: listings/gobject_subclassing/1/custom_button/imp.rs

use gtk::glib;
use gtk::subclass::prelude::*;

// Object holding the state
#[derive(Default)]
pub struct CustomButton;

// The central trait for subclassing a GObject
#[glib::object_subclass]
impl ObjectSubclass for CustomButton {
    const NAME: &'static str = "MyGtkAppCustomButton";
    type Type = super::CustomButton;
    type ParentType = gtk::Button;
}

// Trait shared by all GObjects
impl ObjectImpl for CustomButton {}

// Trait shared by all widgets
impl WidgetImpl for CustomButton {}

// Trait shared by all buttons
impl ButtonImpl for CustomButton {}

The description of the subclassing is in ObjectSubclass.

  • NAME should consist of crate-name, module-path and object-name in order to avoid name collisions. Use PascalCase here.
  • Type refers to the actual GObject that will be created afterwards.
  • ParentType is the GObject we inherit of.

After that, we would have the option to override the virtual methods of our ancestors. Since we only want to have a plain button for now, we override nothing. We still have to add the empty impl though. Next, we describe our custom GObject.

Filename: listings/gobject_subclassing/1/custom_button/mod.rs

mod imp;

use glib::Object;
use gtk::glib;

glib::wrapper! {
    pub struct CustomButton(ObjectSubclass<imp::CustomButton>)
        @extends gtk::Button, gtk::Widget,
        @implements gtk::Accessible, gtk::Actionable, gtk::Buildable, gtk::ConstraintTarget;
}

impl CustomButton {
    pub fn new() -> Self {
        Object::new(&[]).expect("Failed to create `CustomButton`.")
    }

    pub fn with_label(label: &str) -> Self {
        Object::new(&[("label", &label)]).expect("Failed to create `CustomButton`.")
    }
}

impl Default for CustomButton {
    fn default() -> Self {
        Self::new()
    }
}

glib::wrapper! does the most of the work of subclassing for us. Coming from most other languages you would probably expect that you only have to mention the base class you want to inherit from. However, as of today, subclassing of GObjects in Rust requires to mention all ancestors and interfaces apart from GObject and GInitiallyUnowned. For gtk::Button, we can look them up in the corresponding doc page of GTK4.

After these steps, nothing is stopping us anymore from replacing gtk::Button with our CustomButton.

Filename: listings/gobject_subclassing/1/main.rs

mod custom_button;

use custom_button::CustomButton;
use gtk::prelude::*;
use gtk::{Application, ApplicationWindow};

fn main() {
    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Connect to "activate" signal of `app`
    app.connect_activate(build_ui);

    // Run the application
    app.run();
}

fn build_ui(app: &Application) {
    // Create a button
    let button = CustomButton::with_label("Press me!");
    button.set_margin_top(12);
    button.set_margin_bottom(12);
    button.set_margin_start(12);
    button.set_margin_end(12);

    // Connect to "clicked" signal of `button`
    button.connect_clicked(move |button| {
        // Set the label to "Hello World!" after the button has been clicked on
        button.set_label("Hello World!");
    });

    // Create a window
    let window = ApplicationWindow::builder()
        .application(app)
        .title("My GTK App")
        .child(&button)
        .build();

    // Present window
    window.present();
}

We are able to use CustomButton as a drop-in replacement for gtk::Button. This is cool, but also not very tempting to do in a real application. For the gain of zero benefits, it did involve quite a bit of boilerplate after all.

So let us make it a bit more interesting! gtk::Button does not hold much state, but we can let CustomButton hold a number.

Filename: listings/gobject_subclassing/2/custom_button/imp.rs

use gtk::glib;
use gtk::prelude::*;
use gtk::subclass::prelude::*;
use std::cell::Cell;

// Object holding the state
#[derive(Default)]
pub struct CustomButton {
    number: Cell<i32>,
}

// The central trait for subclassing a GObject
#[glib::object_subclass]
impl ObjectSubclass for CustomButton {
    const NAME: &'static str = "MyGtkAppCustomButton";
    type Type = super::CustomButton;
    type ParentType = gtk::Button;
}

// Trait shared by all GObjects
impl ObjectImpl for CustomButton {
    fn constructed(&self, obj: &Self::Type) {
        self.parent_constructed(obj);
        obj.set_label(&self.number.get().to_string());
    }
}

// Trait shared by all widgets
impl WidgetImpl for CustomButton {}

// Trait shared by all buttons
impl ButtonImpl for CustomButton {
    fn clicked(&self, button: &Self::Type) {
        self.number.set(self.number.get() + 1);
        button.set_label(&self.number.get().to_string())
    }
}

We override constructed in ObjectImpl so that the label of the button initializes with number. We also override clicked in ButtonImpl so that every click increases number and updates the label.

Filename: listings/gobject_subclassing/2/main.rs

mod custom_button;

use custom_button::CustomButton;
use gtk::prelude::*;
use gtk::{Application, ApplicationWindow};

fn main() {
    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Connect to "activate" signal of `app`
    app.connect_activate(build_ui);

    // Run the application
    app.run();
}

fn build_ui(app: &Application) {
    // Create a button
    let button = CustomButton::new();
    button.set_margin_top(12);
    button.set_margin_bottom(12);
    button.set_margin_start(12);
    button.set_margin_end(12);

    // Create a window
    let window = ApplicationWindow::builder()
        .application(app)
        .title("My GTK App")
        .child(&button)
        .build();

    // Present window
    window.present();
}

In build_ui we stop calling connect_clicked, and that was it. After a rebuild, the app now features our CustomButton with the label "0". Every time we click on the button, the number displayed by the label increases by 1.

So, when do we want to inherit from GObject?

  • We want to use a certain widget, but with added state and overridden virtual functions.
  • We want to pass a Rust object to a function, but the function expects a GObject.
  • We want to add properties or signals to an object.

Generic Values

Some GObject-related functions rely on generic values for their arguments or return parameters. Since GObject introspection works through a C interface, these functions cannot rely on any powerful Rust concepts. In these cases glib::Value or glib::Variant are used.

Value

Let us start with Value. Conceptually, a Value is similar to a Rust enum defined like this:

enum Value <T> {
    bool(bool),
    i8(i8),
    i32(i32),
    u32(u32),
    i64(i64),
    u64(u64),
    f32(f32),
    f64(f64),
    // boxed types
    String(Option<String>),
    Object(Option<dyn IsA<glib::Object>>),
}

For example, this is how you would use a Value representing an i32.

Filename: listings/gobject_values/1/main.rs

use gtk::prelude::*;

fn main() {
    // Store `i32` as `Value`
    let integer_value = 10.to_value();

    // Retrieve `i32` from `Value`
    let integer = integer_value
        .get::<i32>()
        .expect("The value needs to be of type `i32`.");

    // Check if the retrieved value is correct
    assert_eq!(integer, 10);

    // Store string as `Value`
    let string_value = "Hello!".to_value();

    // Retrieve `String` from `Value`
    let string = string_value
        .get::<String>()
        .expect("The value needs to be of type `String`.");

    // Check if the retrieved value is correct
    assert_eq!(string, "Hello!".to_string());

    // Store `Option<String>` as `Value`
    let string_some_value = "Hello!".to_value();
    let string_none_value = None::<String>.to_value();

    // Retrieve `String` from `Value`
    let string_some = string_some_value
        .get::<Option<String>>()
        .expect("The value needs to be of type `String`.");
    let string_none = string_none_value
        .get::<Option<String>>()
        .expect("The value needs to be of type `String`.");

    // Check if the retrieved value is correct
    assert_eq!(string_some, Some("Hello!".to_string()));
    assert_eq!(string_none, None);
}

Also note that in the enum above boxed types such as String or glib::Object are wrapped in an Option. This comes from C, where every boxed type can potentially be None (or NULL in C terms). You can still access it the same way as with the i32 above. get will then not only return Err if you specified the wrong type, but also if the Value represents None.

Filename: listings/gobject_values/1/main.rs

use gtk::prelude::*;

fn main() {
    // Store `i32` as `Value`
    let integer_value = 10.to_value();

    // Retrieve `i32` from `Value`
    let integer = integer_value
        .get::<i32>()
        .expect("The value needs to be of type `i32`.");

    // Check if the retrieved value is correct
    assert_eq!(integer, 10);

    // Store string as `Value`
    let string_value = "Hello!".to_value();

    // Retrieve `String` from `Value`
    let string = string_value
        .get::<String>()
        .expect("The value needs to be of type `String`.");

    // Check if the retrieved value is correct
    assert_eq!(string, "Hello!".to_string());

    // Store `Option<String>` as `Value`
    let string_some_value = "Hello!".to_value();
    let string_none_value = None::<String>.to_value();

    // Retrieve `String` from `Value`
    let string_some = string_some_value
        .get::<Option<String>>()
        .expect("The value needs to be of type `String`.");
    let string_none = string_none_value
        .get::<Option<String>>()
        .expect("The value needs to be of type `String`.");

    // Check if the retrieved value is correct
    assert_eq!(string_some, Some("Hello!".to_string()));
    assert_eq!(string_none, None);
}

If you want to differentiate between specifying the wrong type and a Value representing None, just call get::<Option<T>> instead.

Filename: listings/gobject_values/1/main.rs

use gtk::prelude::*;

fn main() {
    // Store `i32` as `Value`
    let integer_value = 10.to_value();

    // Retrieve `i32` from `Value`
    let integer = integer_value
        .get::<i32>()
        .expect("The value needs to be of type `i32`.");

    // Check if the retrieved value is correct
    assert_eq!(integer, 10);

    // Store string as `Value`
    let string_value = "Hello!".to_value();

    // Retrieve `String` from `Value`
    let string = string_value
        .get::<String>()
        .expect("The value needs to be of type `String`.");

    // Check if the retrieved value is correct
    assert_eq!(string, "Hello!".to_string());

    // Store `Option<String>` as `Value`
    let string_some_value = "Hello!".to_value();
    let string_none_value = None::<String>.to_value();

    // Retrieve `String` from `Value`
    let string_some = string_some_value
        .get::<Option<String>>()
        .expect("The value needs to be of type `String`.");
    let string_none = string_none_value
        .get::<Option<String>>()
        .expect("The value needs to be of type `String`.");

    // Check if the retrieved value is correct
    assert_eq!(string_some, Some("Hello!".to_string()));
    assert_eq!(string_none, None);
}

We will use Value when we deal with properties and signals later on.

Variant

A Variant is used whenever data needs to be serialized, for example for sending it to another process or over the network, or for storing it on disk. In that sense, a Variant is similar to a Rust object that implements serde::Serialize and serde::Deserialize. It would be possible to add derive macros similar to the ones of serde for serializing/deserializing arbitrary Rust structs. It is just that nobody did the work yet. Pull requests to add this functionality would be very appreciated!

Although GVariant supports arbitrarily complex types, the Rust bindings are currently limited to bool, u8, i16, u16, i32, u32, i64, u64, f64, &str/String, and VariantDict. Containers of the above types are possible as well, such as HashMap, Vec, Option, tuples up to 16 elements, and Variant. These can even be arbitrarily nested like e.g. HashMap<Option<u32>, Vec<HashMap<String, Variant>>>.

In the most simple case, converting Rust types to Variant and vice-versa is very similar to the way it worked with Value.

Filename: listings/gobject_values/2/main.rs

use gtk::prelude::*;

fn main() {
    // Store `i32` as `Variant`
    let integer_variant = 10.to_variant();

    // Retrieve `i32` from `Variant`
    let integer = integer_variant
        .get::<i32>()
        .expect("The variant needs to be of type `i32`.");

    // Check if the retrieved value is correct
    assert_eq!(integer, 10);

    let variant = vec!["Hello", "there!"].to_variant();
    assert_eq!(variant.n_children(), 2);
    let vec = &variant
        .get::<Vec<String>>()
        .expect("The variant needs to be of type `String`.");
    assert_eq!(vec[0], "Hello");
}

However, a Variant is also able to represent containers such as HashMap or Vec. The following snippet shows how to convert between Vec and Variant. More examples can be found in the docs.

Filename: listings/gobject_values/2/main.rs

use gtk::prelude::*;

fn main() {
    // Store `i32` as `Variant`
    let integer_variant = 10.to_variant();

    // Retrieve `i32` from `Variant`
    let integer = integer_variant
        .get::<i32>()
        .expect("The variant needs to be of type `i32`.");

    // Check if the retrieved value is correct
    assert_eq!(integer, 10);

    let variant = vec!["Hello", "there!"].to_variant();
    assert_eq!(variant.n_children(), 2);
    let vec = &variant
        .get::<Vec<String>>()
        .expect("The variant needs to be of type `String`.");
    assert_eq!(vec[0], "Hello");
}

We will use Variant when saving settings using gio::Settings or activating actions via gio::Action.

Properties

Properties provide a public API for accessing state of GObjects.

Let us see how this is done by experimenting with the Switch widget. One of its properties is the state. According to the GTK docs, it can be read and be written to. That is why gtk-rs provides corresponding state and set_state methods.

Filename: listings/gobject_properties/1/main.rs

use gtk::prelude::*;
use gtk::{Align, Box, Orientation, Switch};
use gtk::{Application, ApplicationWindow};

fn main() {
    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Connect to "activate" signal of `app`
    app.connect_activate(build_ui);

    // Run the application
    app.run();
}

fn build_ui(app: &Application) {
    // Create the switch
    let switch = Switch::new();

    // Set and then immediately obtain state
    switch.set_state(true);
    let current_state = switch.state();

    // This prints: "The current state is true"
    println!("The current state is {}", current_state);

    // Set up box
    let gtk_box = Box::builder()
        .margin_top(12)
        .margin_bottom(12)
        .margin_start(12)
        .margin_end(12)
        .valign(Align::Center)
        .halign(Align::Center)
        .spacing(12)
        .orientation(Orientation::Vertical)
        .build();
    gtk_box.append(&switch);

    // Create a window
    let window = ApplicationWindow::builder()
        .application(app)
        .title("My GTK App")
        .child(&gtk_box)
        .build();

    // Present the window
    window.present();
}

Alternatively, we can use the general property and set_property methods. We use the turbofish syntax to specify the type if it cannot be inferred.

Filename: listings/gobject_properties/2/main.rs

use gtk::prelude::*;
use gtk::{Align, Box, Orientation, Switch};
use gtk::{Application, ApplicationWindow};

fn main() {
    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Connect to "activate" signal of `app`
    app.connect_activate(build_ui);

    // Run the application
    app.run();
}

fn build_ui(app: &Application) {
    // Create the switch
    let switch = Switch::new();

    // Set and then immediately obtain state
    switch.set_property("state", &true);
    let current_state = switch.property::<bool>("state");

    // This prints: "The current state is true"
    println!("The current state is {}", current_state);

    // Set up box
    let gtk_box = Box::builder()
        .margin_top(12)
        .margin_bottom(12)
        .margin_start(12)
        .margin_end(12)
        .valign(Align::Center)
        .halign(Align::Center)
        .spacing(12)
        .orientation(Orientation::Vertical)
        .build();
    gtk_box.append(&switch);

    // Create a window
    let window = ApplicationWindow::builder()
        .application(app)
        .title("My GTK App")
        .child(&gtk_box)
        .build();

    // Present the window
    window.present();
}

Both property and set_property panic if the property does not exist, has the wrong type or has the wrong permissions. This is fine in most situations where these cases are hardcoded within the program. If this does not apply for your program you might want to use try_property and try_set_property instead.

Properties can not only be accessed via getters & setters, they can also be bound to each other. Let us see how that would look like for two Switch instances.

Filename: listings/gobject_properties/3/main.rs

use glib::BindingFlags;
use gtk::{glib, Align, Orientation, Switch};
use gtk::{prelude::*, Box};
use gtk::{Application, ApplicationWindow};

fn main() {
    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Connect to "activate" signal of `app`
    app.connect_activate(build_ui);

    // Run the application
    app.run();
}

fn build_ui(app: &Application) {
    // Create the switches
    let switch_1 = Switch::new();
    let switch_2 = Switch::new();

    switch_1
        .bind_property("state", &switch_2, "state")
        .flags(BindingFlags::BIDIRECTIONAL)
        .build();

    // Set up box
    let gtk_box = Box::builder()
        .margin_top(12)
        .margin_bottom(12)
        .margin_start(12)
        .margin_end(12)
        .valign(Align::Center)
        .halign(Align::Center)
        .spacing(12)
        .orientation(Orientation::Vertical)
        .build();
    gtk_box.append(&switch_1);
    gtk_box.append(&switch_2);

    // Create a window
    let window = ApplicationWindow::builder()
        .application(app)
        .title("My GTK App")
        .child(&gtk_box)
        .build();

    // Present the window
    window.present();
}

In our case, we want to bind the "state" property of switch_1 to the "state" property of switch_2. We also want the binding to be bidirectional, so we specify this with the BindingFlags.

Filename: listings/gobject_properties/3/main.rs

use glib::BindingFlags;
use gtk::{glib, Align, Orientation, Switch};
use gtk::{prelude::*, Box};
use gtk::{Application, ApplicationWindow};

fn main() {
    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Connect to "activate" signal of `app`
    app.connect_activate(build_ui);

    // Run the application
    app.run();
}

fn build_ui(app: &Application) {
    // Create the switches
    let switch_1 = Switch::new();
    let switch_2 = Switch::new();

    switch_1
        .bind_property("state", &switch_2, "state")
        .flags(BindingFlags::BIDIRECTIONAL)
        .build();

    // Set up box
    let gtk_box = Box::builder()
        .margin_top(12)
        .margin_bottom(12)
        .margin_start(12)
        .margin_end(12)
        .valign(Align::Center)
        .halign(Align::Center)
        .spacing(12)
        .orientation(Orientation::Vertical)
        .build();
    gtk_box.append(&switch_1);
    gtk_box.append(&switch_2);

    // Create a window
    let window = ApplicationWindow::builder()
        .application(app)
        .title("My GTK App")
        .child(&gtk_box)
        .build();

    // Present the window
    window.present();
}

Now when we click on one of the two switches, the other one is toggled as well.

Adding Properties to Custom GObjects

We can also add properties to custom GObjects. We can demonstrate that by binding the number of our CustomButton to a property. For that we need to be able to lazily evaluate expressions. The crate once_cell provides the Lazy type which allows us to do that. once_cell is already part of Rust nightly. Until it hits stable, we will add it as external dependency.

Filename: listings/Cargo.toml

[dependencies]
once_cell = "1"

Now we define the "number" property within the ObjectImpl implementation. The properties method describes our set of properties. When naming our property, we make sure to do that in kebab-case. Then we describe its type, range and default value. We also declare that the property can be read and be written to. set_property describes how the underlying values can be changed. property takes care of returning the underlying value. The formerly private number is now accessible via the property and set_property methods.

Filename: listings/gobject_properties/4/custom_button/imp.rs

use glib::{BindingFlags, ParamFlags, ParamSpec, ParamSpecInt, Value};
use gtk::glib;
use gtk::prelude::*;
use gtk::subclass::prelude::*;
use once_cell::sync::Lazy;

use std::cell::Cell;

// Object holding the state
#[derive(Default)]
pub struct CustomButton {
    number: Cell<i32>,
}

// The central trait for subclassing a GObject
#[glib::object_subclass]
impl ObjectSubclass for CustomButton {
    const NAME: &'static str = "MyGtkAppCustomButton";
    type Type = super::CustomButton;
    type ParentType = gtk::Button;
}

// Trait shared by all GObjects
impl ObjectImpl for CustomButton {
    fn properties() -> &'static [ParamSpec] {
        static PROPERTIES: Lazy<Vec<ParamSpec>> = Lazy::new(|| {
            vec![ParamSpecInt::new(
                // Name
                "number",
                // Nickname
                "number",
                // Short description
                "number",
                // Minimum value
                i32::MIN,
                // Maximum value
                i32::MAX,
                // Default value
                0,
                // The property can be read and written to
                ParamFlags::READWRITE,
            )]
        });
        PROPERTIES.as_ref()
    }

    fn set_property(&self, _obj: &Self::Type, _id: usize, value: &Value, pspec: &ParamSpec) {
        match pspec.name() {
            "number" => {
                let input_number = value.get().expect("The value needs to be of type `i32`.");
                self.number.replace(input_number);
            }
            _ => unimplemented!(),
        }
    }

    fn property(&self, _obj: &Self::Type, _id: usize, pspec: &ParamSpec) -> Value {
        match pspec.name() {
            "number" => self.number.get().to_value(),
            _ => unimplemented!(),
        }
    }

    fn constructed(&self, obj: &Self::Type) {
        self.parent_constructed(obj);

        // Bind label to number
        // `SYNC_CREATE` ensures that the label will be immediately set
        obj.bind_property("number", obj, "label")
            .flags(BindingFlags::SYNC_CREATE)
            .build();
    }
}

// Trait shared by all widgets
impl WidgetImpl for CustomButton {}

// Trait shared by all buttons
impl ButtonImpl for CustomButton {
    fn clicked(&self, button: &Self::Type) {
        let incremented_number = self.number.get() + 1;
        button.set_property("number", &incremented_number);
    }
}

We can immediately take advantage of this new property by binding the "label" property to it. It even converts the integer value of "number" to the string of "label". Now we do not have to adapt the label in the "clicked" callback anymore.

Let us see what we can do with this by creating two custom buttons.

Filename: listings/gobject_properties/4/main.rs

mod custom_button;

use custom_button::CustomButton;
use glib::BindingFlags;
use gtk::{glib, Align, Orientation};
use gtk::{prelude::*, Box};
use gtk::{Application, ApplicationWindow};

fn main() {
    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Connect to "activate" signal of `app`
    app.connect_activate(build_ui);

    // Run the application
    app.run();
}

fn build_ui(app: &Application) {
    // Create the buttons
    let button_1 = CustomButton::new();
    let button_2 = CustomButton::new();

    // Assure that "number" of `button_2` is always 1 higher than "number" of `button_1`
    button_1
        .bind_property("number", &button_2, "number")
        // How to transform "number" from `button_1` to "number" of `button_2`
        .transform_to(|_, value| {
            let number = value
                .get::<i32>()
                .expect("The property needs to be of type `i32`.");
            let incremented_number = number + 1;
            Some(incremented_number.to_value())
        })
        // How to transform "number" from `button_2` to "number" of `button_1`
        .transform_from(|_, value| {
            let number = value
                .get::<i32>()
                .expect("The property needs to be of type `i32`.");
            let decremented_number = number - 1;
            Some(decremented_number.to_value())
        })
        .flags(BindingFlags::BIDIRECTIONAL | BindingFlags::SYNC_CREATE)
        .build();

    // The closure will be called
    // whenever the property "number" of `button_1` gets changed
    button_1.connect_notify_local(Some("number"), move |button, _| {
        let number = button.property::<i32>("number");
        println!("The current number of `button_1` is {}.", number);
    });

    // Set up box
    let gtk_box = Box::builder()
        .margin_top(12)
        .margin_bottom(12)
        .margin_start(12)
        .margin_end(12)
        .valign(Align::Center)
        .halign(Align::Center)
        .spacing(12)
        .orientation(Orientation::Vertical)
        .build();
    gtk_box.append(&button_1);
    gtk_box.append(&button_2);

    // Create a window
    let window = ApplicationWindow::builder()
        .application(app)
        .title("My GTK App")
        .child(&gtk_box)
        .build();

    // Present the window
    window.present();
}

We have already seen that bound properties do not necessarily have to be of the same type. By leveraging transform_to and transform_from, we can assure that button_2 always displays a number which is 1 higher than the number of button_1.

Filename: listings/gobject_properties/4/main.rs

mod custom_button;

use custom_button::CustomButton;
use glib::BindingFlags;
use gtk::{glib, Align, Orientation};
use gtk::{prelude::*, Box};
use gtk::{Application, ApplicationWindow};

fn main() {
    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Connect to "activate" signal of `app`
    app.connect_activate(build_ui);

    // Run the application
    app.run();
}

fn build_ui(app: &Application) {
    // Create the buttons
    let button_1 = CustomButton::new();
    let button_2 = CustomButton::new();

    // Assure that "number" of `button_2` is always 1 higher than "number" of `button_1`
    button_1
        .bind_property("number", &button_2, "number")
        // How to transform "number" from `button_1` to "number" of `button_2`
        .transform_to(|_, value| {
            let number = value
                .get::<i32>()
                .expect("The property needs to be of type `i32`.");
            let incremented_number = number + 1;
            Some(incremented_number.to_value())
        })
        // How to transform "number" from `button_2` to "number" of `button_1`
        .transform_from(|_, value| {
            let number = value
                .get::<i32>()
                .expect("The property needs to be of type `i32`.");
            let decremented_number = number - 1;
            Some(decremented_number.to_value())
        })
        .flags(BindingFlags::BIDIRECTIONAL | BindingFlags::SYNC_CREATE)
        .build();

    // The closure will be called
    // whenever the property "number" of `button_1` gets changed
    button_1.connect_notify_local(Some("number"), move |button, _| {
        let number = button.property::<i32>("number");
        println!("The current number of `button_1` is {}.", number);
    });

    // Set up box
    let gtk_box = Box::builder()
        .margin_top(12)
        .margin_bottom(12)
        .margin_start(12)
        .margin_end(12)
        .valign(Align::Center)
        .halign(Align::Center)
        .spacing(12)
        .orientation(Orientation::Vertical)
        .build();
    gtk_box.append(&button_1);
    gtk_box.append(&button_2);

    // Create a window
    let window = ApplicationWindow::builder()
        .application(app)
        .title("My GTK App")
        .child(&gtk_box)
        .build();

    // Present the window
    window.present();
}

Now if we click on one button, the "number" and "label" properties of the other button change as well.

The final nice feature of properties is, that you can connect a callback to the event when a property gets changed. We can do this like this:

Filename: listings/gobject_properties/4/main.rs

mod custom_button;

use custom_button::CustomButton;
use glib::BindingFlags;
use gtk::{glib, Align, Orientation};
use gtk::{prelude::*, Box};
use gtk::{Application, ApplicationWindow};

fn main() {
    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Connect to "activate" signal of `app`
    app.connect_activate(build_ui);

    // Run the application
    app.run();
}

fn build_ui(app: &Application) {
    // Create the buttons
    let button_1 = CustomButton::new();
    let button_2 = CustomButton::new();

    // Assure that "number" of `button_2` is always 1 higher than "number" of `button_1`
    button_1
        .bind_property("number", &button_2, "number")
        // How to transform "number" from `button_1` to "number" of `button_2`
        .transform_to(|_, value| {
            let number = value
                .get::<i32>()
                .expect("The property needs to be of type `i32`.");
            let incremented_number = number + 1;
            Some(incremented_number.to_value())
        })
        // How to transform "number" from `button_2` to "number" of `button_1`
        .transform_from(|_, value| {
            let number = value
                .get::<i32>()
                .expect("The property needs to be of type `i32`.");
            let decremented_number = number - 1;
            Some(decremented_number.to_value())
        })
        .flags(BindingFlags::BIDIRECTIONAL | BindingFlags::SYNC_CREATE)
        .build();

    // The closure will be called
    // whenever the property "number" of `button_1` gets changed
    button_1.connect_notify_local(Some("number"), move |button, _| {
        let number = button.property::<i32>("number");
        println!("The current number of `button_1` is {}.", number);
    });

    // Set up box
    let gtk_box = Box::builder()
        .margin_top(12)
        .margin_bottom(12)
        .margin_start(12)
        .margin_end(12)
        .valign(Align::Center)
        .halign(Align::Center)
        .spacing(12)
        .orientation(Orientation::Vertical)
        .build();
    gtk_box.append(&button_1);
    gtk_box.append(&button_2);

    // Create a window
    let window = ApplicationWindow::builder()
        .application(app)
        .title("My GTK App")
        .child(&gtk_box)
        .build();

    // Present the window
    window.present();
}

Now, whenever the "number" property gets changed, the closure gets executed and prints the current value of "number".

Introducing properties to your custom GObjects is useful if you want to

  • allow consumers to be able to access internal state
  • bind state of (different) GObjects
  • notify consumers whenever a property value changes

Signals

GObject signals are a system for registering callbacks for specific events. For example, if we press on a button, the "clicked" signal will be emitted. The signal then takes care that all the registered callbacks will be executed.

gtk-rs provides convenience methods for registering callbacks. In our "Hello World" example we connected the "clicked" signal to a closure which sets the label of the button to "Hello World" as soon as it gets called.

Filename: listings/gobject_signals/1/main.rs

use gtk::prelude::*;
use gtk::{Application, ApplicationWindow, Button};

fn main() {
    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Connect to "activate" signal of `app`
    app.connect_activate(build_ui);

    // Run the application
    app.run();
}

fn build_ui(app: &Application) {
    // Create a button
    let button = Button::builder()
        .label("Press me!")
        .margin_top(12)
        .margin_bottom(12)
        .margin_start(12)
        .margin_end(12)
        .build();

    // Connect to "clicked" signal of `button`
    button.connect_clicked(move |button| {
        // Set the label to "Hello World!" after the button has been clicked on
        button.set_label("Hello World!");
    });

    // Create a window
    let window = ApplicationWindow::builder()
        .application(app)
        .title("My GTK App")
        .child(&button)
        .build();

    // Present the window
    window.present();
}

If we wanted to, we could have connected to it with the generic connect_local method.

Filename: listings/gobject_signals/2/main.rs

use gtk::prelude::*;
use gtk::{Application, ApplicationWindow, Button};

fn main() {
    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Connect to "activate" signal of `app`
    app.connect_activate(build_ui);

    // Run the application
    app.run();
}

fn build_ui(app: &Application) {
    // Create a button
    let button = Button::builder()
        .label("Press me!")
        .margin_top(12)
        .margin_bottom(12)
        .margin_start(12)
        .margin_end(12)
        .build();

    // Connect callback
    button.connect_local("clicked", false, move |args| {
        // Get the button from the arguments
        let button = args[0]
            .get::<Button>()
            .expect("The value needs to be of type `Button`.");
        // Set the label to "Hello World!" after the button has been clicked on
        button.set_label("Hello World!");
        None
    });

    // Create a window
    let window = ApplicationWindow::builder()
        .application(app)
        .title("My GTK App")
        .child(&button)
        .build();

    // Present window
    window.present();
}

Similar to the generic way of accessing properties, the advantage of connect_local is that it also works with custom signals.

If you want to connect from a different thread than the main thread, make sure to use connect instead of connect_local. However, that also means that your connected closure has to implement Send + Sync.

Adding Signals to Custom GObjects

Let us see how we can create our own signals. Again we do that by extending our CustomButton. First we override the necessary methods in ObjectImpl.

Filename: listings/gobject_signals/3/custom_button/imp.rs

use glib::subclass::Signal;
use glib::{BindingFlags, ParamFlags, ParamSpec, ParamSpecInt, Value};
use gtk::glib;
use gtk::prelude::*;
use gtk::subclass::prelude::*;

use once_cell::sync::Lazy;
use std::cell::Cell;

// Object holding the state
#[derive(Default)]
pub struct CustomButton {
    number: Cell<i32>,
}

// The central trait for subclassing a GObject
#[glib::object_subclass]
impl ObjectSubclass for CustomButton {
    const NAME: &'static str = "MyGtkAppCustomButton";
    type Type = super::CustomButton;
    type ParentType = gtk::Button;
}

// Trait shared by all GObjects
impl ObjectImpl for CustomButton {
    fn signals() -> &'static [Signal] {
        static SIGNALS: Lazy<Vec<Signal>> = Lazy::new(|| {
            vec![Signal::builder(
                // Signal name
                "max-number-reached",
                // Types of the values which will be sent to the signal handler
                &[i32::static_type().into()],
                // Type of the value the signal handler sends back
                <()>::static_type().into(),
            )
            .build()]
        });
        SIGNALS.as_ref()
    }

    fn properties() -> &'static [ParamSpec] {
        static PROPERTIES: Lazy<Vec<ParamSpec>> = Lazy::new(|| {
            vec![ParamSpecInt::new(
                // Name
                "number",
                // Nickname
                "number",
                // Short description
                "number",
                // Minimum value
                i32::MIN,
                // Maximum value
                i32::MAX,
                // Default value
                0,
                // The property can be read and written to
                ParamFlags::READWRITE,
            )]
        });
        PROPERTIES.as_ref()
    }

    fn set_property(&self, _obj: &Self::Type, _id: usize, value: &Value, pspec: &ParamSpec) {
        match pspec.name() {
            "number" => {
                let input_number = value.get().expect("The value needs to be of type `i32`.");
                self.number.replace(input_number);
            }
            _ => unimplemented!(),
        }
    }

    fn property(&self, _obj: &Self::Type, _id: usize, pspec: &ParamSpec) -> Value {
        match pspec.name() {
            "number" => self.number.get().to_value(),
            _ => unimplemented!(),
        }
    }

    fn constructed(&self, obj: &Self::Type) {
        self.parent_constructed(obj);

        // Bind label to number
        // `SYNC_CREATE` ensures that the label will be immediately set
        obj.bind_property("number", obj, "label")
            .flags(BindingFlags::SYNC_CREATE)
            .build();
    }
}

// Trait shared by all widgets
impl WidgetImpl for CustomButton {}

static MAX_NUMBER: i32 = 8;

// Trait shared by all buttons
impl ButtonImpl for CustomButton {
    fn clicked(&self, button: &Self::Type) {
        let incremented_number = self.number.get() + 1;
        // If `number` reached `MAX_NUMBER`,
        // emit "max-number-reached" signal and set `number` back to 0
        if incremented_number == MAX_NUMBER {
            button.emit_by_name::<()>("max-number-reached", &[&incremented_number]);
            button.set_property("number", &0);
        } else {
            button.set_property("number", &incremented_number);
        }
    }
}

The signals method is responsible for defining a set of signals. In our case, we only create a single signal named "max-number-reached". When naming our signal, we make sure to do that in kebab-case. When emitted, it sends a single i32 value and expects nothing in return.

We want the signal to be emitted, whenever number reaches MAX_NUMBER. Together with the signal we send the value number currently holds. After we did that, we set number back to 0.

Filename: listings/gobject_signals/3/custom_button/imp.rs

use glib::subclass::Signal;
use glib::{BindingFlags, ParamFlags, ParamSpec, ParamSpecInt, Value};
use gtk::glib;
use gtk::prelude::*;
use gtk::subclass::prelude::*;

use once_cell::sync::Lazy;
use std::cell::Cell;

// Object holding the state
#[derive(Default)]
pub struct CustomButton {
    number: Cell<i32>,
}

// The central trait for subclassing a GObject
#[glib::object_subclass]
impl ObjectSubclass for CustomButton {
    const NAME: &'static str = "MyGtkAppCustomButton";
    type Type = super::CustomButton;
    type ParentType = gtk::Button;
}

// Trait shared by all GObjects
impl ObjectImpl for CustomButton {
    fn signals() -> &'static [Signal] {
        static SIGNALS: Lazy<Vec<Signal>> = Lazy::new(|| {
            vec![Signal::builder(
                // Signal name
                "max-number-reached",
                // Types of the values which will be sent to the signal handler
                &[i32::static_type().into()],
                // Type of the value the signal handler sends back
                <()>::static_type().into(),
            )
            .build()]
        });
        SIGNALS.as_ref()
    }

    fn properties() -> &'static [ParamSpec] {
        static PROPERTIES: Lazy<Vec<ParamSpec>> = Lazy::new(|| {
            vec![ParamSpecInt::new(
                // Name
                "number",
                // Nickname
                "number",
                // Short description
                "number",
                // Minimum value
                i32::MIN,
                // Maximum value
                i32::MAX,
                // Default value
                0,
                // The property can be read and written to
                ParamFlags::READWRITE,
            )]
        });
        PROPERTIES.as_ref()
    }

    fn set_property(&self, _obj: &Self::Type, _id: usize, value: &Value, pspec: &ParamSpec) {
        match pspec.name() {
            "number" => {
                let input_number = value.get().expect("The value needs to be of type `i32`.");
                self.number.replace(input_number);
            }
            _ => unimplemented!(),
        }
    }

    fn property(&self, _obj: &Self::Type, _id: usize, pspec: &ParamSpec) -> Value {
        match pspec.name() {
            "number" => self.number.get().to_value(),
            _ => unimplemented!(),
        }
    }

    fn constructed(&self, obj: &Self::Type) {
        self.parent_constructed(obj);

        // Bind label to number
        // `SYNC_CREATE` ensures that the label will be immediately set
        obj.bind_property("number", obj, "label")
            .flags(BindingFlags::SYNC_CREATE)
            .build();
    }
}

// Trait shared by all widgets
impl WidgetImpl for CustomButton {}

static MAX_NUMBER: i32 = 8;

// Trait shared by all buttons
impl ButtonImpl for CustomButton {
    fn clicked(&self, button: &Self::Type) {
        let incremented_number = self.number.get() + 1;
        // If `number` reached `MAX_NUMBER`,
        // emit "max-number-reached" signal and set `number` back to 0
        if incremented_number == MAX_NUMBER {
            button.emit_by_name::<()>("max-number-reached", &[&incremented_number]);
            button.set_property("number", &0);
        } else {
            button.set_property("number", &incremented_number);
        }
    }
}

If we now press on the button, the number of its label increases until it reaches MAX_NUMBER. Then it emits the "max-number-reached" signal which we can nicely connect to. Whenever we now receive the "max-number-reached" signal, the accompanying number is printed to standard output.

Filename: listings/gobject_signals/3/main.rs

mod custom_button;

use custom_button::CustomButton;
use gtk::prelude::*;
use gtk::{Application, ApplicationWindow};

fn main() {
    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Connect to "activate" signal of `app`
    app.connect_activate(build_ui);

    // Run the application
    app.run();
}
fn build_ui(app: &Application) {
    // Create a button
    let button = CustomButton::new();
    button.set_margin_top(12);
    button.set_margin_bottom(12);
    button.set_margin_start(12);
    button.set_margin_end(12);

    button.connect_local("max-number-reached", false, move |args| {
        // Get the number from the arguments
        // args[0] would return the `CustomButton` instance
        let number = args[1]
            .get::<i32>()
            .expect("The value needs to be of type `i32`.");
        println!("The maximum number {} has been reached", number);
        None
    });

    // Create a window
    let window = ApplicationWindow::builder()
        .application(app)
        .title("My GTK App")
        .child(&button)
        .build();

    // Present window
    window.present();
}

You now know how to connect to every kind of signal and how to create your own. Custom signals are especially useful, if you want to notify consumers of your GObject that a certain event occurred.

The Main Event Loop

We now got comfortable using callbacks, but how do they actually work? All of this happens asynchronously, so there must be something managing the events and scheduling the responses. Unsurprisingly, this is called the main event loop.

The main loop manages all kinds of events — from mouse clicks and keyboard presses to file events. It does all of that within the same thread. Quickly iterating between all tasks gives the illusion of parallelism. That is why you can move the window at the same time as a progress bar is growing.

However, you surely saw GUIs that became unresponsive, at least for a few seconds. That happens when a single task takes too long. Let us look at one example.

Filename: listings/main_event_loop/1/main.rs

use std::time::Duration;

use gtk::prelude::*;
use gtk::{self, Application, ApplicationWindow, Button};

fn main() {
    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Connect to "activate" signal of `app`
    app.connect_activate(build_ui);

    // Run the application
    app.run();
}

fn build_ui(app: &Application) {
    // Create a button
    let button = Button::builder()
        .label("Press me!")
        .margin_top(12)
        .margin_bottom(12)
        .margin_start(12)
        .margin_end(12)
        .build();

    // Connect to "clicked" signal of `button`
    button.connect_clicked(move |_| {
        // GUI is blocked for 5 seconds after the button is pressed
        let five_seconds = Duration::from_secs(5);
        std::thread::sleep(five_seconds);
    });

    // Create a window
    let window = ApplicationWindow::builder()
        .application(app)
        .title("My GTK App")
        .child(&button)
        .build();

    // Present window
    window.present();
}

After we press the button, the GUI is completely frozen for five seconds. We can't even move the window. The sleep call is an artificial example, but it is not unusual wanting to run a slightly longer operation in one go.

How to Avoid Blocking the Main Loop

In order to avoid blocking the main loop we can spawn a new thread and let the operation run there.

Filename: listings/main_event_loop/2/main.rs

use std::{thread, time::Duration};

use gtk::prelude::*;
use gtk::{self, Application, ApplicationWindow, Button};

fn main() {
    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Connect to "activate" signal of `app`
    app.connect_activate(build_ui);

    // Run the application
    app.run();
}

fn build_ui(app: &Application) {
    // Create a button
    let button = Button::builder()
        .label("Press me!")
        .margin_top(12)
        .margin_bottom(12)
        .margin_start(12)
        .margin_end(12)
        .build();

    // Connect to "clicked" signal of `button`
    button.connect_clicked(move |_| {
        // The long running operation runs now in a separate thread
        thread::spawn(move || {
            let five_seconds = Duration::from_secs(5);
            thread::sleep(five_seconds);
        });
    });

    // Create a window
    let window = ApplicationWindow::builder()
        .application(app)
        .title("My GTK App")
        .child(&button)
        .build();

    // Present window
    window.present();
}

If you come from another language than Rust, you might be uncomfortable with the thought of spawning new threads before even looking at other options. Luckily, Rust's safety guarantees allow you to stop worrying about the nasty bugs that concurrency tends to bring.

Normally we want to keep track of the work in the thread. In our case, we don't want the user to spawn additional threads while an existing one is still running. In order to achieve that we can create a channel. The main loop allows us to send a message from multiple places to a single receiver at the main thread. We want to send a bool to inform, whether we want the button to react to clicks or not.

Filename: listings/main_event_loop/3/main.rs

use std::{thread, time::Duration};

use glib::{clone, Continue, MainContext, PRIORITY_DEFAULT};
use gtk::glib;
use gtk::prelude::*;
use gtk::{Application, ApplicationWindow, Button};

fn main() {
    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Connect to "activate" signal of `app`
    app.connect_activate(build_ui);

    // Run the application
    app.run();
}

fn build_ui(app: &Application) {
    // Create a button
    let button = Button::builder()
        .label("Press me!")
        .margin_top(12)
        .margin_bottom(12)
        .margin_start(12)
        .margin_end(12)
        .build();

    let (sender, receiver) = MainContext::channel(PRIORITY_DEFAULT);
    // Connect to "clicked" signal of `button`
    button.connect_clicked(move |_| {
        let sender = sender.clone();
        // The long running operation runs now in a separate thread
        thread::spawn(move || {
            // Deactivate the button until the operation is done
            sender.send(false).expect("Could not send through channel");
            let ten_seconds = Duration::from_secs(10);
            thread::sleep(ten_seconds);
            // Activate the button again
            sender.send(true).expect("Could not send through channel");
        });
    });

    // The main loop executes the closure as soon as it receives the message
    receiver.attach(
        None,
        clone!(@weak button => @default-return Continue(false),
                    move |enable_button| {
                        button.set_sensitive(enable_button);
                        Continue(true)
                    }
        ),
    );

    // Create a window
    let window = ApplicationWindow::builder()
        .application(app)
        .title("My GTK App")
        .child(&button)
        .build();

    // Present window
    window.present();
}

Spawning threads is not the only way to run operations asynchronously. You can also let the main loop take care of running async functions. If you do that from the main thread use spawn_local, from other threads spawn has to be used. The converted code looks and behaves very similar to the multi-threaded code.

Filename: listings/main_event_loop/4/main.rs

use glib::{clone, timeout_future_seconds, Continue, MainContext, PRIORITY_DEFAULT};
use gtk::glib;
use gtk::prelude::*;
use gtk::{Application, ApplicationWindow, Button};

fn main() {
    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Connect to "activate" signal of `app`
    app.connect_activate(build_ui);

    // Run the application
    app.run();
}

fn build_ui(app: &Application) {
    // Create a button
    let button = Button::builder()
        .label("Press me!")
        .margin_top(12)
        .margin_bottom(12)
        .margin_start(12)
        .margin_end(12)
        .build();

    let (sender, receiver) = MainContext::channel(PRIORITY_DEFAULT);
    // Connect to "clicked" signal of `button`
    button.connect_clicked(move |_| {
        let main_context = MainContext::default();
        // The main loop executes the asynchronous block
        main_context.spawn_local(clone!(@strong sender => async move {
            // Deactivate the button until the operation is done
            sender.send(false).expect("Could not send through channel");
            timeout_future_seconds(5).await;
            // Activate the button again
            sender.send(true).expect("Could not send through channel");
        }));
    });

    // The main loop executes the closure as soon as it receives the message
    receiver.attach(
        None,
        clone!(@weak button => @default-return Continue(false),
                    move |enable_button| {
                        button.set_sensitive(enable_button);
                        Continue(true)
                    }
        ),
    );

    // Create a window
    let window = ApplicationWindow::builder()
        .application(app)
        .title("My GTK App")
        .child(&button)
        .build();

    // Present window
    window.present();
}

Since we are single-threaded again, we could even get rid of the channels while achieving the same result.

Filename: listings/main_event_loop/5/main.rs

use glib::{clone, timeout_future_seconds, MainContext};
use gtk::glib;
use gtk::prelude::*;
use gtk::{Application, ApplicationWindow, Button};

fn main() {
    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Connect to "activate" signal of `app`
    app.connect_activate(build_ui);

    // Run the application
    app.run();
}

fn build_ui(app: &Application) {
    // Create a button
    let button = Button::builder()
        .label("Press me!")
        .margin_top(12)
        .margin_bottom(12)
        .margin_start(12)
        .margin_end(12)
        .build();

    // Connect to "clicked" signal of `button`
    button.connect_clicked(move |button| {
        let main_context = MainContext::default();
        // The main loop executes the asynchronous block
        main_context.spawn_local(clone!(@weak button => async move {
            // Deactivate the button until the operation is done
            button.set_sensitive(false);
            timeout_future_seconds(5).await;
            // Activate the button again
            button.set_sensitive(true);
        }));
    });

    // Create a window
    let window = ApplicationWindow::builder()
        .application(app)
        .title("My GTK App")
        .child(&button)
        .build();

    // Present window
    window.present();
}

But why did we not do the same thing with our multi-threaded example?

use std::{thread, time::Duration};

use glib::{clone, MainContext, PRIORITY_DEFAULT};
use gtk::glib;
use gtk::prelude::*;
use gtk::{Application, ApplicationWindow, Button};

fn main() {
    // Create a new application
    let app = Application::builder()
       .application_id("org.gtk-rs.example")
       .build();

    // Connect to "activate" signal
    app.connect_activate(build_ui);

    // Get command-line arguments
    let args: Vec<String> = args().collect();
    // Run the application
    app.run(&args);
}

// When the application is launched…
fn build_ui(application: &Application) {
    // Create a window
    let window = ApplicationWindow::builder()
        .application(application)
        .title("My GTK App")
        .build();

    // Create a button
    let button = Button::builder()
        .label("Press me!")
        .margin_top(12)
        .margin_bottom(12)
        .margin_start(12)
        .margin_end(12)
        .build();

    // DOES NOT COMPILE

    // Connect to "clicked" signal of `button`
    button.connect_clicked(move |button| {
        button.clone();
        // The long running operation runs now in a separate thread
        thread::spawn(move || {
            // Deactivate the button until the operation is done
            button.set_sensitive(false);
            let five_seconds = Duration::from_secs(5);
            thread::sleep(five_seconds);
            // Activate the button again
            button.set_sensitive(true);
        });
    });

    // Add button
    window.set_child(Some(&button));
    window.present();
}

Simply because we would get this error message:

error[E0277]: `NonNull<GObject>` cannot be shared between threads safely

help: within `gtk4::Button`, the trait `Sync` is not implemented for `NonNull<GObject>`

After reference cycles we found the second disadvantage of GTK GObjects: They are not thread safe.

So when should you spawn an async block and when should you spawn a thread?

  • If you have async functions for your IO-bound operations at your disposal, feel free to spawn them on the main loop.
  • If your operation is computation-bound or there is no async function available, you have to spawn threads.

Settings

We have now learned multiple ways to handle states. However, every time we close the application all of it is gone. Let us learn how to use GSettings by storing the state of a Switch in it.

At the very beginning we have to create a GSchema xml file in order to describe the kind of data our application plans to store in the settings.

Filename: listings/settings/1/org.gtk-rs.example.gschema.xml

<?xml version="1.0" encoding="utf-8"?>
<schemalist>
  <schema id="org.gtk-rs.example" path="/org/gtk-rs/example/">
    <key name="is-switch-enabled" type="b">
      <default>false</default>
      <summary>Default switch state</summary>
    </key>
  </schema>
</schemalist>

Let us get through it step by step. The id is the same application id we used when we created our application.

Filename: listings/settings/1/main.rs

use gio::Settings;
use gtk::gio;
use gtk::{glib::signal::Inhibit, prelude::*};
use gtk::{Align, Application, ApplicationWindow, Switch};

fn main() {
    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Connect to "activate" signal of `app`
    app.connect_activate(build_ui);

    // Run the application
    app.run();
}

fn build_ui(app: &Application) {
    // Initialize settings
    let settings = Settings::new("org.gtk-rs.example");

    // Get the last switch state from the settings
    let is_switch_enabled = settings.boolean("is-switch-enabled");

    // Create a switch
    let switch = Switch::builder()
        .margin_top(48)
        .margin_bottom(48)
        .margin_start(48)
        .margin_end(48)
        .valign(Align::Center)
        .halign(Align::Center)
        .state(is_switch_enabled)
        .build();

    switch.connect_state_set(move |_, is_enabled| {
        // Save changed switch state in the settings
        settings
            .set_boolean("is-switch-enabled", is_enabled)
            .expect("Could not set setting.");
        // Do not inhibit the default handler
        Inhibit(false)
    });

    // Create a window
    let window = ApplicationWindow::builder()
        .application(app)
        .title("My GTK App")
        .child(&switch)
        .build();

    // Present window
    window.present();
}

The path must start and end with a forward slash character ('/') and must not contain two sequential slash characters. When creating a path, we advise to take the id, replace the '.' with '/' and add '/' at the front and end of it.

We only want to store a single key with the name "is-switch-enabled". This is a boolean value so its type is "b" (see GVariant Format Strings for the other options). Finally, we define its default value and add a summary.

Now we need to copy and compile the schema. As of right now, cargo is not suitable for that task which is why you will need another build system on top of it. You can find an example on how to do this with meson in the gtk-rust-template.

However, we promised that cargo alone is enough to follow the book. For local testing, you can install the schema by executing the following commands on a Linux or macOS machine:

sudo cp org.gtk-rs.example.gschema.xml /usr/share/glib-2.0/schemas/
sudo glib-compile-schemas /usr/share/glib-2.0/schemas/

On Windows run:

cp org.gtk-rs.example.gschema.xml C:/ProgramData/glib-2.0/schemas/
glib-compile-schemas C:/ProgramData/glib-2.0/schemas/

We initialize the Settings object by specifying the application id.

Filename: listings/settings/1/main.rs

use gio::Settings;
use gtk::gio;
use gtk::{glib::signal::Inhibit, prelude::*};
use gtk::{Align, Application, ApplicationWindow, Switch};

fn main() {
    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Connect to "activate" signal of `app`
    app.connect_activate(build_ui);

    // Run the application
    app.run();
}

fn build_ui(app: &Application) {
    // Initialize settings
    let settings = Settings::new("org.gtk-rs.example");

    // Get the last switch state from the settings
    let is_switch_enabled = settings.boolean("is-switch-enabled");

    // Create a switch
    let switch = Switch::builder()
        .margin_top(48)
        .margin_bottom(48)
        .margin_start(48)
        .margin_end(48)
        .valign(Align::Center)
        .halign(Align::Center)
        .state(is_switch_enabled)
        .build();

    switch.connect_state_set(move |_, is_enabled| {
        // Save changed switch state in the settings
        settings
            .set_boolean("is-switch-enabled", is_enabled)
            .expect("Could not set setting.");
        // Do not inhibit the default handler
        Inhibit(false)
    });

    // Create a window
    let window = ApplicationWindow::builder()
        .application(app)
        .title("My GTK App")
        .child(&switch)
        .build();

    // Present window
    window.present();
}

Then we get the settings key and use it when we create our Switch.

Filename: listings/settings/1/main.rs

use gio::Settings;
use gtk::gio;
use gtk::{glib::signal::Inhibit, prelude::*};
use gtk::{Align, Application, ApplicationWindow, Switch};

fn main() {
    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Connect to "activate" signal of `app`
    app.connect_activate(build_ui);

    // Run the application
    app.run();
}

fn build_ui(app: &Application) {
    // Initialize settings
    let settings = Settings::new("org.gtk-rs.example");

    // Get the last switch state from the settings
    let is_switch_enabled = settings.boolean("is-switch-enabled");

    // Create a switch
    let switch = Switch::builder()
        .margin_top(48)
        .margin_bottom(48)
        .margin_start(48)
        .margin_end(48)
        .valign(Align::Center)
        .halign(Align::Center)
        .state(is_switch_enabled)
        .build();

    switch.connect_state_set(move |_, is_enabled| {
        // Save changed switch state in the settings
        settings
            .set_boolean("is-switch-enabled", is_enabled)
            .expect("Could not set setting.");
        // Do not inhibit the default handler
        Inhibit(false)
    });

    // Create a window
    let window = ApplicationWindow::builder()
        .application(app)
        .title("My GTK App")
        .child(&switch)
        .build();

    // Present window
    window.present();
}

Finally, we assure that the switch state is stored in the settings whenever we click on it.

Filename: listings/settings/1/main.rs

use gio::Settings;
use gtk::gio;
use gtk::{glib::signal::Inhibit, prelude::*};
use gtk::{Align, Application, ApplicationWindow, Switch};

fn main() {
    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Connect to "activate" signal of `app`
    app.connect_activate(build_ui);

    // Run the application
    app.run();
}

fn build_ui(app: &Application) {
    // Initialize settings
    let settings = Settings::new("org.gtk-rs.example");

    // Get the last switch state from the settings
    let is_switch_enabled = settings.boolean("is-switch-enabled");

    // Create a switch
    let switch = Switch::builder()
        .margin_top(48)
        .margin_bottom(48)
        .margin_start(48)
        .margin_end(48)
        .valign(Align::Center)
        .halign(Align::Center)
        .state(is_switch_enabled)
        .build();

    switch.connect_state_set(move |_, is_enabled| {
        // Save changed switch state in the settings
        settings
            .set_boolean("is-switch-enabled", is_enabled)
            .expect("Could not set setting.");
        // Do not inhibit the default handler
        Inhibit(false)
    });

    // Create a window
    let window = ApplicationWindow::builder()
        .application(app)
        .title("My GTK App")
        .child(&switch)
        .build();

    // Present window
    window.present();
}

The Switch now retains its state even after closing the application. But we can make this even better. The Switch has a property "state" and Settings allows us to bind properties to a specific setting. So let us do exactly that.

We can remove the boolean call before initializing the Switch as well as the connect_state_set call. We then bind the setting to the property by specifying the key, object and name of the property. Additionally, we specify SettingsBindFlags to control the direction in which the binding works.

Filename: listings/settings/2/main.rs

use gio::{Settings, SettingsBindFlags};
use gtk::gio;
use gtk::prelude::*;
use gtk::{Align, Application, ApplicationWindow, Switch};

fn main() {
    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Connect to "activate" signal of `app`
    app.connect_activate(build_ui);

    // Run the application
    app.run();
}

fn build_ui(app: &Application) {
    // Initialize settings
    let settings = Settings::new("org.gtk-rs.example");

    // Create a switch
    let switch = Switch::builder()
        .margin_top(48)
        .margin_bottom(48)
        .margin_start(48)
        .margin_end(48)
        .valign(Align::Center)
        .halign(Align::Center)
        .build();

    settings
        .bind("is-switch-enabled", &switch, "state")
        .flags(SettingsBindFlags::DEFAULT)
        .build();

    // Create a window
    let window = ApplicationWindow::builder()
        .application(app)
        .title("My GTK App")
        .child(&switch)
        .build();

    // Present window
    window.present();
}

Whenever you have a property which nicely correspond to a setting, you probably want to bind it to it. In other cases, interacting with the settings via the getter and setter methods tends to be the right choice.

Saving Window State

Quite often, we want the window state to persist between sessions. If the user resizes or maximizes the window, they might expect to find it in the same state the next time they open the app. GTK does not provide this functionality out of the box, but luckily it is not too hard to manually implement it. We basically want two integers (height & width) and a boolean (is_maximized) to persist. We already know how to do this by using Settings.

Filename: listings/saving_window_state/1/org.gtk-rs.example.gschema.xml

<?xml version="1.0" encoding="utf-8"?>
<schemalist>
  <schema id="org.gtk-rs.example" path="/org/gtk-rs/example/">
    <key name="window-width" type="i">
      <default>-1</default>
      <summary>Default window width</summary>
    </key>
    <key name="window-height" type="i">
      <default>-1</default>
      <summary>Default window height</summary>
    </key>
    <key name="is-maximized" type="b">
      <default>false</default>
      <summary>Default window maximized behaviour</summary>
    </key>
  </schema>
</schemalist>

Since we do not care about intermediate state, we only load the window state when the window is constructed and save it when we close the window. That can be done by creating a custom window. First, we create one and add methods for getting and setting the window state.

Filename: listings/saving_window_state/1/custom_window/mod.rs

mod imp;

use glib::Object;
use gtk::prelude::*;
use gtk::subclass::prelude::*;
use gtk::Application;
use gtk::{gio, glib};

glib::wrapper! {
    pub struct Window(ObjectSubclass<imp::Window>)
        @extends gtk::ApplicationWindow, gtk::Window, gtk::Widget,
        @implements gio::ActionGroup, gio::ActionMap, gtk::Accessible, gtk::Buildable,
                    gtk::ConstraintTarget, gtk::Native, gtk::Root, gtk::ShortcutManager;
}

impl Window {
    pub fn new(app: &Application) -> Self {
        // Create new window
        Object::new(&[("application", app)]).expect("Failed to create `Window`.")
    }

    pub fn save_window_size(&self) -> Result<(), glib::BoolError> {
        // Get `settings` from `imp::Window`
        let settings = &self.imp().settings;

        // Get the size of the window
        let size = self.default_size();

        // Set the window state in `settings`
        settings.set_int("window-width", size.0)?;
        settings.set_int("window-height", size.1)?;
        settings.set_boolean("is-maximized", self.is_maximized())?;

        Ok(())
    }

    fn load_window_size(&self) {
        // Get `settings` from `imp::Window`
        let settings = &self.imp().settings;

        // Get the window state from `settings`
        let width = settings.int("window-width");
        let height = settings.int("window-height");
        let is_maximized = settings.boolean("is-maximized");

        // Set the size of the window
        self.set_default_size(width, height);

        // If the window was maximized when it was closed, maximize it again
        if is_maximized {
            self.maximize();
        }
    }
}

The implementation struct holds the settings. We also override the constructed and close_request methods, where we load or save the window state.

Filename: listings/saving_window_state/1/custom_window/imp.rs

use gio::Settings;
use glib::signal::Inhibit;
use gtk::{gio, glib};
use gtk::{subclass::prelude::*, ApplicationWindow};

pub struct Window {
    pub settings: Settings,
}

#[glib::object_subclass]
impl ObjectSubclass for Window {
    const NAME: &'static str = "MyGtkAppWindow";
    type Type = super::Window;
    type ParentType = ApplicationWindow;

    fn new() -> Self {
        Self {
            settings: Settings::new("org.gtk-rs.example"),
        }
    }
}
impl ObjectImpl for Window {
    fn constructed(&self, obj: &Self::Type) {
        self.parent_constructed(obj);
        // Load latest window state
        obj.load_window_size();
    }
}
impl WidgetImpl for Window {}
impl WindowImpl for Window {
    // Save window state right before the window will be closed
    fn close_request(&self, obj: &Self::Type) -> Inhibit {
        if let Err(err) = obj.save_window_size() {
            log::error!("Failed to save window state, {}", &err);
        }
        // Do not inhibit the default handler
        Inhibit(false)
    }
}
impl ApplicationWindowImpl for Window {}

That is it! Now our window retains its state between app sessions.

Please note how we handle a failure in saving into the settings. We do not want to panic for recoverable errors. We might also not want to present all problems at the GUI. In our case we could not even do this, because the window will be immediately closed after the error occurs. Logging is the standard way of handling a situation like this. For that, we need to add the log crate and one of its front-ends, such as pretty_env_logger, to our dependencies.

Filename: listings/Cargo.toml

[dependencies]
log = "0.4"
pretty_env_logger = "0.4"

We then have to initialize pretty_env_logger by calling init in main.

Filename: listings/saving_window_state/1/main.rs

mod custom_window;

use custom_window::Window;
use gtk::prelude::*;
use gtk::{Application, Button};

fn main() {
    // Initialize logger
    pretty_env_logger::init();

    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Connect to "activate" signal of `app`
    app.connect_activate(build_ui);

    // Run the application
    app.run();
}

fn build_ui(app: &Application) {
    // Create a window
    let window = Window::new(app);

    // Create a button
    let button = Button::builder()
        .label("Press me!")
        .margin_top(12)
        .margin_bottom(12)
        .margin_start(12)
        .margin_end(12)
        .build();

    // Connect to "clicked" signal of `button`
    button.connect_clicked(move |button| {
        // Set the label to "Hello World!" after the button has been clicked on
        button.set_label("Hello World!");
    });

    // Add button
    window.set_child(Some(&button));
    window.present();
}

We can now modify the log level by setting the RUST_LOG environment variable as can be seen here

List Widgets

Sometimes you want to display a list of elements in a certain arrangement. ListBox and FlowBox are two container widgets which allow you to do this. ListBox describes a vertical list and FlowBox describes a grid.

Let us explore this concept by adding labels to a ListBox. Each label will display an integer starting from 0 and ranging up to 100.

Filename: listings/list_widgets/1/main.rs

use gtk::prelude::*;
use gtk::{Application, ApplicationWindow, Label, ListBox, PolicyType, ScrolledWindow};

fn main() {
    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Connect to "activate" signal of `app`
    app.connect_activate(build_ui);

    // Run the application
    app.run();
}

fn build_ui(app: &Application) {
    // Create a `ListBox` and add labels with integers from 0 to 100
    let list_box = ListBox::new();
    for number in 0..=100 {
        let label = Label::new(Some(&number.to_string()));
        list_box.append(&label);
    }

    let scrolled_window = ScrolledWindow::builder()
        .hscrollbar_policy(PolicyType::Never) // Disable horizontal scrolling
        .min_content_width(360)
        .child(&list_box)
        .build();

    // Create a window
    let window = ApplicationWindow::builder()
        .application(app)
        .title("My GTK App")
        .default_width(600)
        .default_height(300)
        .child(&scrolled_window)
        .build();

    // Present window
    window.present();
}

We cannot display so many widgets at once. Therefore, we add ListBox to a ScrolledWindow. Now we can scroll through our elements.

Filename: listings/list_widgets/1/main.rs

use gtk::prelude::*;
use gtk::{Application, ApplicationWindow, Label, ListBox, PolicyType, ScrolledWindow};

fn main() {
    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Connect to "activate" signal of `app`
    app.connect_activate(build_ui);

    // Run the application
    app.run();
}

fn build_ui(app: &Application) {
    // Create a `ListBox` and add labels with integers from 0 to 100
    let list_box = ListBox::new();
    for number in 0..=100 {
        let label = Label::new(Some(&number.to_string()));
        list_box.append(&label);
    }

    let scrolled_window = ScrolledWindow::builder()
        .hscrollbar_policy(PolicyType::Never) // Disable horizontal scrolling
        .min_content_width(360)
        .child(&list_box)
        .build();

    // Create a window
    let window = ApplicationWindow::builder()
        .application(app)
        .title("My GTK App")
        .default_width(600)
        .default_height(300)
        .child(&scrolled_window)
        .build();

    // Present window
    window.present();
}

Views

That was easy enough. However, we currently create one widget per element. Since each widget takes up a bit of resources, many of them can lead to slow and unresponsive user interfaces. Depending on the widget type even thousands of elements might not be a problem. But how could we possibly deal with the infinite amount of posts in a social media timeline?

We use scalable lists instead!

  • The model holds our data, filters it and describes its order.
  • The list item factory defines how the data transforms into widgets.
  • The view specifies how the widgets are then arranged.

What makes this concept scalable is that GTK only has to create slightly more widgets than we can currently look at. As we scroll through our elements, the widgets which become invisible will be reused. The following figure demonstrates how this works in practice.

100 000 elements is something ListBox will struggle with, so let us use this to demonstrate scalable lists.

We start by defining and filling up our model. The model is an instance of gio::ListStore. The main limitation here is that gio::ListStore only accepts GObjects. What we would need is a GObject which holds an integer and exposes it as property. To get that we just have to adapt the CustomButton we created in the subclassing chapter. We only need to let it inherit from GObject instead of Button and let the new method accept an integer as parameter.

Filename: listings/list_widgets/2/integer_object/mod.rs

mod imp;

use glib::Object;
use gtk::glib;

glib::wrapper! {
    pub struct IntegerObject(ObjectSubclass<imp::IntegerObject>);
}

impl IntegerObject {
    pub fn new(number: i32) -> Self {
        Object::new(&[("number", &number)]).expect("Failed to create `IntegerObject`.")
    }
}

The imp module can stay the same apart from the rename from CustomButton to IntegerObject.

Filename: listings/list_widgets/2/integer_object/imp.rs

use glib::{ParamFlags, ParamSpec, ParamSpecInt, Value};
use gtk::glib;
use gtk::prelude::*;
use gtk::subclass::prelude::*;
use once_cell::sync::Lazy;

use std::cell::Cell;

// Object holding the state
#[derive(Default)]
pub struct IntegerObject {
    number: Cell<i32>,
}

// The central trait for subclassing a GObject
#[glib::object_subclass]
impl ObjectSubclass for IntegerObject {
    const NAME: &'static str = "MyGtkAppIntegerObject";
    type Type = super::IntegerObject;
}

// Trait shared by all GObjects
impl ObjectImpl for IntegerObject {
    fn properties() -> &'static [ParamSpec] {
        static PROPERTIES: Lazy<Vec<ParamSpec>> = Lazy::new(|| {
            vec![ParamSpecInt::new(
                // Name
                "number",
                // Nickname
                "number",
                // Short description
                "number",
                // Minimum value
                i32::MIN,
                // Maximum value
                i32::MAX,
                // Default value
                0,
                // The property can be read and written to
                ParamFlags::READWRITE,
            )]
        });
        PROPERTIES.as_ref()
    }

    fn set_property(&self, _obj: &Self::Type, _id: usize, value: &Value, pspec: &ParamSpec) {
        match pspec.name() {
            "number" => {
                let input_number = value.get().expect("The value needs to be of type `i32`.");
                self.number.replace(input_number);
            }
            _ => unimplemented!(),
        }
    }

    fn property(&self, _obj: &Self::Type, _id: usize, pspec: &ParamSpec) -> Value {
        match pspec.name() {
            "number" => self.number.get().to_value(),
            _ => unimplemented!(),
        }
    }
}

We now fill the model with integers from 0 to 100 000. Please note that models only takes care of the data. Neither Label nor any other widget is mentioned here.

Filename: listings/list_widgets/2/main.rs

mod integer_object;

use gtk::gio;
use gtk::prelude::*;
use gtk::{
    Application, ApplicationWindow, Label, ListView, PolicyType, ScrolledWindow,
    SignalListItemFactory, SingleSelection,
};
use integer_object::IntegerObject;

fn main() {
    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Connect to "activate" signal of `app`
    app.connect_activate(build_ui);

    // Run the application
    app.run();
}

fn build_ui(app: &Application) {
    // Create a `Vec<IntegerObject>` with numbers from 0 to 100_000
    let vector: Vec<IntegerObject> = (0..=100_000).into_iter().map(IntegerObject::new).collect();

    // Create new model
    let model = gio::ListStore::new(IntegerObject::static_type());

    // Add the vector to the model at position 0 and 0 removals
    model.splice(0, 0, &vector);

    let factory = SignalListItemFactory::new();
    factory.connect_setup(move |_, list_item| {
        let label = Label::new(None);
        list_item.set_child(Some(&label));
    });

    factory.connect_bind(move |_, list_item| {
        // Get `IntegerObject` from `ListItem`
        let integer_object = list_item
            .item()
            .expect("The item has to exist.")
            .downcast::<IntegerObject>()
            .expect("The item has to be an `IntegerObject`.");

        // Get `i32` from `IntegerObject`
        let number = integer_object.property::<i32>("number");

        // Get `Label` from `ListItem`
        let label = list_item
            .child()
            .expect("The child has to exist.")
            .downcast::<Label>()
            .expect("The child has to be a `Label`.");

        // Set "label" to "number"
        label.set_label(&number.to_string());
    });

    let selection_model = SingleSelection::new(Some(&model));
    let list_view = ListView::new(Some(&selection_model), Some(&factory));

    let scrolled_window = ScrolledWindow::builder()
        .hscrollbar_policy(PolicyType::Never) // Disable horizontal scrolling
        .min_content_width(360)
        .child(&list_view)
        .build();

    // Create a window
    let window = ApplicationWindow::builder()
        .application(app)
        .title("My GTK App")
        .default_width(600)
        .default_height(300)
        .child(&scrolled_window)
        .build();

    // Present window
    window.present();
}

The ListItemFactory takes care of the widgets as well as their relationship to the model. Here, we use the SignalListItemFactory which emits a signal for every relevant step in the life of a ListItem. The "setup" signal will be emitted when new widgets have to be created. We connect to it to create a Label for every requested widget.

Filename: listings/list_widgets/2/main.rs

mod integer_object;

use gtk::gio;
use gtk::prelude::*;
use gtk::{
    Application, ApplicationWindow, Label, ListView, PolicyType, ScrolledWindow,
    SignalListItemFactory, SingleSelection,
};
use integer_object::IntegerObject;

fn main() {
    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Connect to "activate" signal of `app`
    app.connect_activate(build_ui);

    // Run the application
    app.run();
}

fn build_ui(app: &Application) {
    // Create a `Vec<IntegerObject>` with numbers from 0 to 100_000
    let vector: Vec<IntegerObject> = (0..=100_000).into_iter().map(IntegerObject::new).collect();

    // Create new model
    let model = gio::ListStore::new(IntegerObject::static_type());

    // Add the vector to the model at position 0 and 0 removals
    model.splice(0, 0, &vector);

    let factory = SignalListItemFactory::new();
    factory.connect_setup(move |_, list_item| {
        let label = Label::new(None);
        list_item.set_child(Some(&label));
    });

    factory.connect_bind(move |_, list_item| {
        // Get `IntegerObject` from `ListItem`
        let integer_object = list_item
            .item()
            .expect("The item has to exist.")
            .downcast::<IntegerObject>()
            .expect("The item has to be an `IntegerObject`.");

        // Get `i32` from `IntegerObject`
        let number = integer_object.property::<i32>("number");

        // Get `Label` from `ListItem`
        let label = list_item
            .child()
            .expect("The child has to exist.")
            .downcast::<Label>()
            .expect("The child has to be a `Label`.");

        // Set "label" to "number"
        label.set_label(&number.to_string());
    });

    let selection_model = SingleSelection::new(Some(&model));
    let list_view = ListView::new(Some(&selection_model), Some(&factory));

    let scrolled_window = ScrolledWindow::builder()
        .hscrollbar_policy(PolicyType::Never) // Disable horizontal scrolling
        .min_content_width(360)
        .child(&list_view)
        .build();

    // Create a window
    let window = ApplicationWindow::builder()
        .application(app)
        .title("My GTK App")
        .default_width(600)
        .default_height(300)
        .child(&scrolled_window)
        .build();

    // Present window
    window.present();
}

In the "bind" step we bind the data in our model to the individual list items.

Filename: listings/list_widgets/2/main.rs

mod integer_object;

use gtk::gio;
use gtk::prelude::*;
use gtk::{
    Application, ApplicationWindow, Label, ListView, PolicyType, ScrolledWindow,
    SignalListItemFactory, SingleSelection,
};
use integer_object::IntegerObject;

fn main() {
    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Connect to "activate" signal of `app`
    app.connect_activate(build_ui);

    // Run the application
    app.run();
}

fn build_ui(app: &Application) {
    // Create a `Vec<IntegerObject>` with numbers from 0 to 100_000
    let vector: Vec<IntegerObject> = (0..=100_000).into_iter().map(IntegerObject::new).collect();

    // Create new model
    let model = gio::ListStore::new(IntegerObject::static_type());

    // Add the vector to the model at position 0 and 0 removals
    model.splice(0, 0, &vector);

    let factory = SignalListItemFactory::new();
    factory.connect_setup(move |_, list_item| {
        let label = Label::new(None);
        list_item.set_child(Some(&label));
    });

    factory.connect_bind(move |_, list_item| {
        // Get `IntegerObject` from `ListItem`
        let integer_object = list_item
            .item()
            .expect("The item has to exist.")
            .downcast::<IntegerObject>()
            .expect("The item has to be an `IntegerObject`.");

        // Get `i32` from `IntegerObject`
        let number = integer_object.property::<i32>("number");

        // Get `Label` from `ListItem`
        let label = list_item
            .child()
            .expect("The child has to exist.")
            .downcast::<Label>()
            .expect("The child has to be a `Label`.");

        // Set "label" to "number"
        label.set_label(&number.to_string());
    });

    let selection_model = SingleSelection::new(Some(&model));
    let list_view = ListView::new(Some(&selection_model), Some(&factory));

    let scrolled_window = ScrolledWindow::builder()
        .hscrollbar_policy(PolicyType::Never) // Disable horizontal scrolling
        .min_content_width(360)
        .child(&list_view)
        .build();

    // Create a window
    let window = ApplicationWindow::builder()
        .application(app)
        .title("My GTK App")
        .default_width(600)
        .default_height(300)
        .child(&scrolled_window)
        .build();

    // Present window
    window.present();
}

We only want single items to be selectable, so we choose SingleSelection. The other options would have been MultiSelection or NoSelection. Then we pass the model and the factory to the ListView.

Filename: listings/list_widgets/2/main.rs

mod integer_object;

use gtk::gio;
use gtk::prelude::*;
use gtk::{
    Application, ApplicationWindow, Label, ListView, PolicyType, ScrolledWindow,
    SignalListItemFactory, SingleSelection,
};
use integer_object::IntegerObject;

fn main() {
    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Connect to "activate" signal of `app`
    app.connect_activate(build_ui);

    // Run the application
    app.run();
}

fn build_ui(app: &Application) {
    // Create a `Vec<IntegerObject>` with numbers from 0 to 100_000
    let vector: Vec<IntegerObject> = (0..=100_000).into_iter().map(IntegerObject::new).collect();

    // Create new model
    let model = gio::ListStore::new(IntegerObject::static_type());

    // Add the vector to the model at position 0 and 0 removals
    model.splice(0, 0, &vector);

    let factory = SignalListItemFactory::new();
    factory.connect_setup(move |_, list_item| {
        let label = Label::new(None);
        list_item.set_child(Some(&label));
    });

    factory.connect_bind(move |_, list_item| {
        // Get `IntegerObject` from `ListItem`
        let integer_object = list_item
            .item()
            .expect("The item has to exist.")
            .downcast::<IntegerObject>()
            .expect("The item has to be an `IntegerObject`.");

        // Get `i32` from `IntegerObject`
        let number = integer_object.property::<i32>("number");

        // Get `Label` from `ListItem`
        let label = list_item
            .child()
            .expect("The child has to exist.")
            .downcast::<Label>()
            .expect("The child has to be a `Label`.");

        // Set "label" to "number"
        label.set_label(&number.to_string());
    });

    let selection_model = SingleSelection::new(Some(&model));
    let list_view = ListView::new(Some(&selection_model), Some(&factory));

    let scrolled_window = ScrolledWindow::builder()
        .hscrollbar_policy(PolicyType::Never) // Disable horizontal scrolling
        .min_content_width(360)
        .child(&list_view)
        .build();

    // Create a window
    let window = ApplicationWindow::builder()
        .application(app)
        .title("My GTK App")
        .default_width(600)
        .default_height(300)
        .child(&scrolled_window)
        .build();

    // Present window
    window.present();
}

Every ListView has to be a direct child of a ScrolledWindow, so we are adding it to one.

Filename: listings/list_widgets/2/main.rs

mod integer_object;

use gtk::gio;
use gtk::prelude::*;
use gtk::{
    Application, ApplicationWindow, Label, ListView, PolicyType, ScrolledWindow,
    SignalListItemFactory, SingleSelection,
};
use integer_object::IntegerObject;

fn main() {
    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Connect to "activate" signal of `app`
    app.connect_activate(build_ui);

    // Run the application
    app.run();
}

fn build_ui(app: &Application) {
    // Create a `Vec<IntegerObject>` with numbers from 0 to 100_000
    let vector: Vec<IntegerObject> = (0..=100_000).into_iter().map(IntegerObject::new).collect();

    // Create new model
    let model = gio::ListStore::new(IntegerObject::static_type());

    // Add the vector to the model at position 0 and 0 removals
    model.splice(0, 0, &vector);

    let factory = SignalListItemFactory::new();
    factory.connect_setup(move |_, list_item| {
        let label = Label::new(None);
        list_item.set_child(Some(&label));
    });

    factory.connect_bind(move |_, list_item| {
        // Get `IntegerObject` from `ListItem`
        let integer_object = list_item
            .item()
            .expect("The item has to exist.")
            .downcast::<IntegerObject>()
            .expect("The item has to be an `IntegerObject`.");

        // Get `i32` from `IntegerObject`
        let number = integer_object.property::<i32>("number");

        // Get `Label` from `ListItem`
        let label = list_item
            .child()
            .expect("The child has to exist.")
            .downcast::<Label>()
            .expect("The child has to be a `Label`.");

        // Set "label" to "number"
        label.set_label(&number.to_string());
    });

    let selection_model = SingleSelection::new(Some(&model));
    let list_view = ListView::new(Some(&selection_model), Some(&factory));

    let scrolled_window = ScrolledWindow::builder()
        .hscrollbar_policy(PolicyType::Never) // Disable horizontal scrolling
        .min_content_width(360)
        .child(&list_view)
        .build();

    // Create a window
    let window = ApplicationWindow::builder()
        .application(app)
        .title("My GTK App")
        .default_width(600)
        .default_height(300)
        .child(&scrolled_window)
        .build();

    // Present window
    window.present();
}

We can now easily scroll through our long list of integers.

Let us see what else we can do. We might want to increase the number every time we activate its row. For that we first add the method increase_number to our IntegerObject.

Filename: listings/list_widgets/3/integer_object/mod.rs

mod imp;

use glib::Object;
use gtk::glib;
use gtk::prelude::*;

glib::wrapper! {
    pub struct IntegerObject(ObjectSubclass<imp::IntegerObject>);
}

impl IntegerObject {
    pub fn new(number: i32) -> Self {
        Object::new(&[("number", &number)]).expect("Failed to create `IntegerObject`.")
    }

    pub fn increase_number(self) {
        let old_number = self.property::<i32>("number");
        self.set_property("number", old_number + 1);
    }
}

In order to interact with our ListView, we connect to its "activate" signal.

Filename: listings/list_widgets/3/main.rs

mod integer_object;

use glib::BindingFlags;
use gtk::prelude::*;
use gtk::{gio, glib};
use gtk::{
    Application, ApplicationWindow, Label, ListView, PolicyType, ScrolledWindow,
    SignalListItemFactory, SingleSelection,
};
use integer_object::IntegerObject;

fn main() {
    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Connect to "activate" signal of `app`
    app.connect_activate(build_ui);

    // Run the application
    app.run();
}

fn build_ui(app: &Application) {
    // Create a `Vec<IntegerObject>` with numbers from 0 to 100_000
    let vector: Vec<IntegerObject> = (0..=100_000).into_iter().map(IntegerObject::new).collect();

    // Create new model
    let model = gio::ListStore::new(IntegerObject::static_type());

    // Add the vector to the model at position 0 and 0 removals
    model.splice(0, 0, &vector);

    let factory = SignalListItemFactory::new();
    factory.connect_setup(move |_, list_item| {
        let label = Label::new(None);
        list_item.set_child(Some(&label));
    });

    factory.connect_bind(move |_, list_item| {
        // Get `IntegerObject` from `ListItem`
        let integer_object = list_item
            .item()
            .expect("The item has to exist.")
            .downcast::<IntegerObject>()
            .expect("The item has to be an `IntegerObject`.");

        // Get `Label` from `ListItem`
        let label = list_item
            .child()
            .expect("The child has to exist.")
            .downcast::<Label>()
            .expect("The child has to be a `Label`.");

        // Bind "label" to "number"
        integer_object
            .bind_property("number", &label, "label")
            .flags(BindingFlags::SYNC_CREATE)
            .build();
    });

    let selection_model = SingleSelection::new(Some(&model));
    let list_view = ListView::new(Some(&selection_model), Some(&factory));

    list_view.connect_activate(move |list_view, position| {
        // Get `IntegerObject` from model
        let model = list_view.model().expect("The model has to exist.");
        let integer_object = model
            .item(position)
            .expect("The item has to exist.")
            .downcast::<IntegerObject>()
            .expect("The item has to be an `IntegerObject`.");

        // Increase "number" of `IntegerObject`
        integer_object.increase_number();
    });

    let scrolled_window = ScrolledWindow::builder()
        .hscrollbar_policy(PolicyType::Never) // Disable horizontal scrolling
        .min_content_width(360)
        .child(&list_view)
        .build();

    // Create a window
    let window = ApplicationWindow::builder()
        .application(app)
        .title("My GTK App")
        .default_width(600)
        .default_height(300)
        .child(&scrolled_window)
        .build();

    // Present window
    window.present();
}

Now every time we activate an element, for example by double-clicking on it, the corresponding "number" property of the IntegerObject in the model will be increased by 1. However, just because the IntegerObject has been modified the corresponding Label does not immediately change. One naive approach would be to bind the properties in the "bind" step of the SignalListItemFactory.

Filename: listings/list_widgets/3/main.rs

mod integer_object;

use glib::BindingFlags;
use gtk::prelude::*;
use gtk::{gio, glib};
use gtk::{
    Application, ApplicationWindow, Label, ListView, PolicyType, ScrolledWindow,
    SignalListItemFactory, SingleSelection,
};
use integer_object::IntegerObject;

fn main() {
    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Connect to "activate" signal of `app`
    app.connect_activate(build_ui);

    // Run the application
    app.run();
}

fn build_ui(app: &Application) {
    // Create a `Vec<IntegerObject>` with numbers from 0 to 100_000
    let vector: Vec<IntegerObject> = (0..=100_000).into_iter().map(IntegerObject::new).collect();

    // Create new model
    let model = gio::ListStore::new(IntegerObject::static_type());

    // Add the vector to the model at position 0 and 0 removals
    model.splice(0, 0, &vector);

    let factory = SignalListItemFactory::new();
    factory.connect_setup(move |_, list_item| {
        let label = Label::new(None);
        list_item.set_child(Some(&label));
    });

    factory.connect_bind(move |_, list_item| {
        // Get `IntegerObject` from `ListItem`
        let integer_object = list_item
            .item()
            .expect("The item has to exist.")
            .downcast::<IntegerObject>()
            .expect("The item has to be an `IntegerObject`.");

        // Get `Label` from `ListItem`
        let label = list_item
            .child()
            .expect("The child has to exist.")
            .downcast::<Label>()
            .expect("The child has to be a `Label`.");

        // Bind "label" to "number"
        integer_object
            .bind_property("number", &label, "label")
            .flags(BindingFlags::SYNC_CREATE)
            .build();
    });

    let selection_model = SingleSelection::new(Some(&model));
    let list_view = ListView::new(Some(&selection_model), Some(&factory));

    list_view.connect_activate(move |list_view, position| {
        // Get `IntegerObject` from model
        let model = list_view.model().expect("The model has to exist.");
        let integer_object = model
            .item(position)
            .expect("The item has to exist.")
            .downcast::<IntegerObject>()
            .expect("The item has to be an `IntegerObject`.");

        // Increase "number" of `IntegerObject`
        integer_object.increase_number();
    });

    let scrolled_window = ScrolledWindow::builder()
        .hscrollbar_policy(PolicyType::Never) // Disable horizontal scrolling
        .min_content_width(360)
        .child(&list_view)
        .build();

    // Create a window
    let window = ApplicationWindow::builder()
        .application(app)
        .title("My GTK App")
        .default_width(600)
        .default_height(300)
        .child(&scrolled_window)
        .build();

    // Present window
    window.present();
}

At first glance, that seems to work. However, as you scroll around and activate a few list elements, you will notice that sometimes multiple numbers change even though you only activated a single one. This relates to how the view works internally. Not every model item belongs to a single widget, but the widgets get recycled instead as you scroll through the view. That also means that in our case, multiple numbers will be bound to the same widget.

Expressions

Situations like these are so common that GTK offers an alternative to property binding: expressions. As a first step it allows us to remove the "bind" step. Let us see how the "setup" step now works.

Filename: listings/list_widgets/4/main.rs

mod integer_object;

use gtk::gio;
use gtk::prelude::*;
use gtk::{
    Application, ApplicationWindow, Label, ListView, PolicyType, ScrolledWindow,
    SignalListItemFactory, SingleSelection, Widget,
};
use integer_object::IntegerObject;

fn main() {
    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Connect to "activate" signal of `app`
    app.connect_activate(build_ui);

    // Run the application
    app.run();
}

fn build_ui(app: &Application) {
    // Create a `Vec<IntegerObject>` with numbers from 0 to 100_000
    let vector: Vec<IntegerObject> = (0..=100_000).into_iter().map(IntegerObject::new).collect();

    // Create new model
    let model = gio::ListStore::new(IntegerObject::static_type());

    // Add the vector to the model at position 0 and 0 removals
    model.splice(0, 0, &vector);

    let factory = SignalListItemFactory::new();
    factory.connect_setup(move |_, list_item| {
        // Create label
        let label = Label::new(None);
        list_item.set_child(Some(&label));

        // Bind `list_item->item->number` to `label->label`
        list_item
            .property_expression("item")
            .chain_property::<IntegerObject>("number")
            .bind(&label, "label", Widget::NONE);
    });

    let selection_model = SingleSelection::new(Some(&model));
    let list_view = ListView::new(Some(&selection_model), Some(&factory));

    list_view.connect_activate(move |list_view, position| {
        // Get `IntegerObject` from model
        let model = list_view.model().expect("The model has to exist.");
        let integer_object = model
            .item(position)
            .expect("The item has to exist.")
            .downcast::<IntegerObject>()
            .expect("The item has to be an `IntegerObject`.");

        // Increase "number" of `IntegerObject`
        integer_object.increase_number();
    });

    let scrolled_window = ScrolledWindow::builder()
        .hscrollbar_policy(PolicyType::Never) // Disable horizontal scrolling
        .min_content_width(360)
        .child(&list_view)
        .build();

    // Create a window
    let window = ApplicationWindow::builder()
        .application(app)
        .title("My GTK App")
        .default_width(600)
        .default_height(300)
        .child(&scrolled_window)
        .build();

    // Present window
    window.present();
}

An expression provides a way to describe references to values. One interesting part here is that these references can be several steps away. This allowed us in the snippet above to bind the property "number" of the property "item" of list_item to the property "label" of label.

It is also worth noting that at the "setup" stage there is no way of knowing which list item belongs to which label, simply because this changes as we scroll through the list. Here, another power of expressions becomes evident. Expressions allow us to describe relationships between objects or properties that might not even exist yet. We just had to tell it to change the label whenever the number that belongs to it changes. That way, we also do not face the problem that multiple labels are bound to the same number. When we now activate a label, only the corresponding number visibly changes.

Let us extend our app a bit more. We can, for example, filter our model to only allow even numbers.

Filename: listings/list_widgets/5/main.rs

mod integer_object;

use gtk::gio;
use gtk::prelude::*;
use gtk::{
    Application, ApplicationWindow, CustomSorter, FilterChange, Label, ListView, PolicyType,
    ScrolledWindow, SignalListItemFactory, SingleSelection, SortListModel, SorterChange, Widget,
};
use integer_object::IntegerObject;

fn main() {
    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Connect to "activate" signal of `app`
    app.connect_activate(build_ui);

    // Run the application
    app.run();
}

fn build_ui(app: &Application) {
    // Create a `Vec<IntegerObject>` with numbers from 0 to 100_000
    let vector: Vec<IntegerObject> = (0..=100_000).into_iter().map(IntegerObject::new).collect();

    // Create new model
    let model = gio::ListStore::new(IntegerObject::static_type());

    // Add the vector to the model at position 0 and 0 removals
    model.splice(0, 0, &vector);

    let factory = SignalListItemFactory::new();
    factory.connect_setup(move |_, list_item| {
        // Create label
        let label = Label::new(None);
        list_item.set_child(Some(&label));

        // Bind `list_item->item->number` to `label->label`
        list_item
            .property_expression("item")
            .chain_property::<IntegerObject>("number")
            .bind(&label, "label", Widget::NONE);
    });

    let filter = gtk::CustomFilter::new(move |obj| {
        // Get `IntegerObject` from `glib::Object`
        let integer_object = obj
            .downcast_ref::<IntegerObject>()
            .expect("The object needs to be of type `IntegerObject`.");

        // Get property "number" from `IntegerObject`
        let number = integer_object.property::<i32>("number");

        // Only allow even numbers
        number % 2 == 0
    });
    let filter_model = gtk::FilterListModel::new(Some(&model), Some(&filter));

    let sorter = CustomSorter::new(move |obj1, obj2| {
        // Get `IntegerObject` from `glib::Object`
        let integer_object_1 = obj1
            .downcast_ref::<IntegerObject>()
            .expect("The object needs to be of type `IntegerObject`.");
        let integer_object_2 = obj2
            .downcast_ref::<IntegerObject>()
            .expect("The object needs to be of type `IntegerObject`.");

        // Get property "number" from `IntegerObject`
        let number_1 = integer_object_1.property::<i32>("number");
        let number_2 = integer_object_2.property::<i32>("number");

        // Reverse sorting order -> large numbers come first
        number_2.cmp(&number_1).into()
    });
    let sort_model = SortListModel::new(Some(&filter_model), Some(&sorter));

    let selection_model = SingleSelection::new(Some(&sort_model));
    let list_view = ListView::new(Some(&selection_model), Some(&factory));

    list_view.connect_activate(move |list_view, position| {
        // Get `IntegerObject` from model
        let model = list_view.model().expect("The model has to exist.");
        let integer_object = model
            .item(position)
            .expect("The item has to exist.")
            .downcast::<IntegerObject>()
            .expect("The item has to be an `IntegerObject`.");

        // Increase "number" of `IntegerObject`
        integer_object.increase_number();

        // Notify that the filter and sorter have been changed
        filter.changed(FilterChange::Different);
        sorter.changed(SorterChange::Different);
    });

    let scrolled_window = ScrolledWindow::builder()
        .hscrollbar_policy(PolicyType::Never) // Disable horizontal scrolling
        .min_content_width(360)
        .child(&list_view)
        .build();

    // Create a window
    let window = ApplicationWindow::builder()
        .application(app)
        .title("My GTK App")
        .default_width(600)
        .default_height(300)
        .child(&scrolled_window)
        .build();

    // Present window
    window.present();
}

Additionally, we can reverse the order of our model.

Filename: listings/list_widgets/5/main.rs

mod integer_object;

use gtk::gio;
use gtk::prelude::*;
use gtk::{
    Application, ApplicationWindow, CustomSorter, FilterChange, Label, ListView, PolicyType,
    ScrolledWindow, SignalListItemFactory, SingleSelection, SortListModel, SorterChange, Widget,
};
use integer_object::IntegerObject;

fn main() {
    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Connect to "activate" signal of `app`
    app.connect_activate(build_ui);

    // Run the application
    app.run();
}

fn build_ui(app: &Application) {
    // Create a `Vec<IntegerObject>` with numbers from 0 to 100_000
    let vector: Vec<IntegerObject> = (0..=100_000).into_iter().map(IntegerObject::new).collect();

    // Create new model
    let model = gio::ListStore::new(IntegerObject::static_type());

    // Add the vector to the model at position 0 and 0 removals
    model.splice(0, 0, &vector);

    let factory = SignalListItemFactory::new();
    factory.connect_setup(move |_, list_item| {
        // Create label
        let label = Label::new(None);
        list_item.set_child(Some(&label));

        // Bind `list_item->item->number` to `label->label`
        list_item
            .property_expression("item")
            .chain_property::<IntegerObject>("number")
            .bind(&label, "label", Widget::NONE);
    });

    let filter = gtk::CustomFilter::new(move |obj| {
        // Get `IntegerObject` from `glib::Object`
        let integer_object = obj
            .downcast_ref::<IntegerObject>()
            .expect("The object needs to be of type `IntegerObject`.");

        // Get property "number" from `IntegerObject`
        let number = integer_object.property::<i32>("number");

        // Only allow even numbers
        number % 2 == 0
    });
    let filter_model = gtk::FilterListModel::new(Some(&model), Some(&filter));

    let sorter = CustomSorter::new(move |obj1, obj2| {
        // Get `IntegerObject` from `glib::Object`
        let integer_object_1 = obj1
            .downcast_ref::<IntegerObject>()
            .expect("The object needs to be of type `IntegerObject`.");
        let integer_object_2 = obj2
            .downcast_ref::<IntegerObject>()
            .expect("The object needs to be of type `IntegerObject`.");

        // Get property "number" from `IntegerObject`
        let number_1 = integer_object_1.property::<i32>("number");
        let number_2 = integer_object_2.property::<i32>("number");

        // Reverse sorting order -> large numbers come first
        number_2.cmp(&number_1).into()
    });
    let sort_model = SortListModel::new(Some(&filter_model), Some(&sorter));

    let selection_model = SingleSelection::new(Some(&sort_model));
    let list_view = ListView::new(Some(&selection_model), Some(&factory));

    list_view.connect_activate(move |list_view, position| {
        // Get `IntegerObject` from model
        let model = list_view.model().expect("The model has to exist.");
        let integer_object = model
            .item(position)
            .expect("The item has to exist.")
            .downcast::<IntegerObject>()
            .expect("The item has to be an `IntegerObject`.");

        // Increase "number" of `IntegerObject`
        integer_object.increase_number();

        // Notify that the filter and sorter have been changed
        filter.changed(FilterChange::Different);
        sorter.changed(SorterChange::Different);
    });

    let scrolled_window = ScrolledWindow::builder()
        .hscrollbar_policy(PolicyType::Never) // Disable horizontal scrolling
        .min_content_width(360)
        .child(&list_view)
        .build();

    // Create a window
    let window = ApplicationWindow::builder()
        .application(app)
        .title("My GTK App")
        .default_width(600)
        .default_height(300)
        .child(&scrolled_window)
        .build();

    // Present window
    window.present();
}

To ensure that our filter and sorter get updated when we modify the numbers, we call the changed method on them.

Filename: listings/list_widgets/5/main.rs

mod integer_object;

use gtk::gio;
use gtk::prelude::*;
use gtk::{
    Application, ApplicationWindow, CustomSorter, FilterChange, Label, ListView, PolicyType,
    ScrolledWindow, SignalListItemFactory, SingleSelection, SortListModel, SorterChange, Widget,
};
use integer_object::IntegerObject;

fn main() {
    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Connect to "activate" signal of `app`
    app.connect_activate(build_ui);

    // Run the application
    app.run();
}

fn build_ui(app: &Application) {
    // Create a `Vec<IntegerObject>` with numbers from 0 to 100_000
    let vector: Vec<IntegerObject> = (0..=100_000).into_iter().map(IntegerObject::new).collect();

    // Create new model
    let model = gio::ListStore::new(IntegerObject::static_type());

    // Add the vector to the model at position 0 and 0 removals
    model.splice(0, 0, &vector);

    let factory = SignalListItemFactory::new();
    factory.connect_setup(move |_, list_item| {
        // Create label
        let label = Label::new(None);
        list_item.set_child(Some(&label));

        // Bind `list_item->item->number` to `label->label`
        list_item
            .property_expression("item")
            .chain_property::<IntegerObject>("number")
            .bind(&label, "label", Widget::NONE);
    });

    let filter = gtk::CustomFilter::new(move |obj| {
        // Get `IntegerObject` from `glib::Object`
        let integer_object = obj
            .downcast_ref::<IntegerObject>()
            .expect("The object needs to be of type `IntegerObject`.");

        // Get property "number" from `IntegerObject`
        let number = integer_object.property::<i32>("number");

        // Only allow even numbers
        number % 2 == 0
    });
    let filter_model = gtk::FilterListModel::new(Some(&model), Some(&filter));

    let sorter = CustomSorter::new(move |obj1, obj2| {
        // Get `IntegerObject` from `glib::Object`
        let integer_object_1 = obj1
            .downcast_ref::<IntegerObject>()
            .expect("The object needs to be of type `IntegerObject`.");
        let integer_object_2 = obj2
            .downcast_ref::<IntegerObject>()
            .expect("The object needs to be of type `IntegerObject`.");

        // Get property "number" from `IntegerObject`
        let number_1 = integer_object_1.property::<i32>("number");
        let number_2 = integer_object_2.property::<i32>("number");

        // Reverse sorting order -> large numbers come first
        number_2.cmp(&number_1).into()
    });
    let sort_model = SortListModel::new(Some(&filter_model), Some(&sorter));

    let selection_model = SingleSelection::new(Some(&sort_model));
    let list_view = ListView::new(Some(&selection_model), Some(&factory));

    list_view.connect_activate(move |list_view, position| {
        // Get `IntegerObject` from model
        let model = list_view.model().expect("The model has to exist.");
        let integer_object = model
            .item(position)
            .expect("The item has to exist.")
            .downcast::<IntegerObject>()
            .expect("The item has to be an `IntegerObject`.");

        // Increase "number" of `IntegerObject`
        integer_object.increase_number();

        // Notify that the filter and sorter have been changed
        filter.changed(FilterChange::Different);
        sorter.changed(SorterChange::Different);
    });

    let scrolled_window = ScrolledWindow::builder()
        .hscrollbar_policy(PolicyType::Never) // Disable horizontal scrolling
        .min_content_width(360)
        .child(&list_view)
        .build();

    // Create a window
    let window = ApplicationWindow::builder()
        .application(app)
        .title("My GTK App")
        .default_width(600)
        .default_height(300)
        .child(&scrolled_window)
        .build();

    // Present window
    window.present();
}

After our changes, the application looks like this:

String List

Often, all you want is to display a list of strings. However, if you either need to filter and sort your displayed data or have too many elements to be displayed by ListBox, you will still want to use a view. GTK provides a convenient model for this use case: gtk::StringList.

Let us see with a small example how to use this API. Filter and sorter is controlled by the factory, so nothing changes here. This is why we will skip this topic here.

First, we add a bunch of strings to our model.

Filename: listings/list_widgets/6/main.rs

use gtk::prelude::*;
use gtk::{
    Application, ApplicationWindow, Label, ListView, NoSelection, PolicyType, ScrolledWindow,
    SignalListItemFactory, StringList, StringObject, Widget,
};

fn main() {
    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Connect to "activate" signal of `app`
    app.connect_activate(build_ui);

    // Run the application
    app.run();
}

fn build_ui(app: &Application) {
    // Create a `StringList` with number from 0 to 100_000
    // `StringList` implements FromIterator<String>
    let model: StringList = (0..=100_000)
        .into_iter()
        .map(|number| format!("Task number {}", number))
        .collect();

    let factory = SignalListItemFactory::new();
    factory.connect_setup(move |_, list_item| {
        // Create label
        let label = Label::new(None);
        list_item.set_child(Some(&label));

        // Bind `list_item->item->string` to `label->label`
        list_item
            .property_expression("item")
            .chain_property::<StringObject>("string")
            .bind(&label, "label", Widget::NONE);
    });

    let selection_model = NoSelection::new(Some(&model));
    let list_view = ListView::new(Some(&selection_model), Some(&factory));

    let scrolled_window = ScrolledWindow::builder()
        .hscrollbar_policy(PolicyType::Never) // Disable horizontal scrolling
        .min_content_width(360)
        .child(&list_view)
        .build();

    // Create a window
    let window = ApplicationWindow::builder()
        .application(app)
        .title("My GTK App")
        .default_width(600)
        .default_height(300)
        .child(&scrolled_window)
        .build();

    // Present window
    window.present();
}

Note that we can create a StringList directly from an iterator over strings. This means we do not have to create a custom GObject for our model anymore.

As usual, we connect the label to the list item via an expression. Here we can use StringObject, which exposes its content via the property "string".

Filename: listings/list_widgets/6/main.rs

use gtk::prelude::*;
use gtk::{
    Application, ApplicationWindow, Label, ListView, NoSelection, PolicyType, ScrolledWindow,
    SignalListItemFactory, StringList, StringObject, Widget,
};

fn main() {
    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Connect to "activate" signal of `app`
    app.connect_activate(build_ui);

    // Run the application
    app.run();
}

fn build_ui(app: &Application) {
    // Create a `StringList` with number from 0 to 100_000
    // `StringList` implements FromIterator<String>
    let model: StringList = (0..=100_000)
        .into_iter()
        .map(|number| format!("Task number {}", number))
        .collect();

    let factory = SignalListItemFactory::new();
    factory.connect_setup(move |_, list_item| {
        // Create label
        let label = Label::new(None);
        list_item.set_child(Some(&label));

        // Bind `list_item->item->string` to `label->label`
        list_item
            .property_expression("item")
            .chain_property::<StringObject>("string")
            .bind(&label, "label", Widget::NONE);
    });

    let selection_model = NoSelection::new(Some(&model));
    let list_view = ListView::new(Some(&selection_model), Some(&factory));

    let scrolled_window = ScrolledWindow::builder()
        .hscrollbar_policy(PolicyType::Never) // Disable horizontal scrolling
        .min_content_width(360)
        .child(&list_view)
        .build();

    // Create a window
    let window = ApplicationWindow::builder()
        .application(app)
        .title("My GTK App")
        .default_width(600)
        .default_height(300)
        .child(&scrolled_window)
        .build();

    // Present window
    window.present();
}

Conclusion

We now know how to display a list of data. Small amount of elements can be handled by ListBox or FlowBox. These widgets are easy to use and allow, if necessary, to be bound to a model such as gio::ListStore. Their data can then be modified, sorted and filtered more easily. However, if we need the widgets to be scalable, we still need to use ListView, ColumnView or GridView instead.

Interface Builder

GTK Builder

Until now, whenever we constructed pre-defined widgets we relied on the builder pattern. As a reminder, that is how we used it in our trusty "Hello World!" app.

Filename: listings/hello_world/3/main.rs

use gtk::prelude::*;
use gtk::{Application, ApplicationWindow, Button};

fn main() {
    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Connect to "activate" signal of `app`
    app.connect_activate(build_ui);

    // Run the application
    app.run();
}

fn build_ui(app: &Application) {
    // Create a button with label and margins
    let button = Button::builder()
        .label("Press me!")
        .margin_top(12)
        .margin_bottom(12)
        .margin_start(12)
        .margin_end(12)
        .build();

    // Connect to "clicked" signal of `button`
    button.connect_clicked(move |button| {
        // Set the label to "Hello World!" after the button has been clicked on
        button.set_label("Hello World!");
    });

    // Create a window
    let window = ApplicationWindow::builder()
        .application(app)
        .title("My GTK App")
        .child(&button)
        .build();

    // Present window
    window.present();
}

Creating widgets directly from code is perfectly fine. However, with most toolkits you can describe your user interface with a markup language and GTK is no exception here. For example the following xml snippet describes the window widget of the "Hello World!" app.

Filename: listings/interface_builder/1/window.ui

<?xml version="1.0" encoding="UTF-8"?>
<interface>
  <object class="GtkApplicationWindow" id="window">
    <property name="title">My GTK App</property>
    <child>
      <object class="GtkButton" id="button">
        <property name="label">Press me!</property>
        <property name="margin-top">12</property>
        <property name="margin-bottom">12</property>
        <property name="margin-start">12</property>
        <property name="margin-end">12</property>
      </object>
    </child>
  </object>
</interface>

The most outer tag always has to be the <interface>. Then you start listing the elements you want to describe. In our case, we want to have a gtk::ApplicationWindow. These xml files are independent of the programming language, which is why the classes have the original names. Luckily, they all convert like this: gtk::ApplicationWindowGtkApplicationWindow. We want to access the window later on, so we also give it an id. Then we can specify properties which are specified here for ApplicationWindow. Since ApplicationWindow can contain other widgets we use the <child> tag to add a Button.

To instantiate the widgets described by the xml files we use gtk::Builder. All widgets that can be described that way can be found here

Puh, yet another builder? Let us summarize what we have so far:

  • GNOME Builder, an IDE used to create GNOME apps,
  • builder pattern, a design pattern used to create objects with many optional parameters and
  • gtk::Builder, the interface builder which creates widgets from xml files.

That was it with the builders. Promised!

This is how it then looks in practice:

Filename: listings/interface_builder/1/main.rs

use gtk::prelude::*;
use gtk::{Application, ApplicationWindow, Button};

fn main() {
    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Connect to "activate" signal
    app.connect_activate(build_ui);

    // Run the application
    app.run();
}

fn build_ui(app: &Application) {
    // Init `gtk::Builder` from file
    let builder = gtk::Builder::from_string(include_str!("window.ui"));

    // Get window and button from `gtk::Builder`
    let window: ApplicationWindow = builder
        .object("window")
        .expect("Could not get object `window` from builder.");
    let button: Button = builder
        .object("button")
        .expect("Could not get object `button` from builder.");

    // Set application
    window.set_application(Some(app));

    // Connect to "clicked" signal
    button.connect_clicked(move |button| {
        // Set the label to "Hello World!" after the button has been clicked on
        button.set_label("Hello World!");
    });

    // Add button
    window.set_child(Some(&button));
    window.present();
}

This is a bit disappointing. Even though we have already described the UI in the markup file, the amount of code is still pretty much the same. There are still cases where it is valuable to know of the existence of gtk::Builder. We will see for example that ShortcutsWindow is quite a bit easier to instantiate that way.

At least we did not lose any flexibility by using gtk::Builder. It is for example still possible to refer to custom widgets such as this bare-bones CustomButton.

Filename: listings/interface_builder/2/custom_button/imp.rs

use gtk::glib;
use gtk::subclass::prelude::*;

// Object holding the state
#[derive(Default)]
pub struct CustomButton;

// The central trait for subclassing a GObject
#[glib::object_subclass]
impl ObjectSubclass for CustomButton {
    const NAME: &'static str = "MyGtkAppCustomButton";
    type Type = super::CustomButton;
    type ParentType = gtk::Button;
}

// Trait shared by all GObjects
impl ObjectImpl for CustomButton {}

// Trait shared by all widgets
impl WidgetImpl for CustomButton {}

// Trait shared by all buttons
impl ButtonImpl for CustomButton {}

Within the xml file we reference the widget with the NAME we gave it in imp.rs.

Filename: listings/interface_builder/3/window/window.ui

<?xml version="1.0" encoding="UTF-8"?>
<interface>
  <object class="GtkApplicationWindow" id="window">
    <property name="title">My GTK App</property>
    <child>
      <object class="MyGtkAppCustomButton" id="button">
        <property name="label">Press me!</property>
        <property name="margin-top">12</property>
        <property name="margin-bottom">12</property>
        <property name="margin-start">12</property>
        <property name="margin-end">12</property>
      </object>
    </child>
  </object>
</interface>

We also have to make sure to register the custom widget before it is used by the interface builder.

Filename: listings/interface_builder/2/main.rs

mod custom_button;

use gtk::prelude::*;
use gtk::{Application, ApplicationWindow};

use custom_button::CustomButton;

fn main() {
    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Connect to "activate" signal
    app.connect_activate(build_ui);

    // Register custom button
    CustomButton::static_type();

    // Run the application
    app.run();
}

fn build_ui(app: &Application) {
    // Init `gtk::Builder` from file
    let builder = gtk::Builder::from_string(include_str!("window.ui"));

    // Get window and button from `gtk::Builder`
    let window: ApplicationWindow = builder
        .object("window")
        .expect("Could not get object `window` from builder.");
    let button: CustomButton = builder
        .object("button")
        .expect("Could not get object `button` from builder.");

    // Set application
    window.set_application(Some(app));

    // Connect to "clicked" signal
    button.connect_clicked(move |button| {
        // Set the label to "Hello World!" after the button has been clicked on
        button.set_label("Hello World!");
    });

    // Add button
    window.set_child(Some(&button));
    window.present();
}

Composite Templates

The actual reason why we devote a whole chapter to the interface builder is the existence of composite templates. Again, composite templates are described by xml files.

Filename: listings/interface_builder/3/window/window.ui

<?xml version="1.0" encoding="UTF-8"?>
<interface>
  <template class="MyGtkAppWindow" parent="GtkApplicationWindow">
    <property name="title">My GTK App</property>
    <child>
      <object class="MyGtkAppCustomButton" id="button">
        <property name="label">Press me!</property>
        <property name="margin-top">12</property>
        <property name="margin-bottom">12</property>
        <property name="margin-start">12</property>
        <property name="margin-end">12</property>
      </object>
    </child>
  </template>
</interface>

At first glance, the content seems to be nearly the same. Before, we described a pre-existing widget.

<object class="GtkApplicationWindow" id="window">

Now, we create a custom widget and let it inherit from a pre-existing one.

<template class="MyGtkAppWindow" parent="GtkApplicationWindow">

Within our code we create a custom widget inheriting from gtk::ApplicationWindow to make use of our template.

Filename: listings/interface_builder/3/window/mod.rs

mod imp;

use glib::Object;
use gtk::Application;
use gtk::{gio, glib};

glib::wrapper! {
    pub struct Window(ObjectSubclass<imp::Window>)
        @extends gtk::ApplicationWindow, gtk::Window, gtk::Widget,
        @implements gio::ActionGroup, gio::ActionMap, gtk::Accessible, gtk::Buildable,
                    gtk::ConstraintTarget, gtk::Native, gtk::Root, gtk::ShortcutManager;
}

impl Window {
    pub fn new(app: &Application) -> Self {
        // Create new window
        Object::new(&[("application", app)]).expect("Failed to create Window")
    }
}

In the private struct, we then add the derive macro gtk::CompositeTemplate. We also specify that the template information comes from a file window.ui in the same folder.

Filename: listings/interface_builder/3/window/imp.rs

use glib::subclass::InitializingObject;
use gtk::glib;
use gtk::prelude::*;
use gtk::subclass::prelude::*;
use gtk::CompositeTemplate;

use crate::custom_button::CustomButton;

// Object holding the state
#[derive(CompositeTemplate, Default)]
#[template(file = "window.ui")]
pub struct Window {
    #[template_child]
    pub button: TemplateChild<CustomButton>,
}

// The central trait for subclassing a GObject
#[glib::object_subclass]
impl ObjectSubclass for Window {
    // `NAME` needs to match `class` attribute of template
    const NAME: &'static str = "MyGtkAppWindow";
    type Type = super::Window;
    type ParentType = gtk::ApplicationWindow;

    fn class_init(klass: &mut Self::Class) {
        Self::bind_template(klass);
    }

    fn instance_init(obj: &InitializingObject<Self>) {
        obj.init_template();
    }
}

// Trait shared by all GObjects
impl ObjectImpl for Window {
    fn constructed(&self, obj: &Self::Type) {
        // Call "constructed" on parent
        self.parent_constructed(obj);

        // Connect to "clicked" signal of `button`
        self.button.connect_clicked(move |button| {
            // Set the label to "Hello World!" after the button has been clicked on
            button.set_label("Hello World!");
        });
    }
}

// Trait shared by all widgets
impl WidgetImpl for Window {}

// Trait shared by all windows
impl WindowImpl for Window {}

// Trait shared by all application
impl ApplicationWindowImpl for Window {}

One very convenient feature of templates is the template child. You use it by adding a struct member with the same name as one id attribute in the template. Template child then:

  • assures that the widget gets registered without doing it manually in main.rs, and
  • stores a reference to the widget for later use.

We need both for our custom button, so we add it to the struct.

Filename: listings/interface_builder/3/window/imp.rs

use glib::subclass::InitializingObject;
use gtk::glib;
use gtk::prelude::*;
use gtk::subclass::prelude::*;
use gtk::CompositeTemplate;

use crate::custom_button::CustomButton;

// Object holding the state
#[derive(CompositeTemplate, Default)]
#[template(file = "window.ui")]
pub struct Window {
    #[template_child]
    pub button: TemplateChild<CustomButton>,
}

// The central trait for subclassing a GObject
#[glib::object_subclass]
impl ObjectSubclass for Window {
    // `NAME` needs to match `class` attribute of template
    const NAME: &'static str = "MyGtkAppWindow";
    type Type = super::Window;
    type ParentType = gtk::ApplicationWindow;

    fn class_init(klass: &mut Self::Class) {
        Self::bind_template(klass);
    }

    fn instance_init(obj: &InitializingObject<Self>) {
        obj.init_template();
    }
}

// Trait shared by all GObjects
impl ObjectImpl for Window {
    fn constructed(&self, obj: &Self::Type) {
        // Call "constructed" on parent
        self.parent_constructed(obj);

        // Connect to "clicked" signal of `button`
        self.button.connect_clicked(move |button| {
            // Set the label to "Hello World!" after the button has been clicked on
            button.set_label("Hello World!");
        });
    }
}

// Trait shared by all widgets
impl WidgetImpl for Window {}

// Trait shared by all windows
impl WindowImpl for Window {}

// Trait shared by all application
impl ApplicationWindowImpl for Window {}

Within the ObjectSubclass trait, we make sure that NAME corresponds to class in the template and ParentType corresponds to parent in the template. We also bind and initialize the template in class_init and instance_init.

Filename: listings/interface_builder/3/window/imp.rs

use glib::subclass::InitializingObject;
use gtk::glib;
use gtk::prelude::*;
use gtk::subclass::prelude::*;
use gtk::CompositeTemplate;

use crate::custom_button::CustomButton;

// Object holding the state
#[derive(CompositeTemplate, Default)]
#[template(file = "window.ui")]
pub struct Window {
    #[template_child]
    pub button: TemplateChild<CustomButton>,
}

// The central trait for subclassing a GObject
#[glib::object_subclass]
impl ObjectSubclass for Window {
    // `NAME` needs to match `class` attribute of template
    const NAME: &'static str = "MyGtkAppWindow";
    type Type = super::Window;
    type ParentType = gtk::ApplicationWindow;

    fn class_init(klass: &mut Self::Class) {
        Self::bind_template(klass);
    }

    fn instance_init(obj: &InitializingObject<Self>) {
        obj.init_template();
    }
}

// Trait shared by all GObjects
impl ObjectImpl for Window {
    fn constructed(&self, obj: &Self::Type) {
        // Call "constructed" on parent
        self.parent_constructed(obj);

        // Connect to "clicked" signal of `button`
        self.button.connect_clicked(move |button| {
            // Set the label to "Hello World!" after the button has been clicked on
            button.set_label("Hello World!");
        });
    }
}

// Trait shared by all widgets
impl WidgetImpl for Window {}

// Trait shared by all windows
impl WindowImpl for Window {}

// Trait shared by all application
impl ApplicationWindowImpl for Window {}

Finally, we connect the callback to the "clicked" signal of button within constructed. The button is easily available thanks to the stored reference in self.

Filename: listings/interface_builder/3/main.rs

pub mod custom_button;
mod window;

use gtk::prelude::*;
use gtk::Application;

use window::Window;

fn main() {
    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Connect to "activate" signal of `app`
    app.connect_activate(build_ui);

    // Run the application
    app.run();
}

fn build_ui(app: &Application) {
    // Create new window and present it
    let window = Window::new(app);
    window.present();
}

With composite templates, main.rs actually became more concise. With regard to capabilities, we also get the best of both worlds.

Conclusion

Thanks to custom widgets we can

  • keep state and part of it as properties,
  • add signals as well as
  • override behavior.

Thanks to composite templates we can

  • describe complex user interfaces concisely, and
  • easily access widgets within the template.

The API of the interface builder is extensive so especially at the beginning you will want to check out the documentation. The basic syntax is explained with Builder, syntax specific to widgets with Widget. If a certain widget accepts additional element, then they are typically explained in the docs of the widget.

In the following chapter, we will see how composite templates help us to create slightly bigger apps such as a To-Do app.

Building a Simple To-Do App

After we have learned so many concepts, it is finally time to put them into practice. We are going to build a To-Do app!

For now, we would already be satisfied with a minimal version. An entry to input new tasks and a list view to display them will suffice. Something like this:

Window

This mockup can be described by the following composite template.

Filename: listings/todo_app/1/window/window.ui

<?xml version="1.0" encoding="UTF-8"?>
<interface>
  <template class="TodoWindow" parent="GtkApplicationWindow">
    <property name="width-request">360</property>
    <property name="title" translatable="yes">To-Do</property>
    <child>
      <object class="GtkBox">
        <property name="orientation">vertical</property>
        <property name="margin-top">12</property>
        <property name="margin-bottom">12</property>
        <property name="margin-start">12</property>
        <property name="margin-end">12</property>
        <property name="spacing">6</property>
        <child>
          <object class="GtkEntry" id="entry"/>
        </child>
        <child>
          <object class="GtkScrolledWindow">
            <property name="hscrollbar-policy">never</property>
            <property name="min-content-height">360</property>
            <property name="vexpand">true</property>
            <child>
              <object class="GtkListView" id="list_view"/>
            </child>
          </object>
        </child>
      </object>
    </child>
  </template>
</interface>

In order to use the composite template, we create a custom widget. The parent is gtk::ApplicationWindow, so we inherit from it. As usual, we have to list all ancestors and interfaces apart from GObject and GInitiallyUnowned.

Filename: listings/todo_app/1/window/mod.rs

mod imp;

use crate::todo_object::TodoObject;
use crate::todo_row::TodoRow;
use glib::{clone, Object};
use gtk::prelude::*;
use gtk::subclass::prelude::*;
use gtk::{gio, glib};
use gtk::{Application, NoSelection, SignalListItemFactory};

glib::wrapper! {
    pub struct Window(ObjectSubclass<imp::Window>)
        @extends gtk::ApplicationWindow, gtk::Window, gtk::Widget,
        @implements gio::ActionGroup, gio::ActionMap, gtk::Accessible, gtk::Buildable,
                    gtk::ConstraintTarget, gtk::Native, gtk::Root, gtk::ShortcutManager;
}

impl Window {
    pub fn new(app: &Application) -> Self {
        // Create new window
        Object::new(&[("application", app)]).expect("Failed to create `Window`.")
    }

    fn model(&self) -> &gio::ListStore {
        // Get state
        let imp = self.imp();
        imp.model.get().expect("Could not get model")
    }

    fn setup_model(&self) {
        // Create new model
        let model = gio::ListStore::new(TodoObject::static_type());

        // Get state and set model
        let imp = self.imp();
        imp.model.set(model).expect("Could not set model");

        // Wrap model with selection and pass it to the list view
        let selection_model = NoSelection::new(Some(self.model()));
        imp.list_view.set_model(Some(&selection_model));
    }

    fn setup_callbacks(&self) {
        // Get state
        let imp = self.imp();
        let model = self.model();

        // Setup callback so that activation
        // creates a new todo object and clears the entry
        imp.entry
            .connect_activate(clone!(@weak model => move |entry| {
                let buffer = entry.buffer();
                let content = buffer.text();
                let todo_object = TodoObject::new(false, content);
                model.append(&todo_object);
                buffer.set_text("");
            }));
    }

    fn setup_factory(&self) {
        // Create a new factory
        let factory = SignalListItemFactory::new();

        // Create an empty `TodoRow` during setup
        factory.connect_setup(move |_, list_item| {
            // Create `TodoRow`
            let todo_row = TodoRow::new();
            list_item.set_child(Some(&todo_row));
        });

        // Tell factory how to bind `TodoRow` to a `TodoObject`
        factory.connect_bind(move |_, list_item| {
            // Get `TodoObject` from `ListItem`
            let todo_object = list_item
                .item()
                .expect("The item has to exist.")
                .downcast::<TodoObject>()
                .expect("The item has to be an `TodoObject`.");

            // Get `TodoRow` from `ListItem`
            let todo_row = list_item
                .child()
                .expect("The child has to exist.")
                .downcast::<TodoRow>()
                .expect("The child has to be a `TodoRow`.");

            todo_row.bind(&todo_object);
        });

        // Tell factory how to unbind `TodoRow` from `TodoObject`
        factory.connect_unbind(move |_, list_item| {
            // Get `TodoRow` from `ListItem`
            let todo_row = list_item
                .child()
                .expect("The child has to exist.")
                .downcast::<TodoRow>()
                .expect("The child has to be a `TodoRow`.");

            todo_row.unbind();
        });

        // Set the factory of the list view
        let imp = self.imp();
        imp.list_view.set_factory(Some(&factory));
    }
}

Then we initialize the composite template for imp::Window. We store references to the entry, the list view as well as the list model. This will come in handy when we later add methods to our window. After that, we add the typical boilerplate for initializing composite templates. We only have to assure that the class attribute of the template in window.ui matches NAME.

Filename: listings/todo_app/1/window/imp.rs

use glib::subclass::InitializingObject;
use gtk::prelude::*;
use gtk::subclass::prelude::*;
use gtk::{gio, glib};
use gtk::{CompositeTemplate, Entry, ListView};
use once_cell::sync::OnceCell;

// Object holding the state
#[derive(CompositeTemplate, Default)]
#[template(file = "window.ui")]
pub struct Window {
    #[template_child]
    pub entry: TemplateChild<Entry>,
    #[template_child]
    pub list_view: TemplateChild<ListView>,
    pub model: OnceCell<gio::ListStore>,
}

// The central trait for subclassing a GObject
#[glib::object_subclass]
impl ObjectSubclass for Window {
    // `NAME` needs to match `class` attribute of template
    const NAME: &'static str = "TodoWindow";
    type Type = super::Window;
    type ParentType = gtk::ApplicationWindow;

    fn class_init(klass: &mut Self::Class) {
        Self::bind_template(klass);
    }

    fn instance_init(obj: &InitializingObject<Self>) {
        obj.init_template();
    }
}

// Trait shared by all GObjects
impl ObjectImpl for Window {
    fn constructed(&self, obj: &Self::Type) {
        // Call "constructed" on parent
        self.parent_constructed(obj);

        // Setup
        obj.setup_model();
        obj.setup_callbacks();
        obj.setup_factory();
    }
}

// Trait shared by all widgets
impl WidgetImpl for Window {}

// Trait shared by all windows
impl WindowImpl for Window {}

// Trait shared by all application
impl ApplicationWindowImpl for Window {}

main.rs also does not hold any surprises for us.

Filename: listings/todo_app/1/main.rs

mod todo_object;
mod todo_row;
mod window;

use gtk::prelude::*;
use gtk::Application;

use window::Window;

fn main() {
    // Initialize logger
    pretty_env_logger::init();

    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.Todo")
        .build();

    // Connect to "activate" signal of `app`
    app.connect_activate(build_ui);

    // Run the application
    app.run();
}

fn build_ui(app: &Application) {
    // Create a new custom window and show it
    let window = Window::new(app);
    window.present();
}

To-Do Object

So far so good. The main user interface is done, but the entry does not react to input yet. Also, where would the input go? We have not even set up the list model yet. Let us do that!

As discussed in the list widgets chapter, we start out by creating a custom GObject. This object will store the state of the task consisting of:

  • a boolean describing whether the task is completed or not, and
  • a string holding the task name.

Filename: listings/todo_app/1/todo_object/mod.rs

mod imp;

use glib::Object;
use gtk::glib;

glib::wrapper! {
    pub struct TodoObject(ObjectSubclass<imp::TodoObject>);
}

impl TodoObject {
    pub fn new(completed: bool, content: String) -> Self {
        Object::new(&[("completed", &completed), ("content", &content)])
            .expect("Failed to create `TodoObject`.")
    }
}

#[derive(Default)]
pub struct TodoData {
    pub completed: bool,
    pub content: String,
}

Unlike the lists chapter, the state is stored in a struct rather than in individual members of imp::TodoObject. This will be very convenient when saving the state in one of the following chapters.

Filename: listings/todo_app/1/todo_object/mod.rs

mod imp;

use glib::Object;
use gtk::glib;

glib::wrapper! {
    pub struct TodoObject(ObjectSubclass<imp::TodoObject>);
}

impl TodoObject {
    pub fn new(completed: bool, content: String) -> Self {
        Object::new(&[("completed", &completed), ("content", &content)])
            .expect("Failed to create `TodoObject`.")
    }
}

#[derive(Default)]
pub struct TodoData {
    pub completed: bool,
    pub content: String,
}

Exposing completed and content as properties does not become much different that way, so we will not discuss it further. If you are curious, you can press on the small eye symbol on the top right of the code snippet to read the implementation.

Filename: listings/todo_app/1/todo_object/imp.rs

use glib::{ParamFlags, ParamSpec, ParamSpecBoolean, ParamSpecString, Value};
use gtk::glib;
use gtk::prelude::*;
use gtk::subclass::prelude::*;

use once_cell::sync::Lazy;
use std::cell::RefCell;
use std::rc::Rc;

use super::TodoData;

// Object holding the state
#[derive(Default)]
pub struct TodoObject {
    pub data: Rc<RefCell<TodoData>>,
}

// The central trait for subclassing a GObject
#[glib::object_subclass]
impl ObjectSubclass for TodoObject {
    const NAME: &'static str = "TodoObject";
    type Type = super::TodoObject;
}

// Trait shared by all GObjects
impl ObjectImpl for TodoObject {
    fn properties() -> &'static [ParamSpec] {
        static PROPERTIES: Lazy<Vec<ParamSpec>> = Lazy::new(|| {
            vec![
                ParamSpecBoolean::new(
                    // Name
                    "completed",
                    // Nickname
                    "completed",
                    // Short description
                    "completed",
                    // Default value
                    false,
                    // The property can be read and written to
                    ParamFlags::READWRITE,
                ),
                ParamSpecString::new(
                    // Name
                    "content",
                    // Nickname
                    "content",
                    // Short description
                    "content",
                    // Default value
                    None,
                    // The property can be read and written to
                    ParamFlags::READWRITE,
                ),
            ]
        });
        PROPERTIES.as_ref()
    }

    fn set_property(&self, _obj: &Self::Type, _id: usize, value: &Value, pspec: &ParamSpec) {
        match pspec.name() {
            "completed" => {
                let input_value = value.get().expect("The value needs to be of type `bool`.");
                self.data.borrow_mut().completed = input_value;
            }
            "content" => {
                let input_value = value
                    .get()
                    .expect("The value needs to be of type `String`.");
                self.data.borrow_mut().content = input_value;
            }
            _ => unimplemented!(),
        }
    }

    fn property(&self, _obj: &Self::Type, _id: usize, pspec: &ParamSpec) -> Value {
        match pspec.name() {
            "completed" => self.data.borrow().completed.to_value(),
            "content" => self.data.borrow().content.to_value(),
            _ => unimplemented!(),
        }
    }
}

To-Do Row

Let us move on to the individual tasks. The row of a task should look like this:

Again, we describe the mockup with a composite template.

Filename: listings/todo_app/1/todo_row/todo_row.ui

<?xml version="1.0" encoding="UTF-8"?>
<interface>
  <template class="TodoRow" parent="GtkBox">
    <child>
      <object class="GtkCheckButton" id="completed_button">
        <property name="margin-top">12</property>
        <property name="margin-bottom">12</property>
        <property name="margin-start">12</property>
        <property name="margin-end">12</property>
      </object>
    </child>
    <child>
      <object class="GtkLabel" id="content_label">
        <property name="margin-top">12</property>
        <property name="margin-bottom">12</property>
        <property name="margin-start">12</property>
        <property name="margin-end">12</property>
      </object>
    </child>
  </template>
</interface>

In the code, we derive TodoRow from gtk:Box:

Filename: listings/todo_app/1/todo_row/mod.rs

mod imp;

use crate::todo_object::TodoObject;
use glib::{BindingFlags, Object};
use gtk::prelude::*;
use gtk::subclass::prelude::*;
use gtk::{glib, pango};
use pango::{AttrInt, AttrList};

glib::wrapper! {
    pub struct TodoRow(ObjectSubclass<imp::TodoRow>)
    @extends gtk::Box, gtk::Widget,
    @implements gtk::Accessible, gtk::Buildable, gtk::ConstraintTarget, gtk::Orientable;
}

impl Default for TodoRow {
    fn default() -> Self {
        Self::new()
    }
}

impl TodoRow {
    pub fn new() -> Self {
        Object::new(&[]).expect("Failed to create `TodoRow`.")
    }

    pub fn bind(&self, todo_object: &TodoObject) {
        // Get state
        let imp = self.imp();
        let completed_button = imp.completed_button.get();
        let content_label = imp.content_label.get();
        let mut bindings = imp.bindings.borrow_mut();

        // Bind `todo_object.completed` to `todo_row.completed_button.active`
        let completed_button_binding = todo_object
            .bind_property("completed", &completed_button, "active")
            .flags(BindingFlags::SYNC_CREATE | BindingFlags::BIDIRECTIONAL)
            .build();
        // Save binding
        bindings.push(completed_button_binding);

        // Bind `todo_object.content` to `todo_row.content_label.label`
        let content_label_binding = todo_object
            .bind_property("content", &content_label, "label")
            .flags(BindingFlags::SYNC_CREATE)
            .build();
        // Save binding
        bindings.push(content_label_binding);

        // Bind `todo_object.completed` to `todo_row.content_label.attributes`
        let content_label_binding = todo_object
            .bind_property("completed", &content_label, "attributes")
            .flags(BindingFlags::SYNC_CREATE)
            .transform_to(|_, active_value| {
                let attribute_list = AttrList::new();
                let active = active_value
                    .get::<bool>()
                    .expect("The value needs to be of type `bool`.");
                if active {
                    // If "active" is true, content of the label will be strikethrough
                    let attribute = AttrInt::new_strikethrough(true);
                    attribute_list.insert(attribute);
                }
                Some(attribute_list.to_value())
            })
            .build();
        // Save binding
        bindings.push(content_label_binding);
    }

    pub fn unbind(&self) {
        // Get state
        let imp = self.imp();

        // Unbind all stored bindings
        for binding in imp.bindings.borrow_mut().drain(..) {
            binding.unbind();
        }
    }
}

In imp::TodoRow, we hold references to completed_button and content_label. We also store a mutable vector of bindings. Why we need that will become clear as soon as we get to bind the state of TodoObject to the corresponding TodoRow.

Filename: listings/todo_app/1/todo_row/imp.rs

use glib::Binding;
use gtk::prelude::*;
use gtk::subclass::prelude::*;
use gtk::{glib, CheckButton, CompositeTemplate, Label};
use std::cell::RefCell;

// Object holding the state
#[derive(Default, CompositeTemplate)]
#[template(file = "todo_row.ui")]
pub struct TodoRow {
    #[template_child]
    pub completed_button: TemplateChild<CheckButton>,
    #[template_child]
    pub content_label: TemplateChild<Label>,
    // Vector holding the bindings to properties of `TodoObject`
    pub bindings: RefCell<Vec<Binding>>,
}

// The central trait for subclassing a GObject
#[glib::object_subclass]
impl ObjectSubclass for TodoRow {
    // `NAME` needs to match `class` attribute of template
    const NAME: &'static str = "TodoRow";
    type Type = super::TodoRow;
    type ParentType = gtk::Box;

    fn class_init(klass: &mut Self::Class) {
        Self::bind_template(klass);
    }

    fn instance_init(obj: &glib::subclass::InitializingObject<Self>) {
        obj.init_template();
    }
}

// Trait shared by all GObjects
impl ObjectImpl for TodoRow {}

// Trait shared by all widgets
impl WidgetImpl for TodoRow {}

// Trait shared by all boxes
impl BoxImpl for TodoRow {}

Now we can bring everything together. We override the imp::Window::constructed in order to set up window contents at the time of its construction.

Filename: listings/todo_app/1/window/imp.rs

use glib::subclass::InitializingObject;
use gtk::prelude::*;
use gtk::subclass::prelude::*;
use gtk::{gio, glib};
use gtk::{CompositeTemplate, Entry, ListView};
use once_cell::sync::OnceCell;

// Object holding the state
#[derive(CompositeTemplate, Default)]
#[template(file = "window.ui")]
pub struct Window {
    #[template_child]
    pub entry: TemplateChild<Entry>,
    #[template_child]
    pub list_view: TemplateChild<ListView>,
    pub model: OnceCell<gio::ListStore>,
}

// The central trait for subclassing a GObject
#[glib::object_subclass]
impl ObjectSubclass for Window {
    // `NAME` needs to match `class` attribute of template
    const NAME: &'static str = "TodoWindow";
    type Type = super::Window;
    type ParentType = gtk::ApplicationWindow;

    fn class_init(klass: &mut Self::Class) {
        Self::bind_template(klass);
    }

    fn instance_init(obj: &InitializingObject<Self>) {
        obj.init_template();
    }
}

// Trait shared by all GObjects
impl ObjectImpl for Window {
    fn constructed(&self, obj: &Self::Type) {
        // Call "constructed" on parent
        self.parent_constructed(obj);

        // Setup
        obj.setup_model();
        obj.setup_callbacks();
        obj.setup_factory();
    }
}

// Trait shared by all widgets
impl WidgetImpl for Window {}

// Trait shared by all windows
impl WindowImpl for Window {}

// Trait shared by all application
impl ApplicationWindowImpl for Window {}

Since we need to access the list model quite often, we add the convenience method Window::model for that. In Window::setup_model we create a new model. Then we store a reference to the model in imp::Window as well as in gtk::ListView.

Filename: listings/todo_app/1/window/mod.rs

mod imp;

use crate::todo_object::TodoObject;
use crate::todo_row::TodoRow;
use glib::{clone, Object};
use gtk::prelude::*;
use gtk::subclass::prelude::*;
use gtk::{gio, glib};
use gtk::{Application, NoSelection, SignalListItemFactory};

glib::wrapper! {
    pub struct Window(ObjectSubclass<imp::Window>)
        @extends gtk::ApplicationWindow, gtk::Window, gtk::Widget,
        @implements gio::ActionGroup, gio::ActionMap, gtk::Accessible, gtk::Buildable,
                    gtk::ConstraintTarget, gtk::Native, gtk::Root, gtk::ShortcutManager;
}

impl Window {
    pub fn new(app: &Application) -> Self {
        // Create new window
        Object::new(&[("application", app)]).expect("Failed to create `Window`.")
    }

    fn model(&self) -> &gio::ListStore {
        // Get state
        let imp = self.imp();
        imp.model.get().expect("Could not get model")
    }

    fn setup_model(&self) {
        // Create new model
        let model = gio::ListStore::new(TodoObject::static_type());

        // Get state and set model
        let imp = self.imp();
        imp.model.set(model).expect("Could not set model");

        // Wrap model with selection and pass it to the list view
        let selection_model = NoSelection::new(Some(self.model()));
        imp.list_view.set_model(Some(&selection_model));
    }

    fn setup_callbacks(&self) {
        // Get state
        let imp = self.imp();
        let model = self.model();

        // Setup callback so that activation
        // creates a new todo object and clears the entry
        imp.entry
            .connect_activate(clone!(@weak model => move |entry| {
                let buffer = entry.buffer();
                let content = buffer.text();
                let todo_object = TodoObject::new(false, content);
                model.append(&todo_object);
                buffer.set_text("");
            }));
    }

    fn setup_factory(&self) {
        // Create a new factory
        let factory = SignalListItemFactory::new();

        // Create an empty `TodoRow` during setup
        factory.connect_setup(move |_, list_item| {
            // Create `TodoRow`
            let todo_row = TodoRow::new();
            list_item.set_child(Some(&todo_row));
        });

        // Tell factory how to bind `TodoRow` to a `TodoObject`
        factory.connect_bind(move |_, list_item| {
            // Get `TodoObject` from `ListItem`
            let todo_object = list_item
                .item()
                .expect("The item has to exist.")
                .downcast::<TodoObject>()
                .expect("The item has to be an `TodoObject`.");

            // Get `TodoRow` from `ListItem`
            let todo_row = list_item
                .child()
                .expect("The child has to exist.")
                .downcast::<TodoRow>()
                .expect("The child has to be a `TodoRow`.");

            todo_row.bind(&todo_object);
        });

        // Tell factory how to unbind `TodoRow` from `TodoObject`
        factory.connect_unbind(move |_, list_item| {
            // Get `TodoRow` from `ListItem`
            let todo_row = list_item
                .child()
                .expect("The child has to exist.")
                .downcast::<TodoRow>()
                .expect("The child has to be a `TodoRow`.");

            todo_row.unbind();
        });

        // Set the factory of the list view
        let imp = self.imp();
        imp.list_view.set_factory(Some(&factory));
    }
}

In Window::setup_callbacks we connect to the "activate" signal of the entry. This signal is triggered when we press the enter key in the entry. Then a new TodoObject with the content will be created and appended to the model. Finally, the entry will be cleared.

Filename: listings/todo_app/1/window/mod.rs

mod imp;

use crate::todo_object::TodoObject;
use crate::todo_row::TodoRow;
use glib::{clone, Object};
use gtk::prelude::*;
use gtk::subclass::prelude::*;
use gtk::{gio, glib};
use gtk::{Application, NoSelection, SignalListItemFactory};

glib::wrapper! {
    pub struct Window(ObjectSubclass<imp::Window>)
        @extends gtk::ApplicationWindow, gtk::Window, gtk::Widget,
        @implements gio::ActionGroup, gio::ActionMap, gtk::Accessible, gtk::Buildable,
                    gtk::ConstraintTarget, gtk::Native, gtk::Root, gtk::ShortcutManager;
}

impl Window {
    pub fn new(app: &Application) -> Self {
        // Create new window
        Object::new(&[("application", app)]).expect("Failed to create `Window`.")
    }

    fn model(&self) -> &gio::ListStore {
        // Get state
        let imp = self.imp();
        imp.model.get().expect("Could not get model")
    }

    fn setup_model(&self) {
        // Create new model
        let model = gio::ListStore::new(TodoObject::static_type());

        // Get state and set model
        let imp = self.imp();
        imp.model.set(model).expect("Could not set model");

        // Wrap model with selection and pass it to the list view
        let selection_model = NoSelection::new(Some(self.model()));
        imp.list_view.set_model(Some(&selection_model));
    }

    fn setup_callbacks(&self) {
        // Get state
        let imp = self.imp();
        let model = self.model();

        // Setup callback so that activation
        // creates a new todo object and clears the entry
        imp.entry
            .connect_activate(clone!(@weak model => move |entry| {
                let buffer = entry.buffer();
                let content = buffer.text();
                let todo_object = TodoObject::new(false, content);
                model.append(&todo_object);
                buffer.set_text("");
            }));
    }

    fn setup_factory(&self) {
        // Create a new factory
        let factory = SignalListItemFactory::new();

        // Create an empty `TodoRow` during setup
        factory.connect_setup(move |_, list_item| {
            // Create `TodoRow`
            let todo_row = TodoRow::new();
            list_item.set_child(Some(&todo_row));
        });

        // Tell factory how to bind `TodoRow` to a `TodoObject`
        factory.connect_bind(move |_, list_item| {
            // Get `TodoObject` from `ListItem`
            let todo_object = list_item
                .item()
                .expect("The item has to exist.")
                .downcast::<TodoObject>()
                .expect("The item has to be an `TodoObject`.");

            // Get `TodoRow` from `ListItem`
            let todo_row = list_item
                .child()
                .expect("The child has to exist.")
                .downcast::<TodoRow>()
                .expect("The child has to be a `TodoRow`.");

            todo_row.bind(&todo_object);
        });

        // Tell factory how to unbind `TodoRow` from `TodoObject`
        factory.connect_unbind(move |_, list_item| {
            // Get `TodoRow` from `ListItem`
            let todo_row = list_item
                .child()
                .expect("The child has to exist.")
                .downcast::<TodoRow>()
                .expect("The child has to be a `TodoRow`.");

            todo_row.unbind();
        });

        // Set the factory of the list view
        let imp = self.imp();
        imp.list_view.set_factory(Some(&factory));
    }
}

The list elements for the gtk::ListView are produced by a factory. Before we move on to the implementation, let us take a step back and think about which behavior we expect here. content_label of TodoRow should follow content of TodoObject. We also want completed_button of TodoRow follow completed of TodoObject. This could be achieved with expressions similar to what we did in the lists chapter.

However, if we toggle the state of completed_button of TodoRow, completed of TodoObject should change too. Unfortunately, expressions cannot handle bidirectional relationships. This means we have to use property bindings. We will need to unbind them manually when they are no longer needed.

We will create empty TodoRow objects in the "setup" step in Window::setup_factory and deal with binding in the "bind" and "unbind" steps.

Filename: listings/todo_app/1/window/mod.rs

mod imp;

use crate::todo_object::TodoObject;
use crate::todo_row::TodoRow;
use glib::{clone, Object};
use gtk::prelude::*;
use gtk::subclass::prelude::*;
use gtk::{gio, glib};
use gtk::{Application, NoSelection, SignalListItemFactory};

glib::wrapper! {
    pub struct Window(ObjectSubclass<imp::Window>)
        @extends gtk::ApplicationWindow, gtk::Window, gtk::Widget,
        @implements gio::ActionGroup, gio::ActionMap, gtk::Accessible, gtk::Buildable,
                    gtk::ConstraintTarget, gtk::Native, gtk::Root, gtk::ShortcutManager;
}

impl Window {
    pub fn new(app: &Application) -> Self {
        // Create new window
        Object::new(&[("application", app)]).expect("Failed to create `Window`.")
    }

    fn model(&self) -> &gio::ListStore {
        // Get state
        let imp = self.imp();
        imp.model.get().expect("Could not get model")
    }

    fn setup_model(&self) {
        // Create new model
        let model = gio::ListStore::new(TodoObject::static_type());

        // Get state and set model
        let imp = self.imp();
        imp.model.set(model).expect("Could not set model");

        // Wrap model with selection and pass it to the list view
        let selection_model = NoSelection::new(Some(self.model()));
        imp.list_view.set_model(Some(&selection_model));
    }

    fn setup_callbacks(&self) {
        // Get state
        let imp = self.imp();
        let model = self.model();

        // Setup callback so that activation
        // creates a new todo object and clears the entry
        imp.entry
            .connect_activate(clone!(@weak model => move |entry| {
                let buffer = entry.buffer();
                let content = buffer.text();
                let todo_object = TodoObject::new(false, content);
                model.append(&todo_object);
                buffer.set_text("");
            }));
    }

    fn setup_factory(&self) {
        // Create a new factory
        let factory = SignalListItemFactory::new();

        // Create an empty `TodoRow` during setup
        factory.connect_setup(move |_, list_item| {
            // Create `TodoRow`
            let todo_row = TodoRow::new();
            list_item.set_child(Some(&todo_row));
        });

        // Tell factory how to bind `TodoRow` to a `TodoObject`
        factory.connect_bind(move |_, list_item| {
            // Get `TodoObject` from `ListItem`
            let todo_object = list_item
                .item()
                .expect("The item has to exist.")
                .downcast::<TodoObject>()
                .expect("The item has to be an `TodoObject`.");

            // Get `TodoRow` from `ListItem`
            let todo_row = list_item
                .child()
                .expect("The child has to exist.")
                .downcast::<TodoRow>()
                .expect("The child has to be a `TodoRow`.");

            todo_row.bind(&todo_object);
        });

        // Tell factory how to unbind `TodoRow` from `TodoObject`
        factory.connect_unbind(move |_, list_item| {
            // Get `TodoRow` from `ListItem`
            let todo_row = list_item
                .child()
                .expect("The child has to exist.")
                .downcast::<TodoRow>()
                .expect("The child has to be a `TodoRow`.");

            todo_row.unbind();
        });

        // Set the factory of the list view
        let imp = self.imp();
        imp.list_view.set_factory(Some(&factory));
    }
}

Binding properties in TodoRow::bind works just like in former chapters. The only difference is that we store the bindings in a vector. This is necessary because a TodoRow will be reused as you scroll through the list. That means that over time a TodoRow will need to bound to a new TodoObject and has to be unbound from the old one. Unbinding will only work if it can access the stored glib::Binding.

Filename: listings/todo_app/1/todo_row/mod.rs

mod imp;

use crate::todo_object::TodoObject;
use glib::{BindingFlags, Object};
use gtk::prelude::*;
use gtk::subclass::prelude::*;
use gtk::{glib, pango};
use pango::{AttrInt, AttrList};

glib::wrapper! {
    pub struct TodoRow(ObjectSubclass<imp::TodoRow>)
    @extends gtk::Box, gtk::Widget,
    @implements gtk::Accessible, gtk::Buildable, gtk::ConstraintTarget, gtk::Orientable;
}

impl Default for TodoRow {
    fn default() -> Self {
        Self::new()
    }
}

impl TodoRow {
    pub fn new() -> Self {
        Object::new(&[]).expect("Failed to create `TodoRow`.")
    }

    pub fn bind(&self, todo_object: &TodoObject) {
        // Get state
        let imp = self.imp();
        let completed_button = imp.completed_button.get();
        let content_label = imp.content_label.get();
        let mut bindings = imp.bindings.borrow_mut();

        // Bind `todo_object.completed` to `todo_row.completed_button.active`
        let completed_button_binding = todo_object
            .bind_property("completed", &completed_button, "active")
            .flags(BindingFlags::SYNC_CREATE | BindingFlags::BIDIRECTIONAL)
            .build();
        // Save binding
        bindings.push(completed_button_binding);

        // Bind `todo_object.content` to `todo_row.content_label.label`
        let content_label_binding = todo_object
            .bind_property("content", &content_label, "label")
            .flags(BindingFlags::SYNC_CREATE)
            .build();
        // Save binding
        bindings.push(content_label_binding);

        // Bind `todo_object.completed` to `todo_row.content_label.attributes`
        let content_label_binding = todo_object
            .bind_property("completed", &content_label, "attributes")
            .flags(BindingFlags::SYNC_CREATE)
            .transform_to(|_, active_value| {
                let attribute_list = AttrList::new();
                let active = active_value
                    .get::<bool>()
                    .expect("The value needs to be of type `bool`.");
                if active {
                    // If "active" is true, content of the label will be strikethrough
                    let attribute = AttrInt::new_strikethrough(true);
                    attribute_list.insert(attribute);
                }
                Some(attribute_list.to_value())
            })
            .build();
        // Save binding
        bindings.push(content_label_binding);
    }

    pub fn unbind(&self) {
        // Get state
        let imp = self.imp();

        // Unbind all stored bindings
        for binding in imp.bindings.borrow_mut().drain(..) {
            binding.unbind();
        }
    }
}

TodoRow::unbind takes care of the cleanup. It iterates through the vector and unbinds each binding. In the end, it clears the vector.

Filename: listings/todo_app/1/todo_row/mod.rs

mod imp;

use crate::todo_object::TodoObject;
use glib::{BindingFlags, Object};
use gtk::prelude::*;
use gtk::subclass::prelude::*;
use gtk::{glib, pango};
use pango::{AttrInt, AttrList};

glib::wrapper! {
    pub struct TodoRow(ObjectSubclass<imp::TodoRow>)
    @extends gtk::Box, gtk::Widget,
    @implements gtk::Accessible, gtk::Buildable, gtk::ConstraintTarget, gtk::Orientable;
}

impl Default for TodoRow {
    fn default() -> Self {
        Self::new()
    }
}

impl TodoRow {
    pub fn new() -> Self {
        Object::new(&[]).expect("Failed to create `TodoRow`.")
    }

    pub fn bind(&self, todo_object: &TodoObject) {
        // Get state
        let imp = self.imp();
        let completed_button = imp.completed_button.get();
        let content_label = imp.content_label.get();
        let mut bindings = imp.bindings.borrow_mut();

        // Bind `todo_object.completed` to `todo_row.completed_button.active`
        let completed_button_binding = todo_object
            .bind_property("completed", &completed_button, "active")
            .flags(BindingFlags::SYNC_CREATE | BindingFlags::BIDIRECTIONAL)
            .build();
        // Save binding
        bindings.push(completed_button_binding);

        // Bind `todo_object.content` to `todo_row.content_label.label`
        let content_label_binding = todo_object
            .bind_property("content", &content_label, "label")
            .flags(BindingFlags::SYNC_CREATE)
            .build();
        // Save binding
        bindings.push(content_label_binding);

        // Bind `todo_object.completed` to `todo_row.content_label.attributes`
        let content_label_binding = todo_object
            .bind_property("completed", &content_label, "attributes")
            .flags(BindingFlags::SYNC_CREATE)
            .transform_to(|_, active_value| {
                let attribute_list = AttrList::new();
                let active = active_value
                    .get::<bool>()
                    .expect("The value needs to be of type `bool`.");
                if active {
                    // If "active" is true, content of the label will be strikethrough
                    let attribute = AttrInt::new_strikethrough(true);
                    attribute_list.insert(attribute);
                }
                Some(attribute_list.to_value())
            })
            .build();
        // Save binding
        bindings.push(content_label_binding);
    }

    pub fn unbind(&self) {
        // Get state
        let imp = self.imp();

        // Unbind all stored bindings
        for binding in imp.bindings.borrow_mut().drain(..) {
            binding.unbind();
        }
    }
}

That was it, we created a basic To-Do app! We will extend it with additional functionality in the following chapters.

Actions

By now, we have already learned many ways to glue our widgets together. We can send messages through channels, emit signals, share reference-counted state and bind properties. Now, we will complete our set by learning about actions.

An action is a piece of functionality bound to a certain GObject. Let us check out the simplest case where we activate an action without a parameter.

Filename: listings/actions/1/main.rs

use gio::SimpleAction;
use glib::clone;
use gtk::prelude::*;
use gtk::{gio, glib};
use gtk::{Application, ApplicationWindow};

fn main() {
    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Connect to "activate" signal of `app`
    app.connect_activate(build_ui);

    // Set keyboard accelerator to trigger "win.close".
    app.set_accels_for_action("win.close", &["<primary>W"]);

    // Run the application
    app.run();
}

fn build_ui(app: &Application) {
    // Create a window and set the title
    let window = ApplicationWindow::builder()
        .application(app)
        .title("My GTK App")
        .width_request(360)
        .build();

    // Add action "close" to `window` taking no parameter
    let action_close = SimpleAction::new("close", None);
    action_close.connect_activate(clone!(@weak window => move |_, _| {
        window.close();
    }));
    window.add_action(&action_close);

    // Present window
    window.present();
}

First, we created a new gio::SimpleAction which is named "close" and takes no parameter. We also connected a callback which closes the window.

Filename: listings/actions/1/main.rs

use gio::SimpleAction;
use glib::clone;
use gtk::prelude::*;
use gtk::{gio, glib};
use gtk::{Application, ApplicationWindow};

fn main() {
    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Connect to "activate" signal of `app`
    app.connect_activate(build_ui);

    // Set keyboard accelerator to trigger "win.close".
    app.set_accels_for_action("win.close", &["<primary>W"]);

    // Run the application
    app.run();
}

fn build_ui(app: &Application) {
    // Create a window and set the title
    let window = ApplicationWindow::builder()
        .application(app)
        .title("My GTK App")
        .width_request(360)
        .build();

    // Add action "close" to `window` taking no parameter
    let action_close = SimpleAction::new("close", None);
    action_close.connect_activate(clone!(@weak window => move |_, _| {
        window.close();
    }));
    window.add_action(&action_close);

    // Present window
    window.present();
}

One of the most popular reasons to use actions are keyboard accelerators, so we added one here. With set_accels_for_action one can assign one or more accelerators to a certain action. Check the documentation of accelerator_parse in order to learn more about its syntax. Here we assigned <primary>W which translates to Ctrl + W on Linux and Windows and ⌘ + W on macOS.

Before we move on to other aspects of actions, let us appreciate a few things that are curious here. The "win" part of "win.close" is the group of the action. But how does GTK know that "win" is the action group of our window? The answer is that it is so common to add actions to windows and applications that there are already two predefined groups available:

  • "app" for actions global to the application, and
  • "win" for actions tied to an application window.

If that was not the case, we would have to add the action group manually via gio::SimpleActionGroup.

Filename: listings/actions/2/main.rs

use gio::SimpleAction;
use glib::clone;
use gtk::gio::SimpleActionGroup;
use gtk::prelude::*;
use gtk::{gio, glib};
use gtk::{Application, ApplicationWindow};

fn main() {
    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Connect to "activate" signal of `app`
    app.connect_activate(build_ui);

    // Set keyboard accelerator to trigger "win.close".
    app.set_accels_for_action("win.close", &["<primary>W"]);

    // Run the application
    app.run();
}

fn build_ui(app: &Application) {
    // Create a window and set the title
    let window = ApplicationWindow::builder()
        .application(app)
        .title("My GTK App")
        .width_request(360)
        .build();

    // Add action "close" to `window` taking no parameter
    let action_close = SimpleAction::new("close", None);
    action_close.connect_activate(clone!(@weak window => move |_, _| {
        window.close();
    }));
    window.add_action(&action_close);

    // Create a new action group and add actions to it
    let actions = SimpleActionGroup::new();
    window.insert_action_group("win", Some(&actions));
    actions.add_action(&action_close);

    // Present window
    window.present();
}

Also, if we had multiple instances of the same windows we would expect that only the currently focused window will be closed when activating "win.close". And indeed, the "win.close" will be dispatched to the currently focused window. However, that also means that we actually define one action per window instance. If we want to have a single globally accessible action instead, we call add_action on our application instead.

Adding "win.close" was useful as a simple example. However, in the future we will use the pre-defined "window.close" action which does exactly the same thing.

Parameter and State

An action, like most functions, can take a parameter. However, unlike most functions it can also be stateful. Let us see how this works.

Filename: listings/actions/3/main.rs

use gio::SimpleAction;
use glib::clone;
use gtk::{gio, glib};
use gtk::{prelude::*, Align};
use gtk::{Application, ApplicationWindow, Button, Label, Orientation};

fn main() {
    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Connect to "activate" signal of `app`
    app.connect_activate(build_ui);

    // Run the application
    app.run();
}

fn build_ui(app: &Application) {
    // Create a window and set the title
    let window = ApplicationWindow::builder()
        .application(app)
        .title("My GTK App")
        .width_request(360)
        .build();

    let original_state = 0;
    let label = Label::builder()
        .label(&format!("Counter: {}", original_state))
        .build();

    // Add action "count" to `window` taking an integer as parameter
    let action_count = SimpleAction::new_stateful(
        "count",
        Some(&i32::static_variant_type()),
        &original_state.to_variant(),
    );
    action_count.connect_activate(clone!(@weak label => move |action, parameter| {
        // Get state
        let mut state = action
            .state()
            .expect("Could not get state.")
            .get::<i32>()
            .expect("The variant needs to be of type `i32`.");

        // Get parameter
        let parameter = parameter
            .expect("Could not get parameter.")
            .get::<i32>()
            .expect("The variant needs to be of type `i32`.");

        // Increase state by parameter and store state
        state += parameter;
        action.set_state(&state.to_variant());

        // Update label with new state
        label.set_label(&format!("Counter: {}", state));
    }));
    window.add_action(&action_count);

    // Create a button with label
    let button = Button::builder().label("Press me!").build();

    // Connect to "clicked" signal of `button`
    button.connect_clicked(move |button| {
        // Activate "win.count" and pass "1" as parameter
        let parameter = 1;
        button
            .activate_action("win.count", Some(&parameter.to_variant()))
            .expect("The action does not exist.");
    });

    // Create a `gtk::Box` and add `button` and `label` to it
    let gtk_box = gtk::Box::builder()
        .orientation(Orientation::Vertical)
        .margin_top(12)
        .margin_bottom(12)
        .margin_start(12)
        .margin_end(12)
        .spacing(12)
        .halign(Align::Center)
        .build();
    gtk_box.append(&button);
    gtk_box.append(&label);

    // Add `gtk_box` to the window
    window.set_child(Some(&gtk_box));

    // Present window
    window.present();
}

Here we created a "win.count" action that increases its state by the given parameter every time it is activated. It also takes care of updating the label with the current state. The button activates the action with each click while passing "1" as parameter. This is how our app works:

Actionable

Connecting actions to the "clicked" signal of buttons is a typical use case, which is why all buttons implement the Actionable interface. This way, the action can be specified by setting the "action-name" property. If the action accepts a parameter, it can be set via the "action-target" property. With ButtonBuilder, we can set everything up by calling its methods.

Filename: listings/actions/4/main.rs

use gio::SimpleAction;
use glib::clone;
use gtk::{gio, glib};
use gtk::{prelude::*, Align};
use gtk::{Application, ApplicationWindow, Button, Label, Orientation};

fn main() {
    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Connect to "activate" signal of `app`
    app.connect_activate(build_ui);

    // Run the application
    app.run();
}

fn build_ui(app: &Application) {
    // Create a window and set the title
    let window = ApplicationWindow::builder()
        .application(app)
        .title("My GTK App")
        .width_request(360)
        .build();

    let original_state = 0;
    let label = Label::builder()
        .label(&format!("Counter: {}", original_state))
        .build();

    // Add action "count" to `window` taking an integer as parameter
    let action_count = SimpleAction::new_stateful(
        "count",
        Some(&i32::static_variant_type()),
        &original_state.to_variant(),
    );
    action_count.connect_activate(clone!(@weak label => move |action, parameter| {
        // Get state
        let mut state = action
        .state()
        .expect("Could not get state.")
        .get::<i32>()
        .expect("The value needs to be of type `i32`.");

        // Get parameter
        let parameter = parameter
            .expect("Could not get parameter.")
            .get::<i32>()
            .expect("The value needs to be of type `i32`.");

        // Increase state by parameter and save state
        state += parameter;
        action.set_state(&state.to_variant());

        // Update label with new state
        label.set_label(&format!("Counter: {}", state));
    }));

    window.add_action(&action_count);

    // Create a button with label and action
    let button = Button::builder()
        .label("Press me!")
        .action_name("win.count")
        .action_target(&1.to_variant())
        .build();

    // Create `gtk_box` and add `button` and `label` to it
    let gtk_box = gtk::Box::builder()
        .orientation(Orientation::Vertical)
        .margin_top(12)
        .margin_bottom(12)
        .margin_start(12)
        .margin_end(12)
        .spacing(12)
        .halign(Align::Center)
        .build();
    gtk_box.append(&button);
    gtk_box.append(&label);

    // Add button
    window.set_child(Some(&gtk_box));

    // Present window
    window.present();
}

Actionable widgets are also easily accessible through the interface builder. As usual, we build up the window via a composite template. Within the template we can then set the "action-name" and "action-target" properties.

Filename: listings/actions/5/window/window.ui

<?xml version="1.0" encoding="UTF-8"?>
<interface>
  <template class="MyGtkAppWindow" parent="GtkApplicationWindow">
    <property name="title">My GTK App</property>
    <child>
      <object class="GtkBox" id="gtk_box">
        <property name="orientation">vertical</property>
        <property name="margin-top">12</property>
        <property name="margin-bottom">12</property>
        <property name="margin-start">12</property>
        <property name="margin-end">12</property>
        <property name="spacing">12</property>
        <property name="halign">center</property>
        <child>
          <object class="GtkButton" id="button">
            <property name="label">Press me!</property>
            <property name="action-name">win.count</property>
            <property name="action-target">1</property>
          </object>
        </child>
        <child>
          <object class="GtkLabel" id="label">
            <property name="label">Counter: 0</property>
          </object>
        </child>
      </object>
    </child>
  </template>
</interface>

We will connect the actions and add them to the window in the Window::add_actions method.

Filename: listings/actions/5/window/mod.rs

mod imp;

use gio::SimpleAction;
use glib::{clone, Object};
use gtk::prelude::*;
use gtk::subclass::prelude::*;
use gtk::Application;
use gtk::{gio, glib};

glib::wrapper! {
    pub struct Window(ObjectSubclass<imp::Window>)
        @extends gtk::ApplicationWindow, gtk::Window, gtk::Widget,
        @implements gio::ActionGroup, gio::ActionMap, gtk::Accessible, gtk::Buildable,
                    gtk::ConstraintTarget, gtk::Native, gtk::Root, gtk::ShortcutManager;
}

impl Window {
    pub fn new(app: &Application) -> Self {
        // Create new window
        Object::new(&[("application", app)]).expect("Failed to create Window")
    }

    fn add_actions(&self) {
        let imp = self.imp();
        let label = imp.label.get();

        // Add stateful action "count" to `window` taking an integer as parameter
        let original_state = 0;
        let action_count = SimpleAction::new_stateful(
            "count",
            Some(&i32::static_variant_type()),
            &original_state.to_variant(),
        );

        action_count.connect_activate(clone!(@weak label => move |action, parameter| {
            // Get state
            let mut state = action
                .state()
                .expect("Could not get state.")
                .get::<i32>()
                .expect("The value needs to be of type `i32`.");

            // Get parameter
            let parameter = parameter
                .expect("Could not get parameter.")
                .get::<i32>()
                .expect("The value needs to be of type `i32`.");

            // Increase state by parameter and save state
            state += parameter;
            action.set_state(&state.to_variant());

            // Update label with new state
            label.set_label(&format!("Counter: {}", state));
        }));
        self.add_action(&action_count);
    }
}

Finally, add_actions will be called within constructed.

Filename: listings/actions/5/window/imp.rs

use glib::subclass::InitializingObject;
use gtk::prelude::*;

use gtk::glib;
use gtk::subclass::prelude::*;
use gtk::{CompositeTemplate, Label};

// Object holding the state
#[derive(CompositeTemplate, Default)]
#[template(file = "window.ui")]
pub struct Window {
    #[template_child]
    pub label: TemplateChild<Label>,
}

// The central trait for subclassing a GObject
#[glib::object_subclass]
impl ObjectSubclass for Window {
    // `NAME` needs to match `class` attribute of template
    const NAME: &'static str = "MyGtkAppWindow";
    type Type = super::Window;
    type ParentType = gtk::ApplicationWindow;

    fn class_init(klass: &mut Self::Class) {
        Self::bind_template(klass);
    }

    fn instance_init(obj: &InitializingObject<Self>) {
        obj.init_template();
    }
}

// Trait shared by all GObjects
impl ObjectImpl for Window {
    fn constructed(&self, obj: &Self::Type) {
        // Call "constructed" on parent
        self.parent_constructed(obj);

        // Add actions
        obj.add_actions();
    }
}

// Trait shared by all widgets
impl WidgetImpl for Window {}

// Trait shared by all windows
impl WindowImpl for Window {}

// Trait shared by all application
impl ApplicationWindowImpl for Window {}

This app behaves the same as our previous example, but it leads us to menu creation.

If you want to create a menu you have to use actions and you will want to use the interface builder. Typically, a menu entry has an action fitting one of these three descriptions:

  • no parameter and no state, or
  • no parameter and boolean state, or
  • string parameter and string state.

Let us modify our small app to demonstrate these cases. First we extend add_actions. For the action without parameter or state, we can use the pre-defined "window.close" action. Therefore we do not have to add anything here.

With the action "sensitive-button", we manipulate the "sensitive" property of button. Here, the convention is that actions with no parameter and boolean state should behave like toggle actions. This means that the caller can expect the boolean state to toggle after activating the action. Luckily for us, that is the default behavior for gio::PropertyAction with a boolean property.

Filename: listings/actions/6/window/mod.rs

mod imp;

use gio::{PropertyAction, SimpleAction};
use glib::{clone, Object};
use gtk::prelude::*;
use gtk::subclass::prelude::*;
use gtk::{gio, glib};
use gtk::{Application, Orientation};

glib::wrapper! {
    pub struct Window(ObjectSubclass<imp::Window>)
        @extends gtk::ApplicationWindow, gtk::Window, gtk::Widget,
        @implements gio::ActionGroup, gio::ActionMap, gtk::Accessible, gtk::Buildable,
                    gtk::ConstraintTarget, gtk::Native, gtk::Root, gtk::ShortcutManager;
}

impl Window {
    pub fn new(app: &Application) -> Self {
        // Create new window
        Object::new(&[("application", app)]).expect("Failed to create Window")
    }

    fn add_actions(&self) {
        // Get state
        let imp = self.imp();
        let label = imp.label.get();

        // Add stateful action "count" to `window` taking an integer as parameter
        let original_state = 0;
        let action_count = SimpleAction::new_stateful(
            "count",
            Some(&i32::static_variant_type()),
            &original_state.to_variant(),
        );

        action_count.connect_activate(clone!(@weak label => move |action, parameter| {
            // Get state
            let mut state = action
                .state()
                .expect("Could not get state.")
                .get::<i32>()
                .expect("The value needs to be of type `i32`.");

            // Get parameter
            let parameter = parameter
                .expect("Could not get parameter.")
                .get::<i32>()
                .expect("The value needs to be of type `i32`.");

            // Increase state by parameter and save state
            state += parameter;
            action.set_state(&state.to_variant());

            // Update label with new state
            label.set_label(&format!("Counter: {}", state));
        }));
        self.add_action(&action_count);

        // Add property action "sensitive-button" to `window`
        let button = imp.button.get();
        let action_sensitive_button = PropertyAction::new("sensitive-button", &button, "sensitive");
        self.add_action(&action_sensitive_button);


        // Add stateful action "orientation" to `window` taking a string as parameter
        let gtk_box = imp.gtk_box.get();
        let action_orientation = SimpleAction::new_stateful(
            "orientation",
            Some(&String::static_variant_type()),
            &"Vertical".to_variant(),
        );

        action_orientation.connect_activate(clone!(@weak gtk_box =>
            move |action, parameter| {
                // Get parameter
                let parameter = parameter
                    .expect("Could not get parameter.")
                    .get::<String>()
                    .expect("The value needs to be of type `String`.");

                let orientation = match parameter.as_str() {
                    "Horizontal" => Orientation::Horizontal,
                    "Vertical" => Orientation::Vertical,
                    _ => unreachable!()
                };

                // Set orientation and save state
                gtk_box.set_orientation(orientation);
                action.set_state(&parameter.to_variant());
        }));
        self.add_action(&action_orientation);
    }
}

A PropertyAction is useful when you need an action that manipulates the property of a GObject. The property then acts as the state of the action. As mentioned above, if the property is a boolean the action has no parameter and toggles the property on activation. In all other cases, the action has a parameter of the same type as the property. When activating the action, the property gets set to the same value as the parameter of the action.

Finally, we add "win.orientation", an action with string parameter and string state. This action can be used to change the orientation of gtk_box. Here the convention is that the state should be set to the given parameter. We do not need the action state to implement orientation switching, however it is useful for making the menu display the current orientation.

Filename: listings/actions/6/window/mod.rs

mod imp;

use gio::{PropertyAction, SimpleAction};
use glib::{clone, Object};
use gtk::prelude::*;
use gtk::subclass::prelude::*;
use gtk::{gio, glib};
use gtk::{Application, Orientation};

glib::wrapper! {
    pub struct Window(ObjectSubclass<imp::Window>)
        @extends gtk::ApplicationWindow, gtk::Window, gtk::Widget,
        @implements gio::ActionGroup, gio::ActionMap, gtk::Accessible, gtk::Buildable,
                    gtk::ConstraintTarget, gtk::Native, gtk::Root, gtk::ShortcutManager;
}

impl Window {
    pub fn new(app: &Application) -> Self {
        // Create new window
        Object::new(&[("application", app)]).expect("Failed to create Window")
    }

    fn add_actions(&self) {
        // Get state
        let imp = self.imp();
        let label = imp.label.get();

        // Add stateful action "count" to `window` taking an integer as parameter
        let original_state = 0;
        let action_count = SimpleAction::new_stateful(
            "count",
            Some(&i32::static_variant_type()),
            &original_state.to_variant(),
        );

        action_count.connect_activate(clone!(@weak label => move |action, parameter| {
            // Get state
            let mut state = action
                .state()
                .expect("Could not get state.")
                .get::<i32>()
                .expect("The value needs to be of type `i32`.");

            // Get parameter
            let parameter = parameter
                .expect("Could not get parameter.")
                .get::<i32>()
                .expect("The value needs to be of type `i32`.");

            // Increase state by parameter and save state
            state += parameter;
            action.set_state(&state.to_variant());

            // Update label with new state
            label.set_label(&format!("Counter: {}", state));
        }));
        self.add_action(&action_count);

        // Add property action "sensitive-button" to `window`
        let button = imp.button.get();
        let action_sensitive_button = PropertyAction::new("sensitive-button", &button, "sensitive");
        self.add_action(&action_sensitive_button);


        // Add stateful action "orientation" to `window` taking a string as parameter
        let gtk_box = imp.gtk_box.get();
        let action_orientation = SimpleAction::new_stateful(
            "orientation",
            Some(&String::static_variant_type()),
            &"Vertical".to_variant(),
        );

        action_orientation.connect_activate(clone!(@weak gtk_box =>
            move |action, parameter| {
                // Get parameter
                let parameter = parameter
                    .expect("Could not get parameter.")
                    .get::<String>()
                    .expect("The value needs to be of type `String`.");

                let orientation = match parameter.as_str() {
                    "Horizontal" => Orientation::Horizontal,
                    "Vertical" => Orientation::Vertical,
                    _ => unreachable!()
                };

                // Set orientation and save state
                gtk_box.set_orientation(orientation);
                action.set_state(&parameter.to_variant());
        }));
        self.add_action(&action_orientation);
    }
}

Even though gio::Menu can also be created with the bindings, the most convenient way is to use the interface builder for that. We do that by adding the menu in front of the template.

Filename: listings/actions/6/window/window.ui

 <?xml version="1.0" encoding="UTF-8"?>
 <interface>
+  <menu id="main-menu">
+    <item>
+      <attribute name="label" translatable="yes">_Close window</attribute>
+      <attribute name="action">window.close</attribute>
+    </item>
+    <item>
+      <attribute name="label" translatable="yes">_Sensitive button</attribute>
+      <attribute name="action">win.sensitive-button</attribute>
+    </item>
+    <section>
+      <attribute name="label" translatable="yes">Orientation</attribute>
+      <item>
+        <attribute name="label" translatable="yes">_Horizontal</attribute>
+        <attribute name="action">win.orientation</attribute>
+        <attribute name="target">Horizontal</attribute>
+      </item>
+      <item>
+        <attribute name="label" translatable="yes">_Vertical</attribute>
+        <attribute name="action">win.orientation</attribute>
+        <attribute name="target">Vertical</attribute>
+      </item>
+    </section>
+  </menu>
   <template class="MyGtkAppWindow" parent="GtkApplicationWindow">
     <property name="title">My GTK App</property>
+    <property name="width-request">360</property>
+    <child type="titlebar">
+      <object class="GtkHeaderBar">
+        <child type ="end">
+          <object class="GtkMenuButton">
+            <property name="icon-name">open-menu-symbolic</property>
+            <property name="menu-model">main-menu</property>
+          </object>
+        </child>
+      </object>
+    </child>
     <child>
       <object class="GtkBox" id="gtk_box">
         <property name="orientation">vertical</property>

Since we connect the menu to the gtk::MenuButton via the menu-model property, the Menu is expected to be a gtk::PopoverMenu. The documentation for PopoverMenu also explains its xml syntax for the interface builder.

Also note how we specified the target:

<attribute name="target">Horizontal</attribute>

String is the default type of the target which is why we did not have to specify a type. With targets of other types you need to manually specify the correct GVariant format string. For example, an i32 variable with value "5" would correspond to this:

<attribute name="target" type="i">5</attribute>

This is how the app looks in action:

We changed the icon of the MenuButton by setting its property "icon-name" to "open-menu-symbolic". You can find more icons with the Icon Library. Pre-installed system icons such as "open-menu-symbolic" can be used without additional steps. We will learn in the resources chapter how to bundle the others.

Settings

The menu entries nicely display the state of our stateful actions, but after the app is closed all changes to that state are lost. As usual, we solve this problem with gio::Settings. First we create a schema with settings corresponding to the stateful actions we created before.

Filename: listings/actions/7/org.gtk-rs.example.gschema.xml

<?xml version="1.0" encoding="utf-8"?>
<schemalist>
  <schema id="org.gtk-rs.example" path="/org/gtk-rs/example/">
    <key name="sensitive-button" type="b">
      <default>true</default>
      <summary>Whether the button is sensitive</summary>
    </key>
    <key name="orientation" type="s">
      <choices>
        <choice value='Horizontal'/>
        <choice value='Vertical'/>
      </choices>
      <default>'Vertical'</default>
      <summary>Orientation of GtkBox</summary>
    </key>
  </schema>
</schemalist>

Then we add the settings to imp::Window. Since gio::Settings does not implement Default, we stop deriving Default for imp::Window and implement it manually.

Filename: listings/actions/7/window/imp.rs

use gio::Settings;
use glib::subclass::InitializingObject;
use gtk::prelude::*;
use gtk::subclass::prelude::*;
use gtk::{gio, glib};
use gtk::{Button, CompositeTemplate, Label};

// Object holding the state
#[derive(CompositeTemplate)]
#[template(file = "window.ui")]
pub struct Window {
    #[template_child]
    pub gtk_box: TemplateChild<gtk::Box>,
    #[template_child]
    pub button: TemplateChild<Button>,
    #[template_child]
    pub label: TemplateChild<Label>,
    pub settings: Settings,
}

impl Default for Window {
    fn default() -> Self {
        Window {
            gtk_box: TemplateChild::default(),
            button: TemplateChild::default(),
            label: TemplateChild::default(),
            settings: Settings::new("org.gtk-rs.example"),
        }
    }
}

// The central trait for subclassing a GObject
#[glib::object_subclass]
impl ObjectSubclass for Window {
    // `NAME` needs to match `class` attribute of template
    const NAME: &'static str = "MyGtkAppWindow";
    type Type = super::Window;
    type ParentType = gtk::ApplicationWindow;

    fn class_init(klass: &mut Self::Class) {
        Self::bind_template(klass);
    }

    fn instance_init(obj: &InitializingObject<Self>) {
        obj.init_template();
    }
}

// Trait shared by all GObjects
impl ObjectImpl for Window {
    fn constructed(&self, obj: &Self::Type) {
        // Call "constructed" on parent
        self.parent_constructed(obj);

        // Setup
        obj.add_actions();
        obj.bind_settings();
    }
}

// Trait shared by all widgets
impl WidgetImpl for Window {}

// Trait shared by all windows
impl WindowImpl for Window {}

// Trait shared by all application
impl ApplicationWindowImpl for Window {}

Creating stateful actions from setting entries is so common that Settings provides a method for that exact purpose. We create actions with create_actions and then add them to the action group of our window.

Filename: listings/actions/7/window/mod.rs

mod imp;

use gio::SimpleAction;
use glib::{clone, Object};
use gtk::prelude::*;
use gtk::subclass::prelude::*;
use gtk::{gio, glib};
use gtk::{Application, Orientation};

glib::wrapper! {
    pub struct Window(ObjectSubclass<imp::Window>)
        @extends gtk::ApplicationWindow, gtk::Window, gtk::Widget,
        @implements gio::ActionGroup, gio::ActionMap, gtk::Accessible, gtk::Buildable,
                    gtk::ConstraintTarget, gtk::Native, gtk::Root, gtk::ShortcutManager;
}

impl Window {
    pub fn new(app: &Application) -> Self {
        // Create new window
        Object::new(&[("application", app)]).expect("Failed to create Window")
    }

    fn add_actions(&self) {
        // Get state
        let imp = self.imp();
        let label = imp.label.get();

        // Add stateful action "count" to `window` taking an integer as parameter
        let original_state = 0;
        let action_count = SimpleAction::new_stateful(
            "count",
            Some(&i32::static_variant_type()),
            &original_state.to_variant(),
        );

        action_count.connect_activate(clone!(@weak label => move |action, parameter| {
            // Get state
            let mut state = action
            .state()
            .expect("Could not get state.")
            .get::<i32>()
            .expect("The variant needs to be of type `i32`.");

            // Get parameter
            let parameter = parameter
                .expect("Could not get parameter.")
                .get::<i32>()
                .expect("The variant needs to be of type `i32`.");

            // Increase state by parameter and save state
            state += parameter;
            action.set_state(&state.to_variant());

            // Update label with new state
            label.set_label(&format!("Counter: {}", state));
        }));
        self.add_action(&action_count);

        // Add action "close" to `window` taking no parameter
        let action_close = SimpleAction::new("close", None);

        action_close.connect_activate(clone!(@weak self as window => move |_, _| {
            window.close();
        }));
        self.add_action(&action_close);

        // Create action from key "sensitive-button" and add to action group "win"
        let action_sensitive_button = imp.settings.create_action("sensitive-button");
        self.add_action(&action_sensitive_button);

        // Create action from key "orientation" and add to action group "win"
        let action_orientation = imp.settings.create_action("orientation");
        self.add_action(&action_orientation);
    }

    fn bind_settings(&self) {
        // Get state
        let imp = self.imp();

        // Bind setting "sensitive-button" to "sensitive" property of `button`
        let button = imp.button.get();
        imp.settings
            .bind("sensitive-button", &button, "sensitive")
            .build();

        // Bind setting "orientation" to "orientation" property of `button`
        let gtk_box = imp.gtk_box.get();
        imp.settings
            .bind("orientation", &gtk_box, "orientation")
            .mapping(|variant, _| {
                let orientation = variant
                    .get::<String>()
                    .expect("The variant needs to be of type `String`.");

                let orientation = match orientation.as_str() {
                    "Horizontal" => Orientation::Horizontal,
                    "Vertical" => Orientation::Vertical,
                    _ => unreachable!(),
                };

                Some(orientation.to_value())
            })
            .build();
    }
}

Since actions from create_actions follow the aforementioned conventions, we can keep further changes to a minimum. The action "win.sensitive-button" toggles its state with each activation and the state of the "win.orientation" action follows the given parameter.

We still have to specify what should happen when the actions are activated though. For the stateful actions, instead of adding callbacks to their "activate" signals we bind the settings to properties we want to manipulate.

Filename: listings/actions/7/window/mod.rs

mod imp;

use gio::SimpleAction;
use glib::{clone, Object};
use gtk::prelude::*;
use gtk::subclass::prelude::*;
use gtk::{gio, glib};
use gtk::{Application, Orientation};

glib::wrapper! {
    pub struct Window(ObjectSubclass<imp::Window>)
        @extends gtk::ApplicationWindow, gtk::Window, gtk::Widget,
        @implements gio::ActionGroup, gio::ActionMap, gtk::Accessible, gtk::Buildable,
                    gtk::ConstraintTarget, gtk::Native, gtk::Root, gtk::ShortcutManager;
}

impl Window {
    pub fn new(app: &Application) -> Self {
        // Create new window
        Object::new(&[("application", app)]).expect("Failed to create Window")
    }

    fn add_actions(&self) {
        // Get state
        let imp = self.imp();
        let label = imp.label.get();

        // Add stateful action "count" to `window` taking an integer as parameter
        let original_state = 0;
        let action_count = SimpleAction::new_stateful(
            "count",
            Some(&i32::static_variant_type()),
            &original_state.to_variant(),
        );

        action_count.connect_activate(clone!(@weak label => move |action, parameter| {
            // Get state
            let mut state = action
            .state()
            .expect("Could not get state.")
            .get::<i32>()
            .expect("The variant needs to be of type `i32`.");

            // Get parameter
            let parameter = parameter
                .expect("Could not get parameter.")
                .get::<i32>()
                .expect("The variant needs to be of type `i32`.");

            // Increase state by parameter and save state
            state += parameter;
            action.set_state(&state.to_variant());

            // Update label with new state
            label.set_label(&format!("Counter: {}", state));
        }));
        self.add_action(&action_count);

        // Add action "close" to `window` taking no parameter
        let action_close = SimpleAction::new("close", None);

        action_close.connect_activate(clone!(@weak self as window => move |_, _| {
            window.close();
        }));
        self.add_action(&action_close);

        // Create action from key "sensitive-button" and add to action group "win"
        let action_sensitive_button = imp.settings.create_action("sensitive-button");
        self.add_action(&action_sensitive_button);

        // Create action from key "orientation" and add to action group "win"
        let action_orientation = imp.settings.create_action("orientation");
        self.add_action(&action_orientation);
    }

    fn bind_settings(&self) {
        // Get state
        let imp = self.imp();

        // Bind setting "sensitive-button" to "sensitive" property of `button`
        let button = imp.button.get();
        imp.settings
            .bind("sensitive-button", &button, "sensitive")
            .build();

        // Bind setting "orientation" to "orientation" property of `button`
        let gtk_box = imp.gtk_box.get();
        imp.settings
            .bind("orientation", &gtk_box, "orientation")
            .mapping(|variant, _| {
                let orientation = variant
                    .get::<String>()
                    .expect("The variant needs to be of type `String`.");

                let orientation = match orientation.as_str() {
                    "Horizontal" => Orientation::Horizontal,
                    "Vertical" => Orientation::Vertical,
                    _ => unreachable!(),
                };

                Some(orientation.to_value())
            })
            .build();
    }
}

Finally, we make sure that bind_settings is called within constructed.

Filename: listings/actions/7/window/imp.rs

use gio::Settings;
use glib::subclass::InitializingObject;
use gtk::prelude::*;
use gtk::subclass::prelude::*;
use gtk::{gio, glib};
use gtk::{Button, CompositeTemplate, Label};

// Object holding the state
#[derive(CompositeTemplate)]
#[template(file = "window.ui")]
pub struct Window {
    #[template_child]
    pub gtk_box: TemplateChild<gtk::Box>,
    #[template_child]
    pub button: TemplateChild<Button>,
    #[template_child]
    pub label: TemplateChild<Label>,
    pub settings: Settings,
}

impl Default for Window {
    fn default() -> Self {
        Window {
            gtk_box: TemplateChild::default(),
            button: TemplateChild::default(),
            label: TemplateChild::default(),
            settings: Settings::new("org.gtk-rs.example"),
        }
    }
}

// The central trait for subclassing a GObject
#[glib::object_subclass]
impl ObjectSubclass for Window {
    // `NAME` needs to match `class` attribute of template
    const NAME: &'static str = "MyGtkAppWindow";
    type Type = super::Window;
    type ParentType = gtk::ApplicationWindow;

    fn class_init(klass: &mut Self::Class) {
        Self::bind_template(klass);
    }

    fn instance_init(obj: &InitializingObject<Self>) {
        obj.init_template();
    }
}

// Trait shared by all GObjects
impl ObjectImpl for Window {
    fn constructed(&self, obj: &Self::Type) {
        // Call "constructed" on parent
        self.parent_constructed(obj);

        // Setup
        obj.add_actions();
        obj.bind_settings();
    }
}

// Trait shared by all widgets
impl WidgetImpl for Window {}

// Trait shared by all windows
impl WindowImpl for Window {}

// Trait shared by all application
impl ApplicationWindowImpl for Window {}

Actions are extremely powerful and we are only scratching the surface here. If you want to learn more about them, the GNOME developer documentation is a good place to start.

Manipulating State of To-Do App

Filtering Tasks

Now it is time to continue working on our To-Do app. One nice feature to add would be filtering of the tasks. What a chance to use our newly gained knowledge of actions! Using actions, we can access the filter via the menu as well as via keyboard shortcuts. This is how we want this to work in the end:

Note that the screencast also shows a button with label "Clear" which will remove all done tasks. This will come in handy when we later make the app preserve the tasks between sessions.

Let us start by adding a menu and a header bar to window.ui. After reading the actions chapter the added code should feel familiar.

Filename: listings/todo_app/2/window/window.ui

 <?xml version="1.0" encoding="UTF-8"?>
 <interface>
+  <menu id="main-menu">
+    <submenu>
+      <attribute name="label" translatable="yes">_Filtering</attribute>
+      <item>
+        <attribute name="label" translatable="yes">_All</attribute>
+        <attribute name="action">win.filter</attribute>
+        <attribute name="target">All</attribute>
+      </item>
+      <item>
+        <attribute name="label" translatable="yes">_Open</attribute>
+        <attribute name="action">win.filter</attribute>
+        <attribute name="target">Open</attribute>
+      </item>
+      <item>
+        <attribute name="label" translatable="yes">_Done</attribute>
+        <attribute name="action">win.filter</attribute>
+        <attribute name="target">Done</attribute>
+      </item>
+    </submenu>
+    <item>
+      <attribute name="label" translatable="yes">_Keyboard Shortcuts</attribute>
+      <attribute name="action">win.show-help-overlay</attribute>
+    </item>
+  </menu>
   <template class="TodoWindow" parent="GtkApplicationWindow">
     <property name="width-request">360</property>
     <property name="title" translatable="yes">To-Do</property>
+    <child type="titlebar">
+      <object class="GtkHeaderBar">
+        <child type="start">
+          <object class="GtkButton" id="clear_button">
+            <property name="label">Clear</property>
+          </object>
+        </child>
+        <child type ="end">
+          <object class="GtkMenuButton" id="menu_button">
+            <property name="icon-name">open-menu-symbolic</property>
+            <property name="menu-model">main-menu</property>
+          </object>
+        </child>
+      </object>
+    </child>
     <child>
       <object class="GtkBox">
         <property name="orientation">vertical</property>

We also create a settings schema. Again, the settings correspond to the stateful actions called by the menu.

Filename: listings/todo_app/2/org.gtk-rs.Todo.gschema.xml

<?xml version="1.0" encoding="utf-8"?>
<schemalist>
  <schema id="org.gtk-rs.Todo" path="/org/gtk-rs/Todo/">
    <key name="filter" type="s">
      <choices>
        <choice value='All'/>
        <choice value='Open'/>
        <choice value='Done'/>
      </choices>
      <default>'All'</default>
      <summary>Filter of the tasks</summary>
    </key>
  </schema>
</schemalist>

Then we add settings and a reference to clear_button to imp::Window. We stop deriving Default for imp::Window and implement it manually.

Filename: listings/todo_app/2/window/imp.rs

use std::fs::File;

use gio::Settings;
use glib::signal::Inhibit;
use glib::subclass::InitializingObject;
use gtk::prelude::*;
use gtk::subclass::prelude::*;
use gtk::{gio, glib};
use gtk::{Button, CompositeTemplate, Entry, ListView, MenuButton};
use once_cell::sync::OnceCell;

use crate::todo_object::TodoObject;
use crate::utils::data_path;

// Object holding the state
#[derive(CompositeTemplate)]
#[template(file = "window.ui")]
pub struct Window {
    #[template_child]
    pub entry: TemplateChild<Entry>,
    #[template_child]
    pub menu_button: TemplateChild<MenuButton>,
    #[template_child]
    pub list_view: TemplateChild<ListView>,
    #[template_child]
    pub clear_button: TemplateChild<Button>,
    pub model: OnceCell<gio::ListStore>,
    pub settings: Settings,
}

impl Default for Window {
    fn default() -> Self {
        Window {
            entry: TemplateChild::default(),
            menu_button: TemplateChild::default(),
            list_view: TemplateChild::default(),
            clear_button: TemplateChild::default(),
            model: OnceCell::default(),
            settings: Settings::new("org.gtk-rs.Todo"),
        }
    }
}

// The central trait for subclassing a GObject
#[glib::object_subclass]
impl ObjectSubclass for Window {
    // `NAME` needs to match `class` attribute of template
    const NAME: &'static str = "TodoWindow";
    type Type = super::Window;
    type ParentType = gtk::ApplicationWindow;

    fn class_init(klass: &mut Self::Class) {
        Self::bind_template(klass);
    }

    fn instance_init(obj: &InitializingObject<Self>) {
        obj.init_template();
    }
}

// Trait shared by all GObjects
impl ObjectImpl for Window {
    fn constructed(&self, obj: &Self::Type) {
        // Call "constructed" on parent
        self.parent_constructed(obj);

        // Setup
        obj.setup_model();
        obj.restore_data();
        obj.setup_callbacks();
        obj.setup_factory();
        obj.setup_shortcut_window();
        obj.setup_filter_action();
    }
}

// Trait shared by all widgets
impl WidgetImpl for Window {}

// Trait shared by all windows
impl WindowImpl for Window {
    fn close_request(&self, window: &Self::Type) -> Inhibit {
        // Store todo data in vector
        let mut backup_data = Vec::new();
        let mut position = 0;
        while let Some(item) = window.model().item(position) {
            // Get `TodoObject` from `glib::Object`
            let todo_data = item
                .downcast_ref::<TodoObject>()
                .expect("The object needs to be of type `TodoObject`.")
                .todo_data();
            // Add todo data to vector and increase position
            backup_data.push(todo_data);
            position += 1;
        }

        // Save state in file
        let file = File::create(data_path()).expect("Could not create json file.");
        serde_json::to_writer_pretty(file, &backup_data)
            .expect("Could not write data to json file");

        // Pass close request on to the parent
        self.parent_close_request(window)
    }
}

// Trait shared by all application
impl ApplicationWindowImpl for Window {}

We also add the getter methods is_completed and todo_data to TodoObject. We will make use of them in the following snippets.

Filename: listings/todo_app/2/todo_object/mod.rs

mod imp;

use glib::Object;
use gtk::glib;
use gtk::subclass::prelude::*;
use serde::{Deserialize, Serialize};

glib::wrapper! {
    pub struct TodoObject(ObjectSubclass<imp::TodoObject>);
}

impl TodoObject {
    pub fn new(completed: bool, content: String) -> Self {
        Object::new(&[("completed", &completed), ("content", &content)])
            .expect("Failed to create `TodoObject`.")
    }

    pub fn is_completed(&self) -> bool {
        let imp = self.imp();
        imp.data.borrow().completed
    }

    pub fn todo_data(&self) -> TodoData {
        let imp = self.imp();
        imp.data.borrow().clone()
    }
}

#[derive(Default, Serialize, Deserialize, Clone)]
pub struct TodoData {
    pub completed: bool,
    pub content: String,
}

Similar to the previous chapter, we let settings create the action. Then we add the newly created action "filter" to our window.

Filename: listings/todo_app/2/window/mod.rs

mod imp;

use std::fs::File;

use crate::todo_object::{TodoData, TodoObject};
use crate::todo_row::TodoRow;
use crate::utils::data_path;
use glib::{clone, Object};
use gtk::prelude::*;
use gtk::subclass::prelude::*;
use gtk::{gio, glib};
use gtk::{Application, CustomFilter, FilterListModel, NoSelection, SignalListItemFactory};
use log::info;

glib::wrapper! {
    pub struct Window(ObjectSubclass<imp::Window>)
        @extends gtk::ApplicationWindow, gtk::Window, gtk::Widget,
        @implements gio::ActionGroup, gio::ActionMap, gtk::Accessible, gtk::Buildable,
                    gtk::ConstraintTarget, gtk::Native, gtk::Root, gtk::ShortcutManager;
}

impl Window {
    pub fn new(app: &Application) -> Self {
        // Create new window
        Object::new(&[("application", app)]).expect("Failed to create `Window`.")
    }

    fn model(&self) -> &gio::ListStore {
        // Get state
        let imp = self.imp();
        imp.model.get().expect("Could not get model")
    }

    fn filter(&self) -> Option<CustomFilter> {
        // Get state
        let imp = self.imp();

        // Get filter_state from settings
        let filter_state: String = imp.settings.get("filter");

        // Create custom filters
        let filter_open = CustomFilter::new(|obj| {
            // Get `TodoObject` from `glib::Object`
            let todo_object = obj
                .downcast_ref::<TodoObject>()
                .expect("The object needs to be of type `TodoObject`.");

            // Only allow completed tasks
            !todo_object.is_completed()
        });
        let filter_done = CustomFilter::new(|obj| {
            // Get `TodoObject` from `glib::Object`
            let todo_object = obj
                .downcast_ref::<TodoObject>()
                .expect("The object needs to be of type `TodoObject`.");

            // Only allow done tasks
            todo_object.is_completed()
        });

        // Return the correct filter
        match filter_state.as_str() {
            "All" => None,
            "Open" => Some(filter_open),
            "Done" => Some(filter_done),
            _ => unreachable!(),
        }
    }

    fn setup_model(&self) {
        // Create new model
        let model = gio::ListStore::new(TodoObject::static_type());

        // Get state and set model
        let imp = self.imp();
        imp.model.set(model).expect("Could not set model");

        // Wrap model with filter and selection and pass it to the list view
        let filter_model = FilterListModel::new(Some(self.model()), self.filter().as_ref());
        let selection_model = NoSelection::new(Some(&filter_model));
        imp.list_view.set_model(Some(&selection_model));

        // Filter model whenever the value of the key "filter" changes
        imp.settings.connect_changed(
            Some("filter"),
            clone!(@weak self as window, @weak filter_model => move |_, _| {
                filter_model.set_filter(window.filter().as_ref());
            }),
        );
    }

    fn restore_data(&self) {
        if let Ok(file) = File::open(data_path()) {
            // Deserialize data from file to vector
            let backup_data: Vec<TodoData> =
                serde_json::from_reader(file).expect("Could not get backup data from json file.");

            // Convert `Vec<TodoData>` to `Vec<TodoObject>`
            let todo_objects: Vec<TodoObject> = backup_data
                .into_iter()
                .map(|todo_data| TodoObject::new(todo_data.completed, todo_data.content))
                .collect();

            // Insert restored objects into model
            self.model().splice(0, 0, &todo_objects);
        } else {
            info!("Backup file does not exist yet {:?}", data_path());
        }
    }

    fn setup_callbacks(&self) {
        // Get state
        let imp = self.imp();
        let model = self.model();

        // Setup callback so that activation
        // creates a new todo object and clears the entry
        imp.entry
            .connect_activate(clone!(@weak model => move |entry| {
                let buffer = entry.buffer();
                let content = buffer.text();
                let todo_object = TodoObject::new(false, content);
                model.append(&todo_object);
                buffer.set_text("");
            }));

        // Setup callback so that click on the clear_button
        // removes all done tasks
        imp.clear_button
            .connect_clicked(clone!(@weak model => move |_| {
                let mut position = 0;
                while let Some(item) = model.item(position) {
                    // Get `TodoObject` from `glib::Object`
                    let todo_object = item
                        .downcast_ref::<TodoObject>()
                        .expect("The object needs to be of type `TodoObject`.");

                    if todo_object.is_completed() {
                        model.remove(position);
                    } else {
                        position += 1;
                    }
                }
            }));
    }

    fn setup_factory(&self) {
        // Create a new factory
        let factory = SignalListItemFactory::new();

        // Create an empty `TodoRow` during setup
        factory.connect_setup(move |_, list_item| {
            // Create `TodoRow`
            let todo_row = TodoRow::new();
            list_item.set_child(Some(&todo_row));
        });

        // Tell factory how to bind `TodoRow` to a `TodoObject`
        factory.connect_bind(move |_, list_item| {
            // Get `TodoObject` from `ListItem`
            let todo_object = list_item
                .item()
                .expect("The item has to exist.")
                .downcast::<TodoObject>()
                .expect("The item has to be an `TodoObject`.");

            // Get `TodoRow` from `ListItem`
            let todo_row = list_item
                .child()
                .expect("The child has to exist.")
                .downcast::<TodoRow>()
                .expect("The child has to be a `TodoRow`.");

            todo_row.bind(&todo_object);
        });

        // Tell factory how to unbind `TodoRow` from `TodoObject`
        factory.connect_unbind(move |_, list_item| {
            // Get `TodoRow` from `ListItem`
            let todo_row = list_item
                .child()
                .expect("The child has to exist.")
                .downcast::<TodoRow>()
                .expect("The child has to be a `TodoRow`.");

            todo_row.unbind();
        });

        // Set the factory of the list view
        let imp = self.imp();
        imp.list_view.set_factory(Some(&factory));
    }

    fn setup_shortcut_window(&self) {
        // Get `ShortcutsWindow` via `gtk::Builder`
        let builder = gtk::Builder::from_string(include_str!("shortcuts.ui"));
        let shortcuts = builder
            .object("shortcuts")
            .expect("Could not get object `shortcuts` from builder.");

        // After calling this method,
        // calling the action "win.show-help-overlay" will show the shortcut window
        self.set_help_overlay(Some(&shortcuts));
    }

    fn setup_filter_action(&self) {
        // Get state
        let imp = self.imp();

        // Create action from key "filter"
        let filter_action = imp.settings.create_action("filter");

        // Add action "filter" to action group "win"
        self.add_action(&filter_action);
    }
}

After activating the action "win.filter", the corresponding setting will be changed. So we need a method which translates this setting into a filter that the gtk::FilterListModel understands. The possible states are "All", "Open" and "Done". We return Some(filter) for "Open" and "Done". If the state is "All" nothing has to be filtered out, so we return None.

Filename: listings/todo_app/2/window/mod.rs

mod imp;

use std::fs::File;

use crate::todo_object::{TodoData, TodoObject};
use crate::todo_row::TodoRow;
use crate::utils::data_path;
use glib::{clone, Object};
use gtk::prelude::*;
use gtk::subclass::prelude::*;
use gtk::{gio, glib};
use gtk::{Application, CustomFilter, FilterListModel, NoSelection, SignalListItemFactory};
use log::info;

glib::wrapper! {
    pub struct Window(ObjectSubclass<imp::Window>)
        @extends gtk::ApplicationWindow, gtk::Window, gtk::Widget,
        @implements gio::ActionGroup, gio::ActionMap, gtk::Accessible, gtk::Buildable,
                    gtk::ConstraintTarget, gtk::Native, gtk::Root, gtk::ShortcutManager;
}

impl Window {
    pub fn new(app: &Application) -> Self {
        // Create new window
        Object::new(&[("application", app)]).expect("Failed to create `Window`.")
    }

    fn model(&self) -> &gio::ListStore {
        // Get state
        let imp = self.imp();
        imp.model.get().expect("Could not get model")
    }

    fn filter(&self) -> Option<CustomFilter> {
        // Get state
        let imp = self.imp();

        // Get filter_state from settings
        let filter_state: String = imp.settings.get("filter");

        // Create custom filters
        let filter_open = CustomFilter::new(|obj| {
            // Get `TodoObject` from `glib::Object`
            let todo_object = obj
                .downcast_ref::<TodoObject>()
                .expect("The object needs to be of type `TodoObject`.");

            // Only allow completed tasks
            !todo_object.is_completed()
        });
        let filter_done = CustomFilter::new(|obj| {
            // Get `TodoObject` from `glib::Object`
            let todo_object = obj
                .downcast_ref::<TodoObject>()
                .expect("The object needs to be of type `TodoObject`.");

            // Only allow done tasks
            todo_object.is_completed()
        });

        // Return the correct filter
        match filter_state.as_str() {
            "All" => None,
            "Open" => Some(filter_open),
            "Done" => Some(filter_done),
            _ => unreachable!(),
        }
    }

    fn setup_model(&self) {
        // Create new model
        let model = gio::ListStore::new(TodoObject::static_type());

        // Get state and set model
        let imp = self.imp();
        imp.model.set(model).expect("Could not set model");

        // Wrap model with filter and selection and pass it to the list view
        let filter_model = FilterListModel::new(Some(self.model()), self.filter().as_ref());
        let selection_model = NoSelection::new(Some(&filter_model));
        imp.list_view.set_model(Some(&selection_model));

        // Filter model whenever the value of the key "filter" changes
        imp.settings.connect_changed(
            Some("filter"),
            clone!(@weak self as window, @weak filter_model => move |_, _| {
                filter_model.set_filter(window.filter().as_ref());
            }),
        );
    }

    fn restore_data(&self) {
        if let Ok(file) = File::open(data_path()) {
            // Deserialize data from file to vector
            let backup_data: Vec<TodoData> =
                serde_json::from_reader(file).expect("Could not get backup data from json file.");

            // Convert `Vec<TodoData>` to `Vec<TodoObject>`
            let todo_objects: Vec<TodoObject> = backup_data
                .into_iter()
                .map(|todo_data| TodoObject::new(todo_data.completed, todo_data.content))
                .collect();

            // Insert restored objects into model
            self.model().splice(0, 0, &todo_objects);
        } else {
            info!("Backup file does not exist yet {:?}", data_path());
        }
    }

    fn setup_callbacks(&self) {
        // Get state
        let imp = self.imp();
        let model = self.model();

        // Setup callback so that activation
        // creates a new todo object and clears the entry
        imp.entry
            .connect_activate(clone!(@weak model => move |entry| {
                let buffer = entry.buffer();
                let content = buffer.text();
                let todo_object = TodoObject::new(false, content);
                model.append(&todo_object);
                buffer.set_text("");
            }));

        // Setup callback so that click on the clear_button
        // removes all done tasks
        imp.clear_button
            .connect_clicked(clone!(@weak model => move |_| {
                let mut position = 0;
                while let Some(item) = model.item(position) {
                    // Get `TodoObject` from `glib::Object`
                    let todo_object = item
                        .downcast_ref::<TodoObject>()
                        .expect("The object needs to be of type `TodoObject`.");

                    if todo_object.is_completed() {
                        model.remove(position);
                    } else {
                        position += 1;
                    }
                }
            }));
    }

    fn setup_factory(&self) {
        // Create a new factory
        let factory = SignalListItemFactory::new();

        // Create an empty `TodoRow` during setup
        factory.connect_setup(move |_, list_item| {
            // Create `TodoRow`
            let todo_row = TodoRow::new();
            list_item.set_child(Some(&todo_row));
        });

        // Tell factory how to bind `TodoRow` to a `TodoObject`
        factory.connect_bind(move |_, list_item| {
            // Get `TodoObject` from `ListItem`
            let todo_object = list_item
                .item()
                .expect("The item has to exist.")
                .downcast::<TodoObject>()
                .expect("The item has to be an `TodoObject`.");

            // Get `TodoRow` from `ListItem`
            let todo_row = list_item
                .child()
                .expect("The child has to exist.")
                .downcast::<TodoRow>()
                .expect("The child has to be a `TodoRow`.");

            todo_row.bind(&todo_object);
        });

        // Tell factory how to unbind `TodoRow` from `TodoObject`
        factory.connect_unbind(move |_, list_item| {
            // Get `TodoRow` from `ListItem`
            let todo_row = list_item
                .child()
                .expect("The child has to exist.")
                .downcast::<TodoRow>()
                .expect("The child has to be a `TodoRow`.");

            todo_row.unbind();
        });

        // Set the factory of the list view
        let imp = self.imp();
        imp.list_view.set_factory(Some(&factory));
    }

    fn setup_shortcut_window(&self) {
        // Get `ShortcutsWindow` via `gtk::Builder`
        let builder = gtk::Builder::from_string(include_str!("shortcuts.ui"));
        let shortcuts = builder
            .object("shortcuts")
            .expect("Could not get object `shortcuts` from builder.");

        // After calling this method,
        // calling the action "win.show-help-overlay" will show the shortcut window
        self.set_help_overlay(Some(&shortcuts));
    }

    fn setup_filter_action(&self) {
        // Get state
        let imp = self.imp();

        // Create action from key "filter"
        let filter_action = imp.settings.create_action("filter");

        // Add action "filter" to action group "win"
        self.add_action(&filter_action);
    }
}

Now, we can set up the model. We initialize filter_model with the state from the settings by calling the method filter. Whenever the state of the key "filter" changes, we call the method filter again to get the updated filter_model.

Filename: listings/todo_app/2/window/mod.rs

mod imp;

use std::fs::File;

use crate::todo_object::{TodoData, TodoObject};
use crate::todo_row::TodoRow;
use crate::utils::data_path;
use glib::{clone, Object};
use gtk::prelude::*;
use gtk::subclass::prelude::*;
use gtk::{gio, glib};
use gtk::{Application, CustomFilter, FilterListModel, NoSelection, SignalListItemFactory};
use log::info;

glib::wrapper! {
    pub struct Window(ObjectSubclass<imp::Window>)
        @extends gtk::ApplicationWindow, gtk::Window, gtk::Widget,
        @implements gio::ActionGroup, gio::ActionMap, gtk::Accessible, gtk::Buildable,
                    gtk::ConstraintTarget, gtk::Native, gtk::Root, gtk::ShortcutManager;
}

impl Window {
    pub fn new(app: &Application) -> Self {
        // Create new window
        Object::new(&[("application", app)]).expect("Failed to create `Window`.")
    }

    fn model(&self) -> &gio::ListStore {
        // Get state
        let imp = self.imp();
        imp.model.get().expect("Could not get model")
    }

    fn filter(&self) -> Option<CustomFilter> {
        // Get state
        let imp = self.imp();

        // Get filter_state from settings
        let filter_state: String = imp.settings.get("filter");

        // Create custom filters
        let filter_open = CustomFilter::new(|obj| {
            // Get `TodoObject` from `glib::Object`
            let todo_object = obj
                .downcast_ref::<TodoObject>()
                .expect("The object needs to be of type `TodoObject`.");

            // Only allow completed tasks
            !todo_object.is_completed()
        });
        let filter_done = CustomFilter::new(|obj| {
            // Get `TodoObject` from `glib::Object`
            let todo_object = obj
                .downcast_ref::<TodoObject>()
                .expect("The object needs to be of type `TodoObject`.");

            // Only allow done tasks
            todo_object.is_completed()
        });

        // Return the correct filter
        match filter_state.as_str() {
            "All" => None,
            "Open" => Some(filter_open),
            "Done" => Some(filter_done),
            _ => unreachable!(),
        }
    }

    fn setup_model(&self) {
        // Create new model
        let model = gio::ListStore::new(TodoObject::static_type());

        // Get state and set model
        let imp = self.imp();
        imp.model.set(model).expect("Could not set model");

        // Wrap model with filter and selection and pass it to the list view
        let filter_model = FilterListModel::new(Some(self.model()), self.filter().as_ref());
        let selection_model = NoSelection::new(Some(&filter_model));
        imp.list_view.set_model(Some(&selection_model));

        // Filter model whenever the value of the key "filter" changes
        imp.settings.connect_changed(
            Some("filter"),
            clone!(@weak self as window, @weak filter_model => move |_, _| {
                filter_model.set_filter(window.filter().as_ref());
            }),
        );
    }

    fn restore_data(&self) {
        if let Ok(file) = File::open(data_path()) {
            // Deserialize data from file to vector
            let backup_data: Vec<TodoData> =
                serde_json::from_reader(file).expect("Could not get backup data from json file.");

            // Convert `Vec<TodoData>` to `Vec<TodoObject>`
            let todo_objects: Vec<TodoObject> = backup_data
                .into_iter()
                .map(|todo_data| TodoObject::new(todo_data.completed, todo_data.content))
                .collect();

            // Insert restored objects into model
            self.model().splice(0, 0, &todo_objects);
        } else {
            info!("Backup file does not exist yet {:?}", data_path());
        }
    }

    fn setup_callbacks(&self) {
        // Get state
        let imp = self.imp();
        let model = self.model();

        // Setup callback so that activation
        // creates a new todo object and clears the entry
        imp.entry
            .connect_activate(clone!(@weak model => move |entry| {
                let buffer = entry.buffer();
                let content = buffer.text();
                let todo_object = TodoObject::new(false, content);
                model.append(&todo_object);
                buffer.set_text("");
            }));

        // Setup callback so that click on the clear_button
        // removes all done tasks
        imp.clear_button
            .connect_clicked(clone!(@weak model => move |_| {
                let mut position = 0;
                while let Some(item) = model.item(position) {
                    // Get `TodoObject` from `glib::Object`
                    let todo_object = item
                        .downcast_ref::<TodoObject>()
                        .expect("The object needs to be of type `TodoObject`.");

                    if todo_object.is_completed() {
                        model.remove(position);
                    } else {
                        position += 1;
                    }
                }
            }));
    }

    fn setup_factory(&self) {
        // Create a new factory
        let factory = SignalListItemFactory::new();

        // Create an empty `TodoRow` during setup
        factory.connect_setup(move |_, list_item| {
            // Create `TodoRow`
            let todo_row = TodoRow::new();
            list_item.set_child(Some(&todo_row));
        });

        // Tell factory how to bind `TodoRow` to a `TodoObject`
        factory.connect_bind(move |_, list_item| {
            // Get `TodoObject` from `ListItem`
            let todo_object = list_item
                .item()
                .expect("The item has to exist.")
                .downcast::<TodoObject>()
                .expect("The item has to be an `TodoObject`.");

            // Get `TodoRow` from `ListItem`
            let todo_row = list_item
                .child()
                .expect("The child has to exist.")
                .downcast::<TodoRow>()
                .expect("The child has to be a `TodoRow`.");

            todo_row.bind(&todo_object);
        });

        // Tell factory how to unbind `TodoRow` from `TodoObject`
        factory.connect_unbind(move |_, list_item| {
            // Get `TodoRow` from `ListItem`
            let todo_row = list_item
                .child()
                .expect("The child has to exist.")
                .downcast::<TodoRow>()
                .expect("The child has to be a `TodoRow`.");

            todo_row.unbind();
        });

        // Set the factory of the list view
        let imp = self.imp();
        imp.list_view.set_factory(Some(&factory));
    }

    fn setup_shortcut_window(&self) {
        // Get `ShortcutsWindow` via `gtk::Builder`
        let builder = gtk::Builder::from_string(include_str!("shortcuts.ui"));
        let shortcuts = builder
            .object("shortcuts")
            .expect("Could not get object `shortcuts` from builder.");

        // After calling this method,
        // calling the action "win.show-help-overlay" will show the shortcut window
        self.set_help_overlay(Some(&shortcuts));
    }

    fn setup_filter_action(&self) {
        // Get state
        let imp = self.imp();

        // Create action from key "filter"
        let filter_action = imp.settings.create_action("filter");

        // Add action "filter" to action group "win"
        self.add_action(&filter_action);
    }
}

In setup_callbacks, we add a signal handler to clear_button, which removes all completed tasks when activated.

Filename: listings/todo_app/2/window/mod.rs

mod imp;

use std::fs::File;

use crate::todo_object::{TodoData, TodoObject};
use crate::todo_row::TodoRow;
use crate::utils::data_path;
use glib::{clone, Object};
use gtk::prelude::*;
use gtk::subclass::prelude::*;
use gtk::{gio, glib};
use gtk::{Application, CustomFilter, FilterListModel, NoSelection, SignalListItemFactory};
use log::info;

glib::wrapper! {
    pub struct Window(ObjectSubclass<imp::Window>)
        @extends gtk::ApplicationWindow, gtk::Window, gtk::Widget,
        @implements gio::ActionGroup, gio::ActionMap, gtk::Accessible, gtk::Buildable,
                    gtk::ConstraintTarget, gtk::Native, gtk::Root, gtk::ShortcutManager;
}

impl Window {
    pub fn new(app: &Application) -> Self {
        // Create new window
        Object::new(&[("application", app)]).expect("Failed to create `Window`.")
    }

    fn model(&self) -> &gio::ListStore {
        // Get state
        let imp = self.imp();
        imp.model.get().expect("Could not get model")
    }

    fn filter(&self) -> Option<CustomFilter> {
        // Get state
        let imp = self.imp();

        // Get filter_state from settings
        let filter_state: String = imp.settings.get("filter");

        // Create custom filters
        let filter_open = CustomFilter::new(|obj| {
            // Get `TodoObject` from `glib::Object`
            let todo_object = obj
                .downcast_ref::<TodoObject>()
                .expect("The object needs to be of type `TodoObject`.");

            // Only allow completed tasks
            !todo_object.is_completed()
        });
        let filter_done = CustomFilter::new(|obj| {
            // Get `TodoObject` from `glib::Object`
            let todo_object = obj
                .downcast_ref::<TodoObject>()
                .expect("The object needs to be of type `TodoObject`.");

            // Only allow done tasks
            todo_object.is_completed()
        });

        // Return the correct filter
        match filter_state.as_str() {
            "All" => None,
            "Open" => Some(filter_open),
            "Done" => Some(filter_done),
            _ => unreachable!(),
        }
    }

    fn setup_model(&self) {
        // Create new model
        let model = gio::ListStore::new(TodoObject::static_type());

        // Get state and set model
        let imp = self.imp();
        imp.model.set(model).expect("Could not set model");

        // Wrap model with filter and selection and pass it to the list view
        let filter_model = FilterListModel::new(Some(self.model()), self.filter().as_ref());
        let selection_model = NoSelection::new(Some(&filter_model));
        imp.list_view.set_model(Some(&selection_model));

        // Filter model whenever the value of the key "filter" changes
        imp.settings.connect_changed(
            Some("filter"),
            clone!(@weak self as window, @weak filter_model => move |_, _| {
                filter_model.set_filter(window.filter().as_ref());
            }),
        );
    }

    fn restore_data(&self) {
        if let Ok(file) = File::open(data_path()) {
            // Deserialize data from file to vector
            let backup_data: Vec<TodoData> =
                serde_json::from_reader(file).expect("Could not get backup data from json file.");

            // Convert `Vec<TodoData>` to `Vec<TodoObject>`
            let todo_objects: Vec<TodoObject> = backup_data
                .into_iter()
                .map(|todo_data| TodoObject::new(todo_data.completed, todo_data.content))
                .collect();

            // Insert restored objects into model
            self.model().splice(0, 0, &todo_objects);
        } else {
            info!("Backup file does not exist yet {:?}", data_path());
        }
    }

    fn setup_callbacks(&self) {
        // Get state
        let imp = self.imp();
        let model = self.model();

        // Setup callback so that activation
        // creates a new todo object and clears the entry
        imp.entry
            .connect_activate(clone!(@weak model => move |entry| {
                let buffer = entry.buffer();
                let content = buffer.text();
                let todo_object = TodoObject::new(false, content);
                model.append(&todo_object);
                buffer.set_text("");
            }));

        // Setup callback so that click on the clear_button
        // removes all done tasks
        imp.clear_button
            .connect_clicked(clone!(@weak model => move |_| {
                let mut position = 0;
                while let Some(item) = model.item(position) {
                    // Get `TodoObject` from `glib::Object`
                    let todo_object = item
                        .downcast_ref::<TodoObject>()
                        .expect("The object needs to be of type `TodoObject`.");

                    if todo_object.is_completed() {
                        model.remove(position);
                    } else {
                        position += 1;
                    }
                }
            }));
    }

    fn setup_factory(&self) {
        // Create a new factory
        let factory = SignalListItemFactory::new();

        // Create an empty `TodoRow` during setup
        factory.connect_setup(move |_, list_item| {
            // Create `TodoRow`
            let todo_row = TodoRow::new();
            list_item.set_child(Some(&todo_row));
        });

        // Tell factory how to bind `TodoRow` to a `TodoObject`
        factory.connect_bind(move |_, list_item| {
            // Get `TodoObject` from `ListItem`
            let todo_object = list_item
                .item()
                .expect("The item has to exist.")
                .downcast::<TodoObject>()
                .expect("The item has to be an `TodoObject`.");

            // Get `TodoRow` from `ListItem`
            let todo_row = list_item
                .child()
                .expect("The child has to exist.")
                .downcast::<TodoRow>()
                .expect("The child has to be a `TodoRow`.");

            todo_row.bind(&todo_object);
        });

        // Tell factory how to unbind `TodoRow` from `TodoObject`
        factory.connect_unbind(move |_, list_item| {
            // Get `TodoRow` from `ListItem`
            let todo_row = list_item
                .child()
                .expect("The child has to exist.")
                .downcast::<TodoRow>()
                .expect("The child has to be a `TodoRow`.");

            todo_row.unbind();
        });

        // Set the factory of the list view
        let imp = self.imp();
        imp.list_view.set_factory(Some(&factory));
    }

    fn setup_shortcut_window(&self) {
        // Get `ShortcutsWindow` via `gtk::Builder`
        let builder = gtk::Builder::from_string(include_str!("shortcuts.ui"));
        let shortcuts = builder
            .object("shortcuts")
            .expect("Could not get object `shortcuts` from builder.");

        // After calling this method,
        // calling the action "win.show-help-overlay" will show the shortcut window
        self.set_help_overlay(Some(&shortcuts));
    }

    fn setup_filter_action(&self) {
        // Get state
        let imp = self.imp();

        // Create action from key "filter"
        let filter_action = imp.settings.create_action("filter");

        // Add action "filter" to action group "win"
        self.add_action(&filter_action);
    }
}

In setup_shortcut_window, we add a handy way to let users of our app know which shortcuts they can use.

Filename: listings/todo_app/2/window/mod.rs

mod imp;

use std::fs::File;

use crate::todo_object::{TodoData, TodoObject};
use crate::todo_row::TodoRow;
use crate::utils::data_path;
use glib::{clone, Object};
use gtk::prelude::*;
use gtk::subclass::prelude::*;
use gtk::{gio, glib};
use gtk::{Application, CustomFilter, FilterListModel, NoSelection, SignalListItemFactory};
use log::info;

glib::wrapper! {
    pub struct Window(ObjectSubclass<imp::Window>)
        @extends gtk::ApplicationWindow, gtk::Window, gtk::Widget,
        @implements gio::ActionGroup, gio::ActionMap, gtk::Accessible, gtk::Buildable,
                    gtk::ConstraintTarget, gtk::Native, gtk::Root, gtk::ShortcutManager;
}

impl Window {
    pub fn new(app: &Application) -> Self {
        // Create new window
        Object::new(&[("application", app)]).expect("Failed to create `Window`.")
    }

    fn model(&self) -> &gio::ListStore {
        // Get state
        let imp = self.imp();
        imp.model.get().expect("Could not get model")
    }

    fn filter(&self) -> Option<CustomFilter> {
        // Get state
        let imp = self.imp();

        // Get filter_state from settings
        let filter_state: String = imp.settings.get("filter");

        // Create custom filters
        let filter_open = CustomFilter::new(|obj| {
            // Get `TodoObject` from `glib::Object`
            let todo_object = obj
                .downcast_ref::<TodoObject>()
                .expect("The object needs to be of type `TodoObject`.");

            // Only allow completed tasks
            !todo_object.is_completed()
        });
        let filter_done = CustomFilter::new(|obj| {
            // Get `TodoObject` from `glib::Object`
            let todo_object = obj
                .downcast_ref::<TodoObject>()
                .expect("The object needs to be of type `TodoObject`.");

            // Only allow done tasks
            todo_object.is_completed()
        });

        // Return the correct filter
        match filter_state.as_str() {
            "All" => None,
            "Open" => Some(filter_open),
            "Done" => Some(filter_done),
            _ => unreachable!(),
        }
    }

    fn setup_model(&self) {
        // Create new model
        let model = gio::ListStore::new(TodoObject::static_type());

        // Get state and set model
        let imp = self.imp();
        imp.model.set(model).expect("Could not set model");

        // Wrap model with filter and selection and pass it to the list view
        let filter_model = FilterListModel::new(Some(self.model()), self.filter().as_ref());
        let selection_model = NoSelection::new(Some(&filter_model));
        imp.list_view.set_model(Some(&selection_model));

        // Filter model whenever the value of the key "filter" changes
        imp.settings.connect_changed(
            Some("filter"),
            clone!(@weak self as window, @weak filter_model => move |_, _| {
                filter_model.set_filter(window.filter().as_ref());
            }),
        );
    }

    fn restore_data(&self) {
        if let Ok(file) = File::open(data_path()) {
            // Deserialize data from file to vector
            let backup_data: Vec<TodoData> =
                serde_json::from_reader(file).expect("Could not get backup data from json file.");

            // Convert `Vec<TodoData>` to `Vec<TodoObject>`
            let todo_objects: Vec<TodoObject> = backup_data
                .into_iter()
                .map(|todo_data| TodoObject::new(todo_data.completed, todo_data.content))
                .collect();

            // Insert restored objects into model
            self.model().splice(0, 0, &todo_objects);
        } else {
            info!("Backup file does not exist yet {:?}", data_path());
        }
    }

    fn setup_callbacks(&self) {
        // Get state
        let imp = self.imp();
        let model = self.model();

        // Setup callback so that activation
        // creates a new todo object and clears the entry
        imp.entry
            .connect_activate(clone!(@weak model => move |entry| {
                let buffer = entry.buffer();
                let content = buffer.text();
                let todo_object = TodoObject::new(false, content);
                model.append(&todo_object);
                buffer.set_text("");
            }));

        // Setup callback so that click on the clear_button
        // removes all done tasks
        imp.clear_button
            .connect_clicked(clone!(@weak model => move |_| {
                let mut position = 0;
                while let Some(item) = model.item(position) {
                    // Get `TodoObject` from `glib::Object`
                    let todo_object = item
                        .downcast_ref::<TodoObject>()
                        .expect("The object needs to be of type `TodoObject`.");

                    if todo_object.is_completed() {
                        model.remove(position);
                    } else {
                        position += 1;
                    }
                }
            }));
    }

    fn setup_factory(&self) {
        // Create a new factory
        let factory = SignalListItemFactory::new();

        // Create an empty `TodoRow` during setup
        factory.connect_setup(move |_, list_item| {
            // Create `TodoRow`
            let todo_row = TodoRow::new();
            list_item.set_child(Some(&todo_row));
        });

        // Tell factory how to bind `TodoRow` to a `TodoObject`
        factory.connect_bind(move |_, list_item| {
            // Get `TodoObject` from `ListItem`
            let todo_object = list_item
                .item()
                .expect("The item has to exist.")
                .downcast::<TodoObject>()
                .expect("The item has to be an `TodoObject`.");

            // Get `TodoRow` from `ListItem`
            let todo_row = list_item
                .child()
                .expect("The child has to exist.")
                .downcast::<TodoRow>()
                .expect("The child has to be a `TodoRow`.");

            todo_row.bind(&todo_object);
        });

        // Tell factory how to unbind `TodoRow` from `TodoObject`
        factory.connect_unbind(move |_, list_item| {
            // Get `TodoRow` from `ListItem`
            let todo_row = list_item
                .child()
                .expect("The child has to exist.")
                .downcast::<TodoRow>()
                .expect("The child has to be a `TodoRow`.");

            todo_row.unbind();
        });

        // Set the factory of the list view
        let imp = self.imp();
        imp.list_view.set_factory(Some(&factory));
    }

    fn setup_shortcut_window(&self) {
        // Get `ShortcutsWindow` via `gtk::Builder`
        let builder = gtk::Builder::from_string(include_str!("shortcuts.ui"));
        let shortcuts = builder
            .object("shortcuts")
            .expect("Could not get object `shortcuts` from builder.");

        // After calling this method,
        // calling the action "win.show-help-overlay" will show the shortcut window
        self.set_help_overlay(Some(&shortcuts));
    }

    fn setup_filter_action(&self) {
        // Get state
        let imp = self.imp();

        // Create action from key "filter"
        let filter_action = imp.settings.create_action("filter");

        // Add action "filter" to action group "win"
        self.add_action(&filter_action);
    }
}

The entries can be organized with gtk::ShortcutsSection and gtk::ShortcutsGroup. If we specify the action name, we also do not have to repeat the keyboard accelerator. gtk::ShortcutsShortcut looks it up on its own. The shortcuts.ui file looks like this:

<?xml version="1.0" encoding="UTF-8"?>
<interface>
  <object class="GtkShortcutsWindow" id="shortcuts">
    <property name="modal">True</property>
    <child>
      <object class="GtkShortcutsSection">
        <property name="section-name">shortcuts</property>
        <property name="max-height">10</property>
        <child>
          <object class="GtkShortcutsGroup">
            <property name="title" translatable="yes" context="shortcut window">General</property>
            <child>
              <object class="GtkShortcutsShortcut">
                <property name="title" translatable="yes" context="shortcut window">Show shortcuts</property>
                <property name="action-name">win.show-help-overlay</property>
              </object>
            </child>
            <child>
              <object class="GtkShortcutsShortcut">
                <property name="title" translatable="yes" context="shortcut window">Filter to show all tasks</property>
                <property name="action-name">win.filter('All')</property>
              </object>
            </child>
            <child>
              <object class="GtkShortcutsShortcut">
                <property name="title" translatable="yes" context="shortcut window">Filter to show only open tasks</property>
                <property name="action-name">win.filter('Open')</property>
              </object>
            </child>
            <child>
              <object class="GtkShortcutsShortcut">
                <property name="title" translatable="yes" context="shortcut window">Filter to show only completed tasks</property>
                <property name="action-name">win.filter('Done')</property>
              </object>
            </child>
          </object>
        </child>
      </object>
    </child>
  </object>
</interface>

Note the way we set action-name for ShortcutsShortcut. Instead of using a separate property for the target, it takes a detailed action name. Detailed names look like this: action_group.action_name(target). Formatting of the target depends on its type and is documented here. In particular, strings have to be enclosed single quotes as you can see in this example.

Finally, we bind the shortcuts to their actions with set_accels_for_action. Here as well, a detailed action name is used. Since this has to be done at the application level, setup_shortcuts takes a gtk::Application as parameter.

Filename: listings/todo_app/2/main.rs

mod todo_object;
mod todo_row;
mod utils;
mod window;

use gtk::prelude::*;
use gtk::Application;

use window::Window;

fn main() {
    // Initialize logger
    pretty_env_logger::init();

    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.Todo")
        .build();

    // Connect to signals
    app.connect_startup(setup_shortcuts);
    app.connect_activate(build_ui);

    // Run the application
    app.run();
}

fn setup_shortcuts(app: &Application) {
    app.set_accels_for_action("win.filter('All')", &["<primary>a"]);
    app.set_accels_for_action("win.filter('Open')", &["<primary>o"]);
    app.set_accels_for_action("win.filter('Done')", &["<primary>d"]);
    app.set_accels_for_action("win.show-help-overlay", &["<primary>question"]);
}

fn build_ui(app: &Application) {
    // Create a new custom window and show it
    let window = Window::new(app);
    window.present();
}

Saving and Restoring Tasks

Since we use Settings, our filter state will persist between sessions. However, the tasks themselves will not. Let us implement that.

We could store our tasks in Settings, but it would be inconvenient. When it comes to serializing and deserializing nothing beats the crate serde. Combined with serde_json we can save our tasks as serialized json files First, we extend our Cargo.toml with the serde and serde_json crate.

[dependencies]
serde = { version = "1.0", features = ["derive"] }
serde_json = "1.0"

Serde is a framework for serializing and deserializing Rust data structures. The derive feature allows us to make our structures (de-)serializable with a single line of code. We also use the rc feature so that Serde can deal with std::rc::Rc objects.

This is why we stored the data of TodoObject in a distinct TodoData structure. Doing so allows us to derive Serialize and Deserialize for TodoData.

Filename: listings/todo_app/2/todo_object/mod.rs

mod imp;

use glib::Object;
use gtk::glib;
use gtk::subclass::prelude::*;
use serde::{Deserialize, Serialize};

glib::wrapper! {
    pub struct TodoObject(ObjectSubclass<imp::TodoObject>);
}

impl TodoObject {
    pub fn new(completed: bool, content: String) -> Self {
        Object::new(&[("completed", &completed), ("content", &content)])
            .expect("Failed to create `TodoObject`.")
    }

    pub fn is_completed(&self) -> bool {
        let imp = self.imp();
        imp.data.borrow().completed
    }

    pub fn todo_data(&self) -> TodoData {
        let imp = self.imp();
        imp.data.borrow().clone()
    }
}

#[derive(Default, Serialize, Deserialize, Clone)]
pub struct TodoData {
    pub completed: bool,
    pub content: String,
}

We plan to store our data as a file, so we create a utility function to provide a suitable file path for us. We use glib::user_data_dir to get the path to the config directory and create a new subdirectory for our app. Then we return the file path.

Filename: listings/todo_app/2/utils.rs

use std::path::PathBuf;

use gtk::glib;

pub fn data_path() -> PathBuf {
    let mut path = glib::user_data_dir();
    path.push("org.gtk-rs.Todo");
    std::fs::create_dir_all(&path).expect("Could not create directory.");
    path.push("data.json");
    path
}

We override the close_request virtual function to save the tasks when the window is closed. To do so, we first iterate through all entries and store them in a Vec. Then we serialize the Vec and store the data as a json file.

Filename: listings/todo_app/2/window/imp.rs

use std::fs::File;

use gio::Settings;
use glib::signal::Inhibit;
use glib::subclass::InitializingObject;
use gtk::prelude::*;
use gtk::subclass::prelude::*;
use gtk::{gio, glib};
use gtk::{Button, CompositeTemplate, Entry, ListView, MenuButton};
use once_cell::sync::OnceCell;

use crate::todo_object::TodoObject;
use crate::utils::data_path;

// Object holding the state
#[derive(CompositeTemplate)]
#[template(file = "window.ui")]
pub struct Window {
    #[template_child]
    pub entry: TemplateChild<Entry>,
    #[template_child]
    pub menu_button: TemplateChild<MenuButton>,
    #[template_child]
    pub list_view: TemplateChild<ListView>,
    #[template_child]
    pub clear_button: TemplateChild<Button>,
    pub model: OnceCell<gio::ListStore>,
    pub settings: Settings,
}

impl Default for Window {
    fn default() -> Self {
        Window {
            entry: TemplateChild::default(),
            menu_button: TemplateChild::default(),
            list_view: TemplateChild::default(),
            clear_button: TemplateChild::default(),
            model: OnceCell::default(),
            settings: Settings::new("org.gtk-rs.Todo"),
        }
    }
}

// The central trait for subclassing a GObject
#[glib::object_subclass]
impl ObjectSubclass for Window {
    // `NAME` needs to match `class` attribute of template
    const NAME: &'static str = "TodoWindow";
    type Type = super::Window;
    type ParentType = gtk::ApplicationWindow;

    fn class_init(klass: &mut Self::Class) {
        Self::bind_template(klass);
    }

    fn instance_init(obj: &InitializingObject<Self>) {
        obj.init_template();
    }
}

// Trait shared by all GObjects
impl ObjectImpl for Window {
    fn constructed(&self, obj: &Self::Type) {
        // Call "constructed" on parent
        self.parent_constructed(obj);

        // Setup
        obj.setup_model();
        obj.restore_data();
        obj.setup_callbacks();
        obj.setup_factory();
        obj.setup_shortcut_window();
        obj.setup_filter_action();
    }
}

// Trait shared by all widgets
impl WidgetImpl for Window {}

// Trait shared by all windows
impl WindowImpl for Window {
    fn close_request(&self, window: &Self::Type) -> Inhibit {
        // Store todo data in vector
        let mut backup_data = Vec::new();
        let mut position = 0;
        while let Some(item) = window.model().item(position) {
            // Get `TodoObject` from `glib::Object`
            let todo_data = item
                .downcast_ref::<TodoObject>()
                .expect("The object needs to be of type `TodoObject`.")
                .todo_data();
            // Add todo data to vector and increase position
            backup_data.push(todo_data);
            position += 1;
        }

        // Save state in file
        let file = File::create(data_path()).expect("Could not create json file.");
        serde_json::to_writer_pretty(file, &backup_data)
            .expect("Could not write data to json file");

        // Pass close request on to the parent
        self.parent_close_request(window)
    }
}

// Trait shared by all application
impl ApplicationWindowImpl for Window {}

Note that we used serde_json::to_writer_pretty here. The pretty suffix suggests that the json file is formatted in a readable way. For your own app you might not care about this and go for serde_json::to_writer which produces smaller files. For this example we like it, because it allows us to see into what a Vec<TodoData> will be serialized.

Filename: data.json

[
  {
    "completed": true,
    "content": "Task Number Two"
  },
  {
    "completed": false,
    "content": "Task Number Five"
  },
  {
    "completed": true,
    "content": "Task Number Six"
  },
  {
    "completed": false,
    "content": "Task Number Seven"
  },
  {
    "completed": false,
    "content": "Task Number Eight"
  }
]

When we start the app, we will want to restore the saved data. Let us add a restore_data method for that. We make sure to handle the case where there is no data file there yet. It might be the first time that we started the app and therefore there is no former session to restore.

Filename: listings/todo_app/2/window/mod.rs

mod imp;

use std::fs::File;

use crate::todo_object::{TodoData, TodoObject};
use crate::todo_row::TodoRow;
use crate::utils::data_path;
use glib::{clone, Object};
use gtk::prelude::*;
use gtk::subclass::prelude::*;
use gtk::{gio, glib};
use gtk::{Application, CustomFilter, FilterListModel, NoSelection, SignalListItemFactory};
use log::info;

glib::wrapper! {
    pub struct Window(ObjectSubclass<imp::Window>)
        @extends gtk::ApplicationWindow, gtk::Window, gtk::Widget,
        @implements gio::ActionGroup, gio::ActionMap, gtk::Accessible, gtk::Buildable,
                    gtk::ConstraintTarget, gtk::Native, gtk::Root, gtk::ShortcutManager;
}

impl Window {
    pub fn new(app: &Application) -> Self {
        // Create new window
        Object::new(&[("application", app)]).expect("Failed to create `Window`.")
    }

    fn model(&self) -> &gio::ListStore {
        // Get state
        let imp = self.imp();
        imp.model.get().expect("Could not get model")
    }

    fn filter(&self) -> Option<CustomFilter> {
        // Get state
        let imp = self.imp();

        // Get filter_state from settings
        let filter_state: String = imp.settings.get("filter");

        // Create custom filters
        let filter_open = CustomFilter::new(|obj| {
            // Get `TodoObject` from `glib::Object`
            let todo_object = obj
                .downcast_ref::<TodoObject>()
                .expect("The object needs to be of type `TodoObject`.");

            // Only allow completed tasks
            !todo_object.is_completed()
        });
        let filter_done = CustomFilter::new(|obj| {
            // Get `TodoObject` from `glib::Object`
            let todo_object = obj
                .downcast_ref::<TodoObject>()
                .expect("The object needs to be of type `TodoObject`.");

            // Only allow done tasks
            todo_object.is_completed()
        });

        // Return the correct filter
        match filter_state.as_str() {
            "All" => None,
            "Open" => Some(filter_open),
            "Done" => Some(filter_done),
            _ => unreachable!(),
        }
    }

    fn setup_model(&self) {
        // Create new model
        let model = gio::ListStore::new(TodoObject::static_type());

        // Get state and set model
        let imp = self.imp();
        imp.model.set(model).expect("Could not set model");

        // Wrap model with filter and selection and pass it to the list view
        let filter_model = FilterListModel::new(Some(self.model()), self.filter().as_ref());
        let selection_model = NoSelection::new(Some(&filter_model));
        imp.list_view.set_model(Some(&selection_model));

        // Filter model whenever the value of the key "filter" changes
        imp.settings.connect_changed(
            Some("filter"),
            clone!(@weak self as window, @weak filter_model => move |_, _| {
                filter_model.set_filter(window.filter().as_ref());
            }),
        );
    }

    fn restore_data(&self) {
        if let Ok(file) = File::open(data_path()) {
            // Deserialize data from file to vector
            let backup_data: Vec<TodoData> =
                serde_json::from_reader(file).expect("Could not get backup data from json file.");

            // Convert `Vec<TodoData>` to `Vec<TodoObject>`
            let todo_objects: Vec<TodoObject> = backup_data
                .into_iter()
                .map(|todo_data| TodoObject::new(todo_data.completed, todo_data.content))
                .collect();

            // Insert restored objects into model
            self.model().splice(0, 0, &todo_objects);
        } else {
            info!("Backup file does not exist yet {:?}", data_path());
        }
    }

    fn setup_callbacks(&self) {
        // Get state
        let imp = self.imp();
        let model = self.model();

        // Setup callback so that activation
        // creates a new todo object and clears the entry
        imp.entry
            .connect_activate(clone!(@weak model => move |entry| {
                let buffer = entry.buffer();
                let content = buffer.text();
                let todo_object = TodoObject::new(false, content);
                model.append(&todo_object);
                buffer.set_text("");
            }));

        // Setup callback so that click on the clear_button
        // removes all done tasks
        imp.clear_button
            .connect_clicked(clone!(@weak model => move |_| {
                let mut position = 0;
                while let Some(item) = model.item(position) {
                    // Get `TodoObject` from `glib::Object`
                    let todo_object = item
                        .downcast_ref::<TodoObject>()
                        .expect("The object needs to be of type `TodoObject`.");

                    if todo_object.is_completed() {
                        model.remove(position);
                    } else {
                        position += 1;
                    }
                }
            }));
    }

    fn setup_factory(&self) {
        // Create a new factory
        let factory = SignalListItemFactory::new();

        // Create an empty `TodoRow` during setup
        factory.connect_setup(move |_, list_item| {
            // Create `TodoRow`
            let todo_row = TodoRow::new();
            list_item.set_child(Some(&todo_row));
        });

        // Tell factory how to bind `TodoRow` to a `TodoObject`
        factory.connect_bind(move |_, list_item| {
            // Get `TodoObject` from `ListItem`
            let todo_object = list_item
                .item()
                .expect("The item has to exist.")
                .downcast::<TodoObject>()
                .expect("The item has to be an `TodoObject`.");

            // Get `TodoRow` from `ListItem`
            let todo_row = list_item
                .child()
                .expect("The child has to exist.")
                .downcast::<TodoRow>()
                .expect("The child has to be a `TodoRow`.");

            todo_row.bind(&todo_object);
        });

        // Tell factory how to unbind `TodoRow` from `TodoObject`
        factory.connect_unbind(move |_, list_item| {
            // Get `TodoRow` from `ListItem`
            let todo_row = list_item
                .child()
                .expect("The child has to exist.")
                .downcast::<TodoRow>()
                .expect("The child has to be a `TodoRow`.");

            todo_row.unbind();
        });

        // Set the factory of the list view
        let imp = self.imp();
        imp.list_view.set_factory(Some(&factory));
    }

    fn setup_shortcut_window(&self) {
        // Get `ShortcutsWindow` via `gtk::Builder`
        let builder = gtk::Builder::from_string(include_str!("shortcuts.ui"));
        let shortcuts = builder
            .object("shortcuts")
            .expect("Could not get object `shortcuts` from builder.");

        // After calling this method,
        // calling the action "win.show-help-overlay" will show the shortcut window
        self.set_help_overlay(Some(&shortcuts));
    }

    fn setup_filter_action(&self) {
        // Get state
        let imp = self.imp();

        // Create action from key "filter"
        let filter_action = imp.settings.create_action("filter");

        // Add action "filter" to action group "win"
        self.add_action(&filter_action);
    }
}

Finally, we make sure that everything is set up in constructed.

Filename: listings/todo_app/2/window/imp.rs

use std::fs::File;

use gio::Settings;
use glib::signal::Inhibit;
use glib::subclass::InitializingObject;
use gtk::prelude::*;
use gtk::subclass::prelude::*;
use gtk::{gio, glib};
use gtk::{Button, CompositeTemplate, Entry, ListView, MenuButton};
use once_cell::sync::OnceCell;

use crate::todo_object::TodoObject;
use crate::utils::data_path;

// Object holding the state
#[derive(CompositeTemplate)]
#[template(file = "window.ui")]
pub struct Window {
    #[template_child]
    pub entry: TemplateChild<Entry>,
    #[template_child]
    pub menu_button: TemplateChild<MenuButton>,
    #[template_child]
    pub list_view: TemplateChild<ListView>,
    #[template_child]
    pub clear_button: TemplateChild<Button>,
    pub model: OnceCell<gio::ListStore>,
    pub settings: Settings,
}

impl Default for Window {
    fn default() -> Self {
        Window {
            entry: TemplateChild::default(),
            menu_button: TemplateChild::default(),
            list_view: TemplateChild::default(),
            clear_button: TemplateChild::default(),
            model: OnceCell::default(),
            settings: Settings::new("org.gtk-rs.Todo"),
        }
    }
}

// The central trait for subclassing a GObject
#[glib::object_subclass]
impl ObjectSubclass for Window {
    // `NAME` needs to match `class` attribute of template
    const NAME: &'static str = "TodoWindow";
    type Type = super::Window;
    type ParentType = gtk::ApplicationWindow;

    fn class_init(klass: &mut Self::Class) {
        Self::bind_template(klass);
    }

    fn instance_init(obj: &InitializingObject<Self>) {
        obj.init_template();
    }
}

// Trait shared by all GObjects
impl ObjectImpl for Window {
    fn constructed(&self, obj: &Self::Type) {
        // Call "constructed" on parent
        self.parent_constructed(obj);

        // Setup
        obj.setup_model();
        obj.restore_data();
        obj.setup_callbacks();
        obj.setup_factory();
        obj.setup_shortcut_window();
        obj.setup_filter_action();
    }
}

// Trait shared by all widgets
impl WidgetImpl for Window {}

// Trait shared by all windows
impl WindowImpl for Window {
    fn close_request(&self, window: &Self::Type) -> Inhibit {
        // Store todo data in vector
        let mut backup_data = Vec::new();
        let mut position = 0;
        while let Some(item) = window.model().item(position) {
            // Get `TodoObject` from `glib::Object`
            let todo_data = item
                .downcast_ref::<TodoObject>()
                .expect("The object needs to be of type `TodoObject`.")
                .todo_data();
            // Add todo data to vector and increase position
            backup_data.push(todo_data);
            position += 1;
        }

        // Save state in file
        let file = File::create(data_path()).expect("Could not create json file.");
        serde_json::to_writer_pretty(file, &backup_data)
            .expect("Could not write data to json file");

        // Pass close request on to the parent
        self.parent_close_request(window)
    }
}

// Trait shared by all application
impl ApplicationWindowImpl for Window {}

Our To-Do app suddenly became much more useful. Not only can we filter tasks, we also retain our tasks between sessions.

CSS

When you want to modify the style of your website, you use CSS. Similarly, GTK supports its own variant of CSS in order to style your app.

We will not explain every piece of syntax used in this chapter. If you are new to CSS or just need a refresher, have a look at the MDN Web Docs.

Let us say we have a button and we want to set its font color to magenta. Every type of widget has a corresponding CSS node. In the case of gtk::Button, this node is called button. Therefore, we create a style.css file with the following content:

Filename: listings/css/1/style.css

button {
  color: magenta;
}

Next, we need to load the CSS file in the startup step of the application. As usual, the widgets are created during the "activate" step.

Filename: listings/css/1/main.rs

use gdk::Display;
use gtk::gdk;
use gtk::prelude::*;
use gtk::{Application, ApplicationWindow, Button, CssProvider, StyleContext};

fn main() {
    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Connect to signals
    app.connect_startup(|_| load_css());
    app.connect_activate(build_ui);

    // Run the application
    app.run();
}

fn load_css() {
    // Load the CSS file and add it to the provider
    let provider = CssProvider::new();
    provider.load_from_data(include_bytes!("style.css"));

    // Add the provider to the default screen
    StyleContext::add_provider_for_display(
        &Display::default().expect("Could not connect to a display."),
        &provider,
        gtk::STYLE_PROVIDER_PRIORITY_APPLICATION,
    );
}

fn build_ui(app: &Application) {
    // Create button
    let button = Button::builder()
        .label("Press me!")
        .margin_top(12)
        .margin_bottom(12)
        .margin_start(12)
        .margin_end(12)
        .build();

    // Create a new window and show it
    let window = ApplicationWindow::builder()
        .application(app)
        .title("My GTK App")
        .child(&button)
        .build();
    window.show();
}

When we now run the app, we notice that our button and the "close" button are magenta. Probably not what we wanted, but that is what our CSS snippet does. We did not specify for which button the rule should apply, so it was applied to both of them.

The GtkInspector comes in quite handy (not only) when playing with CSS. Make sure that the window of your app is focused and press Ctrl + Shift + D. A window will pop up which lets you browse and even manipulate the state of your app. Open the CSS view and override the button color with the following snippet.

button {
 color: blue;
}

With the pause button you can toggle whether your CSS code is active or not.

Style Classes Applied by GTK

Class selectors are one way to choose which specific elements a CSS rule applies to. GTK adds style classes to many of its widgets, often depending on their content. A gtk::Button, for example, will get the text-button style class when its content is a label. That is why we create a new CSS rule which only applies to button nodes with the style class text_button.

Filename: listings/css/2/style.css

button.text-button {
  color: magenta;
}

Now only the font of our button becomes magenta.

Adding Your Own Style Class

With add_css_class we can also add our own style classes to widgets. One use-case for this is when you want a rule to apply to a hand-picked set of widgets. For example if we have two buttons, but want only one of them to have magenta font. Relying on one of the style classes which GTK adds will not help since both will get the same ones. Which is why we add the style class button-1 to the first one.

Filename: listings/css/3/main.rs

use gdk::Display;
use gtk::gdk;
use gtk::prelude::*;
use gtk::{Application, ApplicationWindow, Button, CssProvider, StyleContext};

fn main() {
    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Connect to signals
    app.connect_startup(|_| load_css());
    app.connect_activate(build_ui);

    // Run the application
    app.run();
}

fn load_css() {
    // Load the CSS file and add it to the provider
    let provider = CssProvider::new();
    provider.load_from_data(include_bytes!("style.css"));

    // Add the provider to the default screen
    StyleContext::add_provider_for_display(
        &Display::default().expect("Could not connect to a display."),
        &provider,
        gtk::STYLE_PROVIDER_PRIORITY_APPLICATION,
    );
}

fn build_ui(app: &Application) {
    // Create buttons
    let button_1 = Button::with_label("Press me!");
    let button_2 = Button::with_label("Press me!");

    button_1.add_css_class("button_1");

    // Create `gtk_box` and add buttons
    let gtk_box = gtk::Box::builder()
        .margin_top(12)
        .margin_bottom(12)
        .margin_start(12)
        .margin_end(12)
        .spacing(12)
        .build();
    gtk_box.append(&button_1);
    gtk_box.append(&button_2);

    // Create a new window and show it
    let window = ApplicationWindow::builder()
        .application(app)
        .title("My GTK App")
        .child(&gtk_box)
        .build();
    window.show();
}

Then, we create a CSS rule that applies to button nodes with the style class button-1.

Filename: listings/css/3/style.css

button.button-1 {
  color: magenta;
}

We can see that this way only the first button gets colored magenta.

Specifying Name of a Widget

If you want that your rule only applies to a single widget, matching with style classes can be fine. Ideally however, you would give the widget a name and match with that name instead. This way your intentions are more clear, compared to matching with style classes that can apply to multiple widgets.

Again, we have two buttons but want to color only one of them magenta. We set the name of the first one with set_widget_name.

Filename: listings/css/4/main.rs

use gdk::Display;
use gtk::gdk;
use gtk::prelude::*;
use gtk::{Application, ApplicationWindow, Button, CssProvider, StyleContext};

fn main() {
    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Connect to signals
    app.connect_startup(|_| load_css());
    app.connect_activate(build_ui);

    // Run the application
    app.run();
}

fn load_css() {
    // Load the CSS file and add it to the provider
    let provider = CssProvider::new();
    provider.load_from_data(include_bytes!("style.css"));

    // Add the provider to the default screen
    StyleContext::add_provider_for_display(
        &Display::default().expect("Could not connect to a display."),
        &provider,
        gtk::STYLE_PROVIDER_PRIORITY_APPLICATION,
    );
}

fn build_ui(app: &Application) {
    // Create buttons
    let button_1 = Button::with_label("Press me!");
    let button_2 = Button::with_label("Press me!");

    button_1.set_widget_name("button-1");

    // Create `gtk_box` and add buttons
    let gtk_box = gtk::Box::builder()
        .margin_top(12)
        .margin_bottom(12)
        .margin_start(12)
        .margin_end(12)
        .spacing(12)
        .build();
    gtk_box.append(&button_1);
    gtk_box.append(&button_2);

    // Create a new window and show it
    let window = ApplicationWindow::builder()
        .application(app)
        .title("My GTK App")
        .child(&gtk_box)
        .build();
    window.show();
}

Then, create a CSS rule that applies to button nodes with the name button-1. The name is specified after the # symbol.

Filename: listings/css/4/style.css

button#button-1 {
  color: magenta;
}

Again, the style rule only applies to the first button.

CSS Rules Provided by GTK

Certain styles are common enough that GTK provides CSS rules for them. For example, if you want to indicate that your button leads to a destructive or suggested action you do not have to provide your own CSS rules. All you have to do is to add "destructive-action" or "suggested-action" style class to your button. Most widgets will document these rules in their documentation under CSS nodes.

Filename: listings/css/5/main.rs

use gtk::prelude::*;
use gtk::{Application, ApplicationWindow, Button};

fn main() {
    // Create a new application
    let app = Application::builder()
        .application_id("org.gtk-rs.example")
        .build();

    // Connect to signals
    app.connect_activate(build_ui);

    // Run the application
    app.run();
}

fn build_ui(app: &Application) {
    // Create buttons
    let button_1 = Button::with_label("Destructive");
    let button_2 = Button::with_label("Suggested");

    button_1.add_css_class("destructive-action");
    button_2.add_css_class("suggested-action");

    // Create `gtk_box` and add buttons
    let gtk_box = gtk::Box::builder()
        .margin_top(12)
        .margin_bottom(12)
        .margin_start(12)
        .margin_end(12)
        .spacing(6)
        .build();
    gtk_box.append(&button_1);
    gtk_box.append(&button_2);

    // Create a new window and show it
    let window = ApplicationWindow::builder()
        .application(app)
        .title("My GTK App")
        .child(&gtk_box)
        .build();
    window.show();
}

Interface Builder

We can also add style classes with the interface builder. Just add the <style> element to your widget. The <style> element is documented together with gtk::Widget. Adding again destructive and suggested buttons, would then look like this:

Filename: listings/css/6/window/window.ui

<?xml version="1.0" encoding="UTF-8"?>
<interface>
  <template class="MyGtkAppWindow" parent="GtkApplicationWindow">
    <property name="title" translatable="yes">My GTK App</property>
    <child>
      <object class="GtkBox">
        <property name="margin-top">12</property>
        <property name="margin-bottom">12</property>
        <property name="margin-start">12</property>
        <property name="margin-end">12</property>
        <property name="spacing">6</property>
        <child>
          <object class="GtkButton">
            <property name="label">Destructive</property>
            <style>
              <class name="destructive-action"/>
            </style>
          </object>
        </child>
        <child>
          <object class="GtkButton">
            <property name="label">Suggested</property>
            <style>
              <class name="suggested-action"/>
            </style>
          </object>
        </child>
      </object>
    </child>
  </template>
</interface>

Pseudo-classes

Sometimes you want your CSS rules to apply under even more precise conditions than style classes allow. That is where pseudo-classes come in. Let us use a single button with name button-1 to demonstrate this concept.

Filename: listings/css/7/window/window.ui

<?xml version="1.0" encoding="UTF-8"?>
<interface>
  <template class="MyGtkAppWindow" parent="GtkApplicationWindow">
    <property name="title" translatable="yes">My GTK App</property>
    <child>
      <object class="GtkButton">
        <property name="label">Hover over me!</property>
        <property name="margin-top">12</property>
        <property name="margin-bottom">12</property>
        <property name="margin-start">12</property>
        <property name="margin-end">12</property>
        <property name="name">button-1</property>
      </object>
    </child>
  </template>
</interface>

By adding the pseudo-class hover, we say that we want this rule to only apply to a button node with name button-1 when hovering over it with the mouse pointer.

Filename: listings/css/7/style.css

button#button-1:hover {
  color: magenta;
  background: yellow;
}

If we now hover over the button, we see that over the span of one second its background turns yellow and its font turns magenta. After we removed the cursor, the button returns to its original state.

Nodes

In the previous examples, a widget always corresponded to a single CSS node. This is not always the case. For example, gtk::MenuButton has multiple CSS nodes. Let us see how that works.

First, we create a single MenuButton.

Filename: listings/css/8/window/window.ui

<?xml version="1.0" encoding="UTF-8"?>
<interface>
  <template class="MyGtkAppWindow" parent="GtkApplicationWindow">
    <property name="title" translatable="yes">My GTK App</property>
    <child>
      <object class="GtkMenuButton">
        <property name="margin-top">12</property>
        <property name="margin-bottom">12</property>
        <property name="margin-start">12</property>
        <property name="margin-end">12</property>
      </object>
    </child>
  </template>
</interface>

You can make a MenuButton show an icon or a label. If you choose to do neither of those, as we currently do, it shows an image displaying an arrow.

An inheritance tree of CSS nodes displays this situation:

menubutton
╰── button.toggle
    ╰── <content>
         ╰── [arrow]

We see that the menubutton node has children, which themselves have children and attached style classes. Now we know that we have to add a CSS rule that applies to the arrow node, which is a descendant of menubutton.

Filename: listings/css/8/style.css

menubutton arrow {
  color: magenta;
}

Indeed, we get a MenuButton with a magenta arrow.

Exported Colors

Now that we know how to use CSS, it is time to update our To-Do app. Before, the individual tasks were a bit hard to distinguish. It would be nice if the todo rows would be surrounded by borders. Let us add that!

The class TodoRow inherits from gtk::Box, so we could just match for the node box. However, if we create a custom widget we might as well give it its own CSS name. Keep in mind, that this is not the same as when we gave a specific instance of a widget a name. When calling set_css_name , we change the name of the CSS node of a widget. In our case, the widget TodoRow now corresponds to the node todo-row.

Filename: listings/todo_app/3/todo_row/imp.rs

use glib::Binding;
use gtk::prelude::*;
use gtk::subclass::prelude::*;
use gtk::{glib, CheckButton, CompositeTemplate, Label};
use std::cell::RefCell;

// Object holding the state
#[derive(Default, CompositeTemplate)]
#[template(file = "todo_row.ui")]
pub struct TodoRow {
    #[template_child]
    pub completed_button: TemplateChild<CheckButton>,
    #[template_child]
    pub content_label: TemplateChild<Label>,
    // Vector holding the bindings to properties of `TodoObject`
    pub bindings: RefCell<Vec<Binding>>,
}

// The central trait for subclassing a GObject
#[glib::object_subclass]
impl ObjectSubclass for TodoRow {
    // `NAME` needs to match `class` attribute of template
    const NAME: &'static str = "TodoRow";
    type Type = super::TodoRow;
    type ParentType = gtk::Box;

    fn class_init(klass: &mut Self::Class) {
        Self::bind_template(klass);
        klass.set_css_name("todo-row");
    }

    fn instance_init(obj: &glib::subclass::InitializingObject<Self>) {
        obj.init_template();
    }
}

// Trait shared by all GObjects
impl ObjectImpl for TodoRow {}

// Trait shared by all widgets
impl WidgetImpl for TodoRow {}

// Trait shared by all boxes
impl BoxImpl for TodoRow {}

Now we have to decide which color to use for the borders. Luckily, the stylesheet that GTK uses provides pre-defined colors for various use-cases. As of this writing, the exported colors of the default stylesheet can only be found in its source code.

There we find the color borders, which should be used for the widget's border color. We can then access the pre-defined color by adding an @ in front of its name.

Filename: listings/todo_app/3/style.css

todo-row {
  border: 1px solid @borders;
}

Now our tasks have borders around them, and we are one step further in finishing our To-Do app.

This was also an excellent opportunity to show how to set the CSS name of custom widget and how to access exported colors. In the end, we find that GTK provides a style rule to add borders to a node. This seems nicer, so we will use that instead. We match the style rule by adding the style class frame to our TodoRow.

Filename: listings/todo_app/4/todo_row/todo_row.ui

<?xml version="1.0" encoding="UTF-8"?>
<interface>
  <template class="TodoRow" parent="GtkBox">
    <child>
      <object class="GtkCheckButton" id="completed_button">
        <property name="margin-top">12</property>
        <property name="margin-bottom">12</property>
        <property name="margin-start">12</property>
        <property name="margin-end">12</property>
      </object>
    </child>
    <child>
      <object class="GtkLabel" id="content_label">
        <property name="margin-top">12</property>
        <property name="margin-bottom">12</property>
        <property name="margin-start">12</property>
        <property name="margin-end">12</property>
      </object>
    </child>
    <style>
      <class name="frame"/>
    </style>
  </template>
</interface>

Conclusion

There are surely enough ways to define CSS rules. Let us briefly recap the syntax we learned. The following rule matches the node arrow, which is a descendant of the node button with the name button-1 and the style classes toggle and text-button. The rule then actually applies, when we also hover over arrow.

button#button-1.toggle.text-button arrow:hover {
  color: magenta;
}

When the rule applies, the color parameter will be set to magenta. You can find the full list of supported parameters in GTK's documentation.

In the following chapter we will learn how to make a binary bundle with CSS files, icons and any other resources that our app might need at runtime.

Resources
